Sony HCD-DX8 - Page 58

58
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
Q892 8-729-620-05 TRANSISTOR 2SC2603TP-EF
Q911 8-729-141-83 TRANSISTOR 2SB1375
Q912 8-729-113-13 TRANSISTOR FA1A4M-T1L33
< RESISTOR >
R101 1-216-049-11 RES-CHIP 1K 5% 1/10W
R103 1-216-073-00 METAL CHIP 10K 5% 1/10W
R104 1-216-073-00 METAL CHIP 10K 5% 1/10W
R105 1-216-097-00 RES-CHIP 100K 5% 1/10W
R107 1-216-105-00 RES-CHIP 220K 5% 1/10W
R108 1-216-097-00 RES-CHIP 100K 5% 1/10W
R109 1-216-073-00 METAL CHIP 10K 5% 1/10W
R110 1-216-045-00 METAL CHIP 680 5% 1/10W
R111 1-216-073-00 METAL CHIP 10K 5% 1/10W
R112 1-216-089-00 RES-CHIP 47K 5% 1/10W
R113 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R114 1-216-097-00 RES-CHIP 100K 5% 1/10W
R115 1-216-073-00 METAL CHIP 10K 5% 1/10W
R116 1-216-065-00 RES-CHIP 4.7K 5% 1/10W
R121 1-216-224-00 RES-CHIP 12K 5% 1/8W
R122 1-216-073-00 METAL CHIP 10K 5% 1/10W
R123 1-216-073-00 METAL CHIP 10K 5% 1/10W
R124 1-216-065-00 RES-CHIP 4.7K 5% 1/10W
R125 1-216-073-00 METAL CHIP 10K 5% 1/10W
R132 1-216-049-11 RES-CHIP 1K 5% 1/10W
R133 1-216-049-11 RES-CHIP 1K 5% 1/10W
R134 1-216-049-11 RES-CHIP 1K 5% 1/10W
R141 1-216-049-11 RES-CHIP 1K 5% 1/10W
R142 1-216-051-00 METAL CHIP 1.2K 5% 1/10W
R143 1-216-089-00 RES-CHIP 47K 5% 1/10W
R144 1-216-295-00 SHORT 0
R145 1-216-041-00 METAL CHIP 470 5% 1/10W
R146 1-216-041-00 METAL CHIP 470 5% 1/10W
R147 1-216-041-00 METAL CHIP 470 5% 1/10W
R151 1-216-049-11 RES-CHIP 1K 5% 1/10W
R153 1-216-073-00 METAL CHIP 10K 5% 1/10W
R154 1-216-073-00 METAL CHIP 10K 5% 1/10W
R155 1-216-097-00 RES-CHIP 100K 5% 1/10W
R157 1-216-105-00 RES-CHIP 220K 5% 1/10W
R158 1-216-097-00 RES-CHIP 100K 5% 1/10W
R159 1-216-073-00 METAL CHIP 10K 5% 1/10W
R160 1-216-045-00 METAL CHIP 680 5% 1/10W
R161 1-216-222-00 RES-CHIP 10K 5% 1/8W
R162 1-216-089-00 RES-CHIP 47K 5% 1/10W
R163 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R164 1-216-097-00 RES-CHIP 100K 5% 1/10W
R165 1-216-073-00 METAL CHIP 10K 5% 1/10W
R166 1-216-065-00 RES-CHIP 4.7K 5% 1/10W
R171 1-216-075-00 METAL CHIP 12K 5% 1/10W
R172 1-216-073-00 METAL CHIP 10K 5% 1/10W
R173 1-216-073-00 METAL CHIP 10K 5% 1/10W
R175 1-216-073-00 METAL CHIP 10K 5% 1/10W
R201 1-216-025-00 RES-CHIP 100 5% 1/10W
R202 1-216-085-00 METAL CHIP 33K 5% 1/10W
R203 1-216-025-00 RES-CHIP 100 5% 1/10W
R204 1-216-085-00 METAL CHIP 33K 5% 1/10W
R301 1-216-085-00 METAL CHIP 33K 5% 1/10W
R302 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R303 1-216-025-00 RES-CHIP 100 5% 1/10W
R304 1-216-025-00 RES-CHIP 100 5% 1/10W
R305 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R306 1-216-071-00 METAL CHIP 8.2K 5% 1/10W
R307 1-216-065-00 RES-CHIP 4.7K 5% 1/10W
R308 1-216-071-00 METAL CHIP 8.2K 5% 1/10W
R309 1-216-081-00 METAL CHIP 22K 5% 1/10W
R311 1-216-121-00 RES-CHIP 1M 5% 1/10W
R312 1-216-102-00 RES-CHIP 160K 5% 1/10W
R313 1-216-097-00 RES-CHIP 100K 5% 1/10W
R315 1-216-073-00 METAL CHIP 10K 5% 1/10W
R316 1-216-234-00 RES-CHIP 33K 5% 1/8W
R317 1-216-222-00 RES-CHIP 10K 5% 1/8W
R318 1-216-073-00 METAL CHIP 10K 5% 1/10W
R319 1-216-111-00 METAL CHIP 390K 5% 1/10W
R320 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R321 1-216-071-00 METAL CHIP 8.2K 5% 1/10W
R331 1-216-099-00 METAL CHIP 120K 5% 1/10W
R332 1-216-025-00 RES-CHIP 100 5% 1/10W
R333 1-216-067-00 METAL CHIP 5.6K 5% 1/10W
R334 1-216-100-00 RES-CHIP 130K 5% 1/10W
R335 1-216-033-00 METAL CHIP 220 5% 1/10W
R336 1-216-099-00 METAL CHIP 120K 5% 1/10W
R337 1-216-033-00 METAL CHIP 220 5% 1/10W
R338 1-216-081-00 METAL CHIP 22K 5% 1/10W
R339 1-216-075-00 METAL CHIP 12K 5% 1/10W
R340 1-216-107-00 METAL CHIP 270K 5% 1/10W
R341 1-216-033-00 METAL CHIP 220 5% 1/10W
R342 1-216-075-00 METAL CHIP 12K 5% 1/10W
0 R343 1-219-787-17 FUSIBLE 5.6 5% 1/4W F
0 R344 1-219-787-17 FUSIBLE 5.6 5% 1/4W F
R345 1-216-079-00 METAL CHIP 18K 5% 1/10W
R346 1-216-079-00 METAL CHIP 18K 5% 1/10W
R347 1-216-073-00 METAL CHIP 10K 5% 1/10W
R351 1-216-085-00 METAL CHIP 33K 5% 1/10W
R352 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R353 1-216-025-00 RES-CHIP 100 5% 1/10W
R354 1-216-025-00 RES-CHIP 100 5% 1/10W
R355 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R356 1-216-071-00 METAL CHIP 8.2K 5% 1/10W
R357 1-216-065-00 RES-CHIP 4.7K 5% 1/10W
R358 1-216-071-00 METAL CHIP 8.2K 5% 1/10W
R359 1-216-085-00 METAL CHIP 33K 5% 1/10W
R360 1-216-045-00 METAL CHIP 680 5% 1/10W
R361 1-216-049-11 RES-CHIP 1K 5% 1/10W
R363 1-216-049-11 RES-CHIP 1K 5% 1/10W
R364 1-216-045-00 METAL CHIP 680 5% 1/10W
R366 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R367 1-216-089-00 RES-CHIP 47K 5% 1/10W
R368 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R369 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R371 1-216-238-91 RES-CHIP 47K 5% 1/8W
R372 1-216-065-00 RES-CHIP 4.7K 5% 1/10W
R373 1-216-049-11 RES-CHIP 1K 5% 1/10W
R374 1-216-089-00 RES-CHIP 47K 5% 1/10W
R375 1-216-094-00 RES-CHIP 75K 5% 1/10W
R376 1-216-065-00 RES-CHIP 4.7K 5% 1/10W
The components identified by mark 0 or dotted
line with mark 0 are critical for safety.
Replace only with part number specified.
MAIN
