Sony HCD-DX8 - DRIVER SECTION PARTS

54
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
LEAF SW MAIN
< TRANSISTOR >
Q1001 8-729-029-56 TRANSISTOR DTA144ESA-TP
< RESISTOR >
R907 1-247-879-11 CARBON 100K 5% 1/4W
R1001 1-249-409-11 CARBON 220 5% 1/4W
R1002 1-249-409-11 CARBON 220 5% 1/4W
R1003 1-249-414-11 CARBON 560 5% 1/4W
R1004 1-247-834-11 CARBON 1.3K 5% 1/4W
R1005 1-247-818-11 CARBON 300 5% 1/4W
R1006 1-247-864-11 CARBON 24K 5% 1/4W
R1007 1-247-780-00 CARBON 7.5 5% 1/4W
R1008 1-249-417-11 CARBON 1K 5% 1/4W
< VARIABLE RESISTOR >
RV1001 1-241-785-11 RES, ADJ, CARBON 10K
RV1002 1-241-785-11 RES, ADJ, CARBON 10K
< SWITCH >
S1001 1-570-953-11 SWITCH, PUSH (1 KEY) (A PLAY)
S1002 1-570-953-11 SWITCH, PUSH (1 KEY) (B PLAY)
S1003 1-771-333-11 SWITCH, LEAF (A HALF)
S1004 1-771-536-11 SWITCH, LEAF (A 120/70)
S1005 1-771-536-11 SWITCH, LEAF (REC A)
S1006 1-771-333-11 SWITCH, LEAF (B HALF)
S1008 1-771-536-11 SWITCH, LEAF (B 120/70)
S1009 1-771-536-11 SWITCH, LEAF (REC B)
**************************************************************
A-4428-487-A MAIN BOARD, COMPLETE (E3, MY, SP, AUS)
A-4473-085-A MAIN BOARD, COMPLETE (EA)
A-4473-094-A MAIN BOARD, COMPLETE (E2)
A-4473-097-A MAIN BOARD, COMPLETE (MX, AR)
*********************
7-685-646-79 SCREW +BVTP 3X8 TYPE2 N-S
< CAPACITOR/SHORT >
C101 1-163-001-11 CERAMIC CHIP 220PF 10% 50V
C102 1-126-961-11 ELECT 2.2uF 20% 50V
C103 1-126-964-11 ELECT 10uF 20% 50V
C104 1-126-964-11 ELECT 10uF 20% 50V
C105 1-126-964-11 ELECT 10uF 20% 50V
C106 1-136-161-00 MYLAR 0.047uF 5% 50V
C107 1-136-495-11 MYLAR 0.068uF 5% 50V
C108 1-136-495-11 MYLAR 0.068uF 5% 50V
C109 1-163-019-00 CERAMIC CHIP 0.0068uF 10% 50V
C110 1-163-019-00 CERAMIC CHIP 0.0068uF 10% 50V
C111 1-163-018-00 CERAMIC CHIP 0.0056uF 5% 50V
C112 1-126-961-11 ELECT 2.2uF 20% 50V
C113 1-126-957-11 ELECT 0.22uF 20% 50V
C115 1-136-169-00 MYLAR 0.22uF 5% 50V
C116 1-136-169-00 MYLAR 0.22uF 5% 50V
C117 1-126-964-11 ELECT 10uF 20% 50V
C118 1-126-961-11 ELECT 2.2uF 20% 50V
C121 1-126-964-11 ELECT 10uF 20% 50V
C122 1-126-964-11 ELECT 10uF 20% 50V
C123 1-126-964-11 ELECT 10uF 20% 50V
C124 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C125 1-126-964-11 ELECT 10uF 20% 50V
C131 1-136-169-00 MYLAR 0.22uF 5% 50V
C132 1-126-964-11 ELECT 10uF 20% 50V
C133 1-126-925-11 ELECT 470uF 20% 10V
C134 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C135 1-126-964-11 ELECT 10uF 20% 50V
C140 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C142 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C144 1-126-964-11 ELECT 10uF 20% 50V
C146 1-126-925-11 ELECT 470uF 20% 10V
C151 1-163-001-11 CERAMIC CHIP 220PF 10% 50V
C152 1-126-961-11 ELECT 2.2uF 20% 50V
C153 1-126-964-11 ELECT 10uF 20% 50V
C154 1-126-964-11 ELECT 10uF 20% 50V
C155 1-126-964-11 ELECT 10uF 20% 50V
C156 1-136-161-00 MYLAR 0.047uF 5% 50V
C157 1-136-495-11 MYLAR 0.068uF 5% 50V
C158 1-136-495-11 MYLAR 0.068uF 5% 50V
C159 1-163-019-00 CERAMIC CHIP 0.0068uF 10% 50V
C160 1-163-019-00 CERAMIC CHIP 0.0068uF 10% 50V
C161 1-163-018-00 CERAMIC CHIP 0.0056uF 5% 50V
C162 1-126-961-11 ELECT 2.2uF 20% 50V
C165 1-136-169-00 MYLAR 0.22uF 5% 50V
C166 1-136-169-00 MYLAR 0.22uF 5% 50V
C167 1-126-964-11 ELECT 10uF 20% 50V
C171 1-126-964-11 ELECT 10uF 20% 50V
C172 1-126-964-11 ELECT 10uF 20% 50V
C175 1-126-964-11 ELECT 10uF 20% 50V
C199 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C201 1-104-665-11 ELECT 100uF 20% 10V
C202 1-126-925-11 ELECT 470uF 20% 10V
C203 1-163-033-00 CERAMIC CHIP 0.022uF 50V
C204 1-126-961-11 ELECT 2.2uF 20% 50V
C205 1-163-033-00 CERAMIC CHIP 0.022uF 50V
C206 1-126-961-11 ELECT 2.2uF 20% 50V
C207 1-126-916-11 ELECT 1000uF 20% 6.3V
C208 1-163-117-00 CERAMIC CHIP 100PF 5% 50V
C209 1-126-925-11 ELECT 470uF 20% 10V
C212 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C301 1-126-960-11 ELECT 1uF 20% 50V
C302 1-130-479-00 MYLAR 0.0047uF 5% 50V
C303 1-136-165-00 MYLAR 0.1uF 5% 50V
C304 1-136-165-00 MYLAR 0.1uF 5% 50V
C305 1-126-964-11 ELECT 10uF 20% 50V
C306 1-126-960-11 ELECT 1uF 20% 50V
C307 1-126-959-11 ELECT 0.47uF 20% 50V
C308 1-126-964-11 ELECT 10uF 20% 50V
C309 1-137-194-81 MYLAR 0.47uF 5% 50V
C310 1-163-005-11 CERAMIC CHIP 470PF 10% 50V
C311 1-126-964-11 ELECT 10uF 20% 50V
C312 1-126-959-11 ELECT 0.47uF 20% 50V
C313 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C314 1-126-964-11 ELECT 10uF 20% 50V
C315 1-126-963-11 ELECT 4.7uF 20% 50V
C316 1-126-933-11 ELECT 100uF 20% 16V
C317 1-104-665-11 ELECT 100uF 20% 10V
