Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
49
HCD-CQ1
CN605 1-568-830-11 CONNECTOR, FFC 11P
CN801 1-816-048-11 TERMINAL BOARD (SPEAKER)
0 CN901 1-564-321-00 PIN, CONNECTOR (3.96mm PITCH) 2P
0 CN902 1-564-321-21 PIN, CONNECTOR (3.96mm PITCH) 2P
CN903 1-691-767-11 PLUG (MICRO CONNECTOR) 5P
< DIODE >
D651 8-719-988-61 DIODE 1SS355TE-17
D821 8-719-988-61 DIODE 1SS355TE-17
D901 8-719-051-07 DIODE EC10DA40
D902 8-719-051-07 DIODE EC10DA40
D903 8-719-051-07 DIODE EC10DA40
D904 8-719-051-07 DIODE EC10DA40
D905 8-719-988-61 DIODE 1SS355TE-17
D907 8-719-988-61 DIODE 1SS355TE-17
D908 8-719-988-61 DIODE 1SS355TE-17
D911 8-719-500-56 DIODE D3SBA20
D912 8-719-975-85 DIODE 21DQ04N-TA2
D913 8-719-975-85 DIODE 21DQ04N-TA2
D914 8-719-975-85 DIODE 21DQ04N-TA2
D915 8-719-975-85 DIODE 21DQ04N-TA2
< TERMINAL BOARD >
EP901 1-537-770-21 TERMINAL BOARD, GROUND
EP902 1-537-770-21 TERMINAL BOARD, GROUND (US,CND)
< IC >
IC301 8-759-669-03 IC LC75342
IC801 8-759-333-24 IC LM1876TF
IC901 6-703-627-01 IC NJU7201L40 (T3)
IC911 8-759-445-59 IC BA033T
IC913 8-759-701-59 IC TA7809S
IC914 6-701-760-01 IC uPC3504AHF
< COIL >
L801 1-422-009-13 COIL, AIR-CORE
L851 1-422-009-13 COIL, AIR-CORE
< TRANSISTOR >
Q601 8-729-046-97 TRANSISTOR 2SD1938 (F) -T (TX) .SO
Q602 8-729-027-23 TRANSISTOR DTA114EKA-T146
Q603 8-729-027-23 TRANSISTOR DTA114EKA-T146
Q604 8-729-046-97 TRANSISTOR 2SD1938 (F) -T (TX) .SO
Q605 8-729-046-97 TRANSISTOR 2SD1938 (F) -T (TX) .SO
Q654 8-729-046-97 TRANSISTOR 2SD1938 (F) -T (TX) .SO
Q822 8-729-120-28 TRANSISTOR 2SC1623-T1-L5L6
Q823 8-729-120-28 TRANSISTOR 2SC1623-T1-L5L6
Q824 8-729-120-28 TRANSISTOR 2SC1623-T1-L5L6
Q901 8-729-120-28 TRANSISTOR 2SC1623-T1-L5L6
Q902 8-729-602-36 TRANSISTOR 2SA1602TP-1EF
Q911 6-550-185-01 TRANSISTOR RT1P137P-TP-1
Q912 8-729-900-53 TRANSISTOR DTC114EKA-T146
< RESISTOR >
R301 1-216-827-11 METAL CHIP 3.3K 5% 1/16W
R311 1-216-809-11 METAL CHIP 100 5% 1/16W
R312 1-216-809-11 METAL CHIP 100 5% 1/16W
R313 1-216-809-11 METAL CHIP 100 5% 1/16W
R314 1-216-864-11 METAL CHIP 0 5% 1/16W
R315 1-216-821-11 METAL CHIP 1K 5% 1/16W
R351 1-216-827-11 METAL CHIP 3.3K 5% 1/16W
R365 1-216-821-11 METAL CHIP 1K 5% 1/16W
R609 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R610 1-216-845-11 METAL CHIP 100K 5% 1/16W
R611 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R612 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R613 1-216-827-11 METAL CHIP 3.3K 5% 1/16W
R614 1-216-833-11 METAL CHIP 10K 5% 1/16W
R616 1-216-821-11 METAL CHIP 1K 5% 1/16W
R619 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R620 1-216-827-11 METAL CHIP 3.3K 5% 1/16W
R621 1-216-821-11 METAL CHIP 1K 5% 1/16W
R622 1-216-833-11 METAL CHIP 10K 5% 1/16W
R625 1-216-845-11 METAL CHIP 100K 5% 1/16W
R626 1-216-845-11 METAL CHIP 100K 5% 1/16W
R631 1-216-821-11 METAL CHIP 1K 5% 1/16W
R632 1-216-821-11 METAL CHIP 1K 5% 1/16W
R651 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R652 1-216-837-11 METAL CHIP 22K 5% 1/16W
R659 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R660 1-216-845-11 METAL CHIP 100K 5% 1/16W
R661 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R681 1-216-821-11 METAL CHIP 1K 5% 1/16W
R682 1-216-821-11 METAL CHIP 1K 5% 1/16W
R801 1-216-821-11 METAL CHIP 1K 5% 1/16W
R802 1-216-838-11 METAL CHIP 27K 5% 1/16W
R803 1-216-821-11 METAL CHIP 1K 5% 1/16W
R804 1-216-836-11 METAL CHIP 18K 5% 1/16W
R805 1-216-797-11 METAL CHIP 10 5% 1/16W
R806 1-260-320-11 CARBON 220 5% 1/2W
R807 1-216-841-11 METAL CHIP 47K 5% 1/16W
R808 1-260-076-11 CARBON 10 5% 1/2W
R809 1-216-797-11 METAL CHIP 10 5% 1/16W
R821 1-216-845-11 METAL CHIP 100K 5% 1/16W
R822 1-216-842-11 METAL CHIP 56K 5% 1/16W
R823 1-260-090-51 CARBON 180 5% 1/2W
(US,CND,MX,TW)
R823 1-260-163-11 CARBON 200 5% 1/2W
(EXCEPT US,CND,MX,TW)
R824 1-216-864-11 METAL CHIP 0 5% 1/16W
R851 1-216-821-11 METAL CHIP 1K 5% 1/16W
R852 1-216-838-11 METAL CHIP 27K 5% 1/16W
R853 1-216-821-11 METAL CHIP 1K 5% 1/16W
R854 1-216-836-11 METAL CHIP 18K 5% 1/16W
R855 1-216-797-11 METAL CHIP 10 5% 1/16W
R856 1-260-320-11 CARBON 220 5% 1/2W
R857 1-216-842-11 METAL CHIP 56K 5% 1/16W
R858 1-260-076-11 CARBON 10 5% 1/2W
R859 1-216-797-11 METAL CHIP 10 5% 1/16W
R902 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
0 R906 1-219-237-11 SOLID 3.3M 20% 1/2W
(US,CND)
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Les composants identifiés par
une marque 0 sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
