Sony HCD-DX70 - MAIN MAIN TRANS MOTOR PAD SWITCH PANEL

63
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
HCD-DX70
D921 8-719-200-82 DIODE 11ES2
D922 8-719-200-82 DIODE 11ES2
D952 8-719-988-61 DIODE 1SS355TE-17
D953 8-719-988-61 DIODE 1SS355TE-17
< FERRITE BEAD >
FB201 1-216-864-91 SHORT 0
FB203 1-216-864-91 SHORT 0
FB204 1-216-864-91 SHORT 0
FB516 1-216-864-91 SHORT 0
FB562 1-216-864-91 SHORT 0
FB599 1-216-864-91 SHORT 0
< FRONT END >
FE1 1-693-477-11 FRONT END (3 GANGS)
< IC >
IC11 8-759-828-33 IC LA1845
IC51 8-759-584-70 IC LC72131
IC101 8-759-652-04 IC M61504FP-TP
IC102 8-759-710-97 IC NJM4565M (TE2)
IC104 8-759-710-97 IC NJM4565M (TE2)
IC105 8-759-525-25 IC BU4052BCF-E2
IC106 8-759-710-97 IC NJM4565M (TE2)
IC201 8-749-923-04 IC TOTX178A
IC202 8-759-491-46 IC TC74VHCT04AFT (EL)
IC301 8-759-652-02 IC HA12226F
IC302 8-759-143-54 IC uPC1330HA
IC303 8-759-656-83 IC NJM4580MD-TE
IC304 8-759-656-83 IC NJM4580MD-TE
IC501 8-759-829-45 IC M30620MCA-A95FP
IC502 8-759-635-63 IC M51943BSL-TP
IC911 8-759-039-69 IC uPC7805AHF
IC921 8-759-088-08 IC uPC7812AHF
IC951 8-759-158-62 IC TA78057S
IC961 8-759-701-59 IC AN7809
< IFT >
IFT11 1-435-848-11 TRANSFORMER,IF (CERAMIC FILTER)
< JACK >
J101 1-793-987-11 JACK, PIN 2P
J102 1-793-987-11 JACK, PIN 2P
< JUMPER RESISTOR >
JR1 1-216-864-91 SHORT 0
JR2 1-216-864-91 SHORT 0
JR3 1-216-864-91 SHORT 0
JR4 1-216-864-91 SHORT 0
JR5 1-216-864-91 SHORT 0
JR7 1-216-864-91 SHORT 0
JR8 1-216-864-91 SHORT 0
JR9 1-216-864-91 SHORT 0
JR10 1-216-864-91 SHORT 0
JR11 1-216-864-91 SHORT 0
JR13 1-216-864-91 SHORT 0
JR15 1-216-864-91 SHORT 0
JR18 1-216-864-91 SHORT 0
JR19 1-216-864-91 SHORT 0
JR20 1-216-864-91 SHORT 0
JR21 1-216-864-91 SHORT 0
JR22 1-216-864-91 SHORT 0
JR24 1-216-864-91 SHORT 0
JR25 1-216-864-91 SHORT 0
JR26 1-216-864-91 SHORT 0
JR27 1-216-864-91 SHORT 0
JR28 1-216-864-91 SHORT 0
JR29 1-216-864-91 SHORT 0
JR30 1-216-864-91 SHORT 0
JR35 1-216-864-91 SHORT 0
JR38 1-216-864-91 SHORT 0
JR201 1-216-864-91 SHORT 0
JR301 1-216-864-91 SHORT 0
JR304 1-216-864-91 SHORT 0
JR501 1-216-864-91 SHORT 0
JR801 1-216-864-91 SHORT 0
< COIL >
L201 1-414-189-31 INDUCTOR 100uH
L301 1-410-780-11 INDUCTOR 27MH
L302 1-414-193-41 INDUCTOR 220uH
L303 1-414-193-41 INDUCTOR 220uH
L351 1-410-780-11 INDUCTOR 27MH
< FILTER >
LPF11 1-234-612-11 FILTER, LOW PASS
LPF12 1-234-612-11 FILTER, LOW PASS
< TRANSISTOR >
Q1 8-729-178-63 TRANSISTOR 2SC2786-K
Q2 8-729-422-57 TRANSISTOR UN4111
Q11 8-729-620-05 TRANSISTOR 2SC2603-EF
Q12 8-729-620-05 TRANSISTOR 2SC2603-EF
Q101 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q102 8-729-144-85 TRANSISTOR 2SK1133
Q103 8-729-141-73 TRANSISTOR 2SC3624A-T1L15L16
Q141 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q151 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q152 8-729-144-85 TRANSISTOR 2SK1133
Q153 8-729-141-73 TRANSISTOR 2SC3624A-T1L15L16
Q301 8-729-801-93 TRANSISTOR 2SD1387-3
Q302 8-729-142-46 TRANSISTOR 2SC2001-LK
Q303 8-729-142-46 TRANSISTOR 2SC2001-LK
Q304 8-729-113-69 TRANSISTOR FN1F4M-M32
Q305 8-729-113-13 TRANSISTOR FA1A4M-L33
Q391 8-729-140-04 TRANSISTOR 2SB1116A-L
Q392 8-729-113-13 TRANSISTOR FA1A4M-L33
Q393 8-729-140-04 TRANSISTOR 2SB1116A-L
Q394 8-729-113-13 TRANSISTOR FA1A4M-L33
Q395 8-729-113-13 TRANSISTOR FA1A4M-L33
Q396 8-729-116-57 TRANSISTOR 2SB1068-K
Q397 8-729-113-13 TRANSISTOR FA1A4M-L33
Q503 8-729-113-13 TRANSISTOR FA1A4M-L33
Q504 8-729-113-69 TRANSISTOR FN1F4M-M32
Q505 8-729-113-13 TRANSISTOR FA1A4M-L33
Q575 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q821 8-729-120-28 TRANSISTOR 2SC1623-L5L6
MAIN
