Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
48
HCD-CQ1
R438 1-216-809-11 METAL CHIP 100 5% 1/16W
R439 1-216-809-11 METAL CHIP 100 5% 1/16W
R440 1-216-809-11 METAL CHIP 100 5% 1/16W
R441 1-216-809-11 METAL CHIP 100 5% 1/16W
R442 1-216-809-11 METAL CHIP 100 5% 1/16W
R443 1-216-809-11 METAL CHIP 100 5% 1/16W
R444 1-216-809-11 METAL CHIP 100 5% 1/16W
R445 1-216-809-11 METAL CHIP 100 5% 1/16W
R446 1-216-809-11 METAL CHIP 100 5% 1/16W
R447 1-216-809-11 METAL CHIP 100 5% 1/16W
< SWITCH >
S401 1-762-333-21 SWITCH, TACTILE (^/1)
S402 1-762-333-21 SWITCH, TACTILE (DIMMER)
S403 1-762-333-21 SWITCH, TACTILE (VOLUME +)
S404 1-762-333-21 SWITCH, TACTILE (VOLUME -)
S405 1-762-333-21 SWITCH, TACTILE (FUCTION)
S406 1-762-333-21 SWITCH, TACTILE (+ >)
S407 1-762-333-21 SWITCH, TACTILE (. -)
S408 1-762-333-21 SWITCH, TACTILE (x)
S409 1-762-333-21 SWITCH, TACTILE (u)
S410 1-762-333-21 SWITCH, TACTILE (Z)
************************************************************
A-4731-453-A POWER BOARD, COMPLETE (US,CND)
A-4731-467-A POWER BOARD, COMPLETE (AEP,UK)
A-4731-472-A POWER BOARD, COMPLETE (SP)
A-4731-477-A POWER BOARD, COMPLETE (HK)
A-4731-482-A POWER BOARD, COMPLETE (AUS)
A-4731-487-A POWER BOARD, COMPLETE (TW)
A-4731-492-A POWER BOARD, COMPLETE (KR)
A-4731-497-A POWER BOARD, COMPLETE (MX)
***********************
7-685-647-79 SCREW +BVTP 3X10 TYPE2 IT-3
< CAPACITOR >
C301 1-124-261-00 ELECT 10uF 20% 50V
C302 1-136-165-00 MYLAR 0.1uF 5.00% 50V
C303 1-136-165-00 MYLAR 0.1uF 5.00% 50V
C304 1-130-476-00 MYLAR 0.0027uF 5% 50V
C305 1-126-163-11 ELECT 4.7uF 20% 50V
C306 1-126-163-11 ELECT 4.7uF 20% 50V
C307 1-126-163-11 ELECT 4.7uF 20% 50V
C308 1-126-163-11 ELECT 4.7uF 20% 50V
C309 1-126-163-11 ELECT 4.7uF 20% 50V
C310 1-124-261-00 ELECT 10uF 20% 50V
C311 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C312 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C313 1-162-953-11 CERAMIC CHIP 100PF 5% 50V
C315 1-128-499-11 ELECT 220uF 20.00% 16V
C316 1-119-774-11 ELECT 100uF 20.00% 16V
C317 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C351 1-124-261-00 ELECT 10uF 20% 50V
C352 1-136-165-00 YLAR 0.1uF 5.00% 50V
C353 1-136-165-00 MYLAR 0.1uF 5.00% 50V
C354 1-130-476-00 MYLAR 0.0027uF 5% 50V
C355 1-126-163-11 ELECT 4.7uF 20% 50V
C356 1-126-163-11 ELECT 4.7uF 20% 50V
C357 1-126-163-11 ELECT 4.7uF 20% 50V
C358 1-126-163-11 ELECT 4.7uF 20% 50V
C359 1-126-163-11 ELECT 4.7uF 20% 50V
C360 1-124-261-00 ELECT 10uF 20% 50V
C367 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C613 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C614 1-107-713-11 ELECT 4.7uF 20.00% 50V
C621 1-164-362-11 CERAMIC CHIP 470PF 5.00% 50V
C651 1-128-551-11 ELECT 22uF 20.00% 25V
C652 1-126-916-11 ELECT 1000uF 20.00% 6.3V
C671 1-164-362-11 CERAMIC CHIP 470PF 5.00% 50V
C802 1-136-165-00 FILM 0.1uF 5.00% 50V
C803 1-119-823-11 ELECT 4.7uF 20% 50V
C805 1-119-799-11 ELECT 47uF 20% 25V
C806 1-162-956-11 CERAMIC CHIP 180PF 5% 50V
C807 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C808 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C809 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C810 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C814 1-162-951-11 CERAMIC CHIP 68PF 5% 50V
C821 1-126-933-11 ELECT 100uF 20.00% 16V
C822 1-126-967-11 ELECT 47uF 20.00% 50V
C823 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C852 1-136-165-00 FILM 0.1uF 5.00% 50V
C853 1-119-823-11 ELECT 4.7uF 20% 50V
C855 1-119-799-11 ELECT 47uF 20% 25V
C856 1-162-956-11 CERAMIC CHIP 180PF 5% 50V
C857 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C858 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C859 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C860 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C864 1-162-951-11 CERAMIC CHIP 68PF 5% 50V
C901 1-104-665-11 ELECT 100uF 20.00% 10V
C903 1-126-767-11 ELECT 1000uF 20.00% 16V
C904 1-136-165-00 FILM 0.1uF 5.00% 50V
C905 1-136-165-00 FILM 0.1uF 5.00% 50V
0 C906 1-113-925-11 CERAMIC 0.01uF 20.00% 250V
C907 1-124-257-11 ELECT 2.2uF 20.00% 50V
C911 1-126-953-11 ELECT 2200uF 20.00% 35V
C912 1-126-953-11 ELECT 2200uF 20.00% 35V
C913 1-136-165-00 FILM 0.1uF 5.00% 50V
C914 1-136-165-00 FILM 0.1uF 5.00% 50V
C915 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C921 1-128-551-11 ELECT 22uF 20.00% 25V
C922 1-126-947-11 ELECT 47uF 20.00% 25V
C925 1-128-551-11 ELECT 22uF 20.00% 25V
C926 1-126-947-11 ELECT 47uF 20.00% 25V
C927 1-126-944-11 ELECT 3300uF 20.00% 25V
C928 1-136-165-00 FILM 0.1uF 5.00% 50V
C929 1-136-165-00 FILM 0.1uF 5.00% 50V
C931 1-128-551-11 ELECT 22uF 20.00% 25V
C932 1-126-947-11 ELECT 47uF 20.00% 25V
< CONNECTOR >
CN603 1-784-792-11 CONNECTOR, FFC 31P
CN604 1-568-830-11 CONNECTOR, FFC 11P
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Les composants identifiés par
une marque 0 sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
PANEL POWER
To Next Page
