Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
CONTROL HEADPHONE LCD LOADING MAIN
R847 1-216-065-00 RES-CHIP 4.7K 5% 1/10W
R848 1-216-065-00 RES-CHIP 4.7K 5% 1/10W
R849 1-216-065-00 RES-CHIP 4.7K 5% 1/10W
R851 1-216-073-00 METAL CHIP 10K 5% 1/10W
R852 1-216-073-00 METAL CHIP 10K 5% 1/10W
< ROTARY ENCODER >
RV801 1-473-392-11 ENCODER, ROTARY (VOLUME)
RV802 1-418-859-11 ENCODER, ROTARY (BASS)
RV803 1-418-859-11 ENCODER, ROTARY (TREBLE)
< SWITCH >
S800 1-571-760-11 SWITCH, KEY BOARD (TUNING −)
S801 1-571-760-11 SWITCH, KEY BOARD (TUNING +)
S802 1-571-760-11 SWITCH, KEY BOARD (REC z)
S803 1-571-760-11 SWITCH, KEY BOARD (TAPE B M)
S804 1-571-760-11 SWITCH, KEY BOARD (TAPE B m)
S805 1-571-760-11 SWITCH, KEY BOARD (TAPE B x)
S806 1-571-760-11 SWITCH, KEY BOARD (TAPE B Y)
S807 1-571-760-11 SWITCH, KEY BOARD (BAND)
S808 1-571-760-11 SWITCH, KEY BOARD (CD x)
S809 1-571-760-11 SWITCH, KEY BOARD (CD u)
S810 1-571-760-11 SWITCH, KEY BOARD (TUNING MODE)
S811 1-571-760-11 SWITCH, KEY BOARD (CD REPEAT)
S812 1-571-760-11 SWITCH, KEY BOARD (PLAY MODE)
S813 1-571-760-11 SWITCH, KEY BOARD (CD > M)
S814 1-571-760-11 SWITCH, KEY BOARD (CD . m)
S815 1-571-760-11 SWITCH, KEY BOARD (CD Z)
S817 1-571-760-11 SWITCH, KEY BOARD (DSG)
S818 1-571-760-11 SWITCH, KEY BOARD (VIDEO)
S819 1-571-760-11 SWITCH, KEY BOARD (MD)
S820 1-571-760-11 SWITCH, KEY BOARD (TAPE)
S821 1-571-760-11 SWITCH, KEY BOARD (CD)
S822 1-571-760-11 SWITCH, KEY BOARD (TUNER)
S823 1-571-760-11 SWITCH, KEY BOARD (I/1)
S824 1-571-760-11 SWITCH, KEY BOARD (X)
S825 1-571-760-11 SWITCH, KEY BOARD (CD SYNC)
S827 1-571-760-11 SWITCH, KEY BOARD
(HI SPEED DUBBING AtB)
S828 1-571-760-11 SWITCH, KEY BOARD (TAPE A M)
S829 1-571-760-11 SWITCH, KEY BOARD (TAPE A m)
S830 1-571-760-11 SWITCH, KEY BOARD (TAPE A x)
S831 1-571-760-11 SWITCH, KEY BOARD (TAPE A Y)
**************************************************************
1-678-412-11 HEADPHONE BOARD
*****************
< CAPACITOR >
C135 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C235 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
< JACK >
J301 1-785-925-11 JACK (PHONES)
< COIL >
L102 1-410-993-42 INDUCTOR CHIP 1uH
L202 1-410-993-42 INDUCTOR CHIP 1uH
**************************************************************
1-678-409-11 LCD BOARD
**********
< CONNECTOR >
CN802 1-793-599-11 CONNECTOR, FFC/FPC (ZIF) 17P
CN804 1-793-601-11 CONNECTOR, FFC/FPC (ZIF) 21P
< LED >
D800 8-719-075-51 LED SELS6B14C-LF62 (LCD BACK LIGHT)
D801 8-719-075-51 LED SELS6B14C-LF62 (LCD BACK LIGHT)
D802 8-719-075-51 LED SELS6B14C-LF62 (LCD BACK LIGHT)
D803 8-719-075-51 LED SELS6B14C-LF62 (LCD BACK LIGHT)
< SHORT >
JR601 1-216-296-00 SHORT 0
JR609 1-216-296-00 SHORT 0
< LIQUID CRYSTAL DISPLAY >
LCD801 1-803-542-11 DISPLAY PANEL, LIQUID CRYSTAL
**************************************************************
1-676-599-11 LOADING BOARD
**************
< CONNECTOR >
* CN1 1-568-943-11 PIN, CONNECTOR 5P
< SWITCH >
S1 1-771-799-11 SWITCH, LEVER (SLIDE)
(DISC TRAY OPEN/CLOSE DETECT)
**************************************************************
A-4473-598-A MAIN BOARD, COMPLETE (AEP, UK)
A-4475-017-A MAIN BOARD, COMPLETE (EA)
A-4475-018-A MAIN BOARD, COMPLETE (AUS)
**********************
7-685-546-14 SCREW +BTP 3X8 TYPE2 N-S
< CAPACITOR >
C101 1-126-963-11 ELECT 4.7uF 20% 50V
C102 1-126-963-11 ELECT 4.7uF 20% 50V
C103 1-126-963-11 ELECT 4.7uF 20% 50V
C104 1-126-963-11 ELECT 4.7uF 20% 50V
C105 1-126-963-11 ELECT 4.7uF 20% 50V
C106 1-126-963-11 ELECT 4.7uF 20% 50V
C107 1-163-022-00 CERAMIC CHIP 0.012uF 10% 50V
C109 1-126-963-11 ELECT 4.7uF 20% 50V
C110 1-126-963-11 ELECT 4.7uF 20% 50V
C111 1-163-023-00 CERAMIC CHIP 0.015uF 5% 50V
C112 1-163-023-00 CERAMIC CHIP 0.015uF 5% 50V
C113 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C114 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C115 1-163-014-00 CERAMIC CHIP 0.0027uF 10% 50V
