Sony HCD-CQ1 - Page 50

Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
50
HCD-CQ1
R907 1-216-821-11 METAL CHIP 1K 5% 1/16W
R908 1-216-821-11 METAL CHIP 1K 5% 1/16W
R909 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R910 1-216-864-11 METAL CHIP 0 5% 1/16W
0 R911 1-219-119-11 FUSIBLE 0.1 5% 1/4W
R912 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R913 1-216-817-11 METAL CHIP 470 5% 1/16W
R914 1-216-809-11 METAL CHIP 100 5% 1/16W
< RELAY >
RY801 1-755-170-11 RELAY (12V)
0 RY901 1-755-467-11 RELAY (POWER)
< TRANSFORMER >
0 T902 1-437-672-21 TRANSFORMER, POWER (US,CND,TW,MX)
0 T902 1-437-673-21 TRANSFORMER, POWER
(AEP,UK,HK,KR,SP,AUS)
************************************************************
A-4732-629-A REG BOARD, COMPLETE
*******************
< CAPACITOR >
C961 1-107-888-11 ELECT 47uF 20.00% 25V
C962 1-107-907-11 ELECT 22uF 20.00% 25V
< CONNECTOR >
CN961 1-785-315-11 PIN, CONNECTOR (STRAIGHT) 3P
< IC >
IC961 8-759-701-59 IC TA7809S
************************************************************
A-4731-459-A REMOCON BOARD, COMPLETE
*************************
< CAPACITOR >
C501 1-124-589-11 ELECT 47uF 20% 16V
C502 1-164-156-11 CERAMIC CHIP 0.1uF 25V
< CONNECTOR >
CN501 1-506-469-11 PIN, CONNECTOR 4P
< DIODE >
D501 8-719-055-70 DIODE SEL6210S-D-TP5 (STAND BY)
< IC >
IC501 8-759-826-32 IC NJL72H400A
< RESISTOR >
R501 1-216-805-11 METAL CHIP 47 5% 1/16W
R502 1-216-864-11 METAL CHIP 0 5% 1/16W
R503 1-216-817-11 METAL CHIP 470 5% 1/16W
************************************************************
MISCELLANEOUS
***************
101 1-693-603-31 TUNER (FM/AM) (HK,SP,TW,MX,AUS)
101 1-693-605-11 TUNER (FM/AM) (AEP,UK,KR)
101 1-693-623-11 TUNER (FM/AM)(FOR BLACK)(US,CND)
101 1-693-623-31 TUNER (FM/AM)(FOR WHITE)(US,CND)
102 1-765-324-11 FFC 11P
103 1-765-324-11 FFC 11P
0 107 1-769-079-22 CORD, POWER (KR)
0 107 1-775-790-11 CORD, POWER (AUS)
0 107 1-777-071-83 CORD, POWER (AEP,UK,HK,SP,TW)
0 107 1-783-531-11 CORD, POWER (US,CND)
0 107 1-827-226-11 CORD, POWER (MX)
156 1-827-558-11 FFC 21P (150)
157 1-827-559-11 FFC 33P (425)
159 1-773-320-11 FFC 31P (150)
212 1-792-024-11 WIRE (FLAT TYPE)(16 CORE)
263 1-452-925-21 MAGNET ASSY
0 604 8-820-020-02 OPTICAL PICK-UP (KSS-213D/Q-RP)
0 F901 1-533-451-11 FUSE, GLASS TUBE (DIA. 5)(3.15A 125V)
(US,CND)
0 F901 1-533-470-11 FUSE, GLASS TUBE (DIA. 5)(T3.15AL 250V)
(EXCEPT UC,CND)
0 F911 1-533-449-11 FUSE, GLASS TUBE (DIA. 5)(2.0A 125V)
(US,CND)
0 F911 1-533-467-11 FUSE, GLASS TUBE (T1.6A 250V)
(EXCEPT US,CND)
0 F912 1-533-449-11 FUSE, GLASS TUBE (DIA. 5)(2.0A 125V)
(US,CND)
0 F912 1-533-467-11 FUSE, GLASS TUBE (T1.6A 250V)
(EXCEPT US,CND)
M102 X-2625-769-1 GEAR ASSY (MB)(RP), MORTOR(SLED)
0 T901 1-439-715-11 TRANSFORMER, POWER (US,CND,TW,MX)
0 T901 1-439-716-11 TRANSFORMER, POWER (AEP,UK,SP,AUS)
0 T901 1-439-717-11 TRANSFORMER, POWER (HK,KR)
************************************************************
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Les composants identifiés par
une marque 0 sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
POWER REG REMOCON
Ver 1.2
