Sony HCD-DZ100K - Page 54

54
HCD-DZ100K/DZ500KF
IC201 MM1623BFBE
– I/O Board –
1V CC1
2C IN
3MUTE1
4CVBS IN
5YC mix.
6Y IN
7GND1
8BIAS
9I/P
10CY IN
11CLP
12Cb IN
13
MUTE2
14Cr IN
28 V CC 2
27 S-DC OUT
26
C
OUT
25 S1
24 S2
23
CVBS
OUT
22 GND2
21 Y OUT
20
CY
OUT
19 GND2
18 Cb OUT
17 GND2
16 Cr OUT
15 GND
6dB
6dB
6dB
–
6dB
6dB
6dB
6dB
6dB
150Ω
Bias
150kΩ
Bias
150kΩ
Bias
150kΩ
Bias
Clamp
Clamp
S-DC out
S1/S2
200Ω
LPF
6.75MHz
LPF
6.75MHz
LPF
6.75MHz
LPF
13.5MHz
LPF
6.75MHz
LPF
13.5MHz
LPF
6.75MHz
LPF
13.5MHz
LPF
6.75MHz
Bias
Clamp
75Ω
Driver
75Ω
Driver
75Ω
Driver
75Ω
Driver
75Ω
Driver
75Ω
Driver
