Sony HCD-DX70 - Front Panel Section

52
HCD-DX70
7-2. FRONT PANEL SECTION
Ref. No. Part No. Description Remarks
Ref. No. Part No. Description Remarks
51
67
52
54
55
53
56
57
58
59
59
60
61
FL601
Tape mechanism deck
not supplied
not supplied
not supplied
62
63
61
61
64
61
61
61
61
65
66
51 4-231-571-01 KNOB VOL
52 X-4953-362-1 FRONT PANEL ASSY
53 4-225-252-01 CUSHION (FOOT)
54 X-4953-412-1 TC HOLDER (R) ASSY
55 X-4953-360-1 TC HOLDER (L) ASSY
56 4-231-805-01 KNOB (MIC)
57 4-231-586-01 SPRING L
58 4-231-836-01 SPRING (HEART CAM-A)
59 4-224-104-11 DAMPER
60 1-680-263-11 CD SW BOARD
61 4-951-620-01 SCREW (2.6X8), +BVTP
62 4-231-581-01 HOLDER FL
63 A-4475-763-A PANEL MOUNTED PC BOARD
64 A-4475-778-A PAD SWITCH MOUNTED PC BOARD
65 4-231-841-01 SPRING (HEART CAM-B)
66 4-231-587-01 SPRING R
67 4-225-531-01 BRACKET (RING)
FL601 1-518-739-11 INDICATOR TUBE, FLUORESCENT
