Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
47
HCD-CQ1
R207 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R208 1-216-813-11 METAL CHIP 220 5% 1/16W
R209 1-216-833-11 METAL CHIP 10K 5% 1/16W
R212 1-216-813-11 METAL CHIP 220 5% 1/16W
R213 1-216-809-11 METAL CHIP 100 5% 1/16W
R251 1-216-805-11 METAL CHIP 47 5% 1/16W
R252 1-216-813-11 METAL CHIP 220 5% 1/16W
< VIBRATOR >
X101 1-567-098-41 VIBRATOR, CRYSTAL (32.768kHz)
X102 1-577-360-11 VIBRATOR, CERAMIC (6MHz)
************************************************************
A-4731-461-A JACK BOARD, COMPLETE
*********************
< CAPACITOR >
C701 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C702 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C703 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C704 1-162-953-11 CERAMIC CHIP 100PF 5% 50V
C705 1-162-953-11 CERAMIC CHIP 100PF 5% 50V
C706 1-162-953-11 CERAMIC CHIP 100PF 5% 50V
C707 1-162-953-11 CERAMIC CHIP 100PF 5% 50V
C708 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C709 1-164-156-11 CERAMIC CHIP 0.1uF 25V
< CONNECTOR >
CN701 1-568-830-11 CONNECTOR, FFC 11P
< TERMINAL BOARD >
EP701 1-537-770-21 TERMINAL BOARD, GROUND
< JACK >
J701 1-566-891-11 JACK (PHONES)
J702 1-573-798-11 JACK, MINIATURE (DIA. 3.5)(IN)
J703 1-573-798-11 JACK, MINIATURE (DIA. 3.5)(OUT)
< RESISTOR >
R701 1-218-867-11 METAL CHIP 6.8K 5% 1/10W
R702 1-216-833-11 METAL CHIP 10K 5% 1/16W
R703 1-218-867-11 METAL CHIP 6.8K 5% 1/10W
R704 1-216-833-11 METAL CHIP 10K 5% 1/16W
R705 1-216-845-11 METAL CHIP 100K 5% 1/16W
R706 1-216-864-11 METAL CHIP 0 5% 1/16W
R707 1-216-845-11 METAL CHIP 100K 5% 1/16W
R708 1-216-864-11 METAL CHIP 0 5% 1/16W
************************************************************
LOADING BOARD
**************
< CONNECTOR >
CN1 1-785-331-11 PIN, CONNECTOR (LIGHT ANGLE) 5P
< SWITCH >
S1 1-786-514-11 SWITCH, LEVER (SLIDE)
(LODING IN/OUT DETECT)
************************************************************
1-687-250-11 PANEL BOARD
************
4-244-735-01 PLATE, LIGHT GUIDE
4-244-736-01 SHEET (LCD)
4-246-812-01 SHEET, REFLECTION
< CAPACITOR >
C401 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C402 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C403 1-162-974-11 CERAMIC CHIP 0.01uF 50V
< CONNECTOR >
CN401 1-784-881-21 CONNECTOR,FFC (LIF (NON-ZIF)) 33P
< DIODE >
D401 6-500-646-01 DIODE SECU4E01C (BACK LIGHT)
D402 6-500-646-01 DIODE SECU4E01C (BACK LIGHT)
D403 6-500-646-01 DIODE SECU4E01C (BACK LIGHT)
D404 6-500-646-01 DIODE SECU4E01C (BACK LIGHT)
< LIQUID CRYSTAL DISPLAY >
LCD401 1-805-197-11 DISPLAY PANEL, LIQUID CRYSTAL
< RESISTOR >
R401 1-216-821-11 METAL CHIP 1K 5% 1/16W
R402 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R403 1-216-813-11 METAL CHIP 220 5% 1/16W
R404 1-216-813-11 METAL CHIP 220 5% 1/16W
R405 1-216-813-11 METAL CHIP 220 5% 1/16W
R406 1-216-813-11 METAL CHIP 220 5% 1/16W
R407 1-216-821-11 METAL CHIP 1K 5% 1/16W
R408 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R409 1-216-821-11 METAL CHIP 1K 5% 1/16W
R410 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R411 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R412 1-216-833-11 METAL CHIP 10K 5% 1/10W
R413 1-216-833-11 METAL CHIP 10K 5% 1/10W
R421 1-216-809-11 METAL CHIP 100 5% 1/16W
R422 1-216-809-11 METAL CHIP 100 5% 1/16W
R423 1-216-809-11 METAL CHIP 100 5% 1/16W
R424 1-216-809-11 METAL CHIP 100 5% 1/16W
R425 1-216-809-11 METAL CHIP 100 5% 1/16W
R426 1-216-809-11 METAL CHIP 100 5% 1/16W
R427 1-216-809-11 METAL CHIP 100 5% 1/16W
R428 1-216-809-11 METAL CHIP 100 5% 1/16W
R429 1-216-809-11 METAL CHIP 100 5% 1/16W
R430 1-216-809-11 METAL CHIP 100 5% 1/16W
R431 1-216-809-11 METAL CHIP 100 5% 1/16W
R432 1-216-809-11 METAL CHIP 100 5% 1/16W
R433 1-216-809-11 METAL CHIP 100 5% 1/16W
R434 1-216-809-11 METAL CHIP 100 5% 1/16W
R435 1-216-809-11 METAL CHIP 100 5% 1/16W
R436 1-216-809-11 METAL CHIP 100 5% 1/16W
R437 1-216-809-11 METAL CHIP 100 5% 1/16W
JACK LOADINGCONTROL PANEL
