8
HCD-DZ100K/DZ500KF
SECTION 3
DISASSEMBLY
3-1. DISASSEMBLY FLOW
• This set can be disassembled in the order shown below.
• The dotted square with arrow ( ) prompts you to move to the next job when all of the works within the dotted square ( ) are
completed.
3-3.FL BOARD, H/P BOARD
(Page 10)
3-4.KEY BOARD, STBY BOARD
(Page 10)
3-8.DVD MECHANISM DECK
(CDM85-DVBU102)
(Page 13)
3-9.TRAY
(Page 13)
3-10.BELT, MS-203 BOARD
(Page 14)
3-11.BASE UNIT (DVBU102)
(Page 15)
3-12.OPTICAL PICK-UP
(KHM-310CAA/C2NP)
(Page 15)
3-5.I/O BOARD, DC FAN
(Page 11)
3-7.MAIN BOARD
(Page 12)
3-6.DMB10 BOARD
(Page 11)
3-2.CASE, FRONT PANEL ASSY
(Page 9)
SET
