9
HCD-DZ100K/DZ500KF
3-2. CASE, FRONT PANEL ASSY
Note: Follow the disassembly procedure in the numerical order given.
DVD lid
1
The lever is moved in the direction
of the arrow with the thin rod.
2
3
DVD lid assy
4
screw (CASE3 TP2)
5
screw
(CASE3 TP2)
6
five screws (+BV 3)
7
case
qj
front panel assy
9
three screws (+BV 3)
8
w
ire (flat type)
19p(CN509)
qa
claw
qs
q;
claw
qh
MIC board
qg
t
apping screw
(DIA.2.6
×
8)
qd
froating screw
(PTPWHM 2.6)
qf
IPOD board
