HCD-DZ100K/DZ500KF
Pin No. Pin Name I/O Description
46 CE/STBY_LED O Flash Write CE (not used)
47 DRIVE_RST(EN) O Driver signal reset
48 DRIVE_OCP(DIAG) I Digital amp (power driver) diag
49 OVERFLOW1 I Over flow status1 of digital amp (IC110)
50 OVERFLOW2 I Over flow status2 of digital amp (IC108 to 110)
51 DAMP LATCH1 O Digital amp (IC108) chip select1 signal output
52 DAMP LATCH2 O Digital amp (IC109) chip select2 signal output
53 DAMP LATCH3 O Digital amp (IC110) chip select3 signal output
54 DAMP INIT O Digital amp (IC108 to 110) reset signal output
55 DAMP SOFT MUTE O Digital amp (IC108 to 110) soft muting output
56 HP SW I Switch headphone is insert
57 HP MUTE O Control of muting headphone signal
58 DSP_ACK I DSP acknowledge (not used)
59 DSP_GP9 I DSP GP9 in (not used)
60 DSP_XRST O DSP reset (not used)
61 DSP_HCE O DSP chip enable (not used)
62 VCC — Power supply (+3.3V)
63 DSP_BST O DSP bootstrap (for DSP INIT) (not used)
64 VSS — Ground terminal
65 DSP_PM O DSP PLL initial (not used)
66 DIR RST O DIR reset out (not used)
67 DIR HCE O DIR chip enable signal output (not used)
68 DIR RERR I DIR error input (not used)
69 DIR XSTATE I DIR change clock status (not used)
70 DIR HDOUT I DIR Data input (not used)
71 DSP_SKIP O DSP GP12 (not used)
72 AD_RST O ADC reset (not used)
73 MODE0 O Not used
74 KEY INT I Wakeup from ECO mode by key input
75 RDS-CLK/MIC-CLK O MIC volume IC (IC607) control clock output
76 RDS-DATA/MIC-DATA O MIC volume IC (IC607) control data output
77 PLL-CLK O Tuner clock
78 PLL-DO I Tuner data input (uCOM←pack)
79 PLL-CE O Tuner chip enable
80 PLL-DI O Tuner data output (pack←uCOM)
81 AV SELECT 0 O Audio/Video select0
82 AV SELECT 1 O Audio/Video select1
83 AV SELECT 2 O Audio/Video select2
84 AV SELECT 3 O Audio/Video select3 (not used)
85 TUNED I Tuner pack tuned input
86 IO_CE O I/O expander chip enable / control of loading CD tray (open action)
87 IO_RESET O I/O expander reset / control of loading CD tray (close action)
88 IO_DI O I/O expander data out / SW2 of CDM
89 IO_DO I I/O expander data in / SW3 of CDM
90 IO_CLK O I/O expander clock
91 IPOD/MIC SW O Audio attenuate control output
92 DESTINATION I Destination select
