HCD-DZ100K/DZ500KF
SECTION 2
GENERAL
This section is extracted
from instruction manual.
For more information, refer to the pages indicated in parentheses.
Front panel
A "/1 (on/standby)
B Disc tray
C A (open/close)
D H (play)
E X (pause)
F x (stop)
G ./>
H FUNCTION
I MIC jack
J VOLUME
K (remote sensor)
L Front panel display
M AUDIO IN jack
Index to Parts and Controls
Rear panel
A SPEAKER jacks
B VIDEO VIDEO/AUDIO IN jacks
C COMPONENT VIDEO OUT jacks
D MONITOR OUT (VIDEO / S VIDEO) jacks
E AM terminal
F FM 75 COAXIAL jack
SPEAKER
COAXIAL
FM75
Y
P
B
/C
B
P
R
/C
R
AM
S VIDEO
AUDIO IN VIDEO IN
RL
VIDEO
(DVD ONLY)
DVD ONLY
MONITOR OUT
COMPONENT VIDEO OUT
VIDEO
FRONT R FRONT L SURR R SURR L CENTER WOOFER
