Sony HCD-CP2A - Page 8

8
BASE UNIT (BU-K5BD41)
TRAY, LOADING BOARD
1 floating screw
(PTPWHM2.6)
2 base unit
(BU-K5BD41)
2 belt (CDM55)
B
3 Pull the tray pushing B.
4 two screws
(BTP2.6 × 6)
5 LOADING board
1 Rotate the gear(B) in
the direction of arrow A.
A
