Sony HCD-DR4 - Printed Wiring Board - Panel VR Section

HCD-DR4/DR5/DR6/DR440/W300/W5000/XB500
– 75 – – 76 –
7-22. PRINTED WIRING BOARD – PANEL VR SECTION –
• See page 20 for Circuit Boards Location.
• Semiconductor
Location
D611 B-5
D612 C-4
D616 D-9
D618 D-11
D619 B-8
D620 B-8
D621 C-8
D623 C-9
D624 C-9
D625 C-10
D626 C-11
D627 C-11
Ref. No. Location
(Page 71)
