78
HCD-DZ100K/DZ500KF
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
MAIN
0IC901 6-707-742-11 IC STR-F6168-LF1352
0IC921 6-707-740-01 IC STR-V153
IC931 8-759-648-34 IC TA76431AS (TPE6)
IC941 6-707-746-01 IC SI-3120KM-TL
IC942 6-707-745-10 IC SI-3050KM-TL
IC943 6-707-744-01 IC SI-3033KM-TL
IC951 6-707-743-01 IC TA76L431S (TPE6, Q)
< JACK >
J201 1-780-202-11 TERMINAL BOARD (SP) (4P) (SPEAKER)
J202 1-780-203-11 TERMINAL BOARD (SP) (2P) (WOOFER, CENTER)
< COIL >
L101 1-457-078-11 AIR-CORE COIL
L102 1-457-078-11 AIR-CORE COIL
L103 1-457-078-11 AIR-CORE COIL
L104 1-457-078-11 AIR-CORE COIL
L105 1-457-078-11 AIR-CORE COIL
L106 1-457-078-11 AIR-CORE COIL
L107 1-414-398-11 INDUCTOR 10uH
L111 1-457-077-11 AIR-CORE COIL
L112 1-457-077-11 AIR-CORE COIL
L113 1-457-077-11 AIR-CORE COIL
L114 1-457-077-11 AIR-CORE COIL
L115 1-457-077-11 AIR-CORE COIL
L116 1-457-077-11 AIR-CORE COIL
L121 1-456-680-11 INDUCTOR 10uH
L122 1-456-680-11 INDUCTOR 10uH
L123 1-456-680-11 INDUCTOR 10uH
L124 1-456-680-11 INDUCTOR 10uH
L125 1-456-680-11 INDUCTOR 10uH
L126 1-456-680-11 INDUCTOR 10uH
L127 1-456-680-11 INDUCTOR 10uH (DZ500KF)
L131 1-456-680-11 INDUCTOR 10uH
L132 1-456-680-11 INDUCTOR 10uH
L133 1-456-680-11 INDUCTOR 10uH
L134 1-456-680-11 INDUCTOR 10uH
L135 1-456-680-11 INDUCTOR 10uH
L136 1-456-680-11 INDUCTOR 10uH
L137 1-456-680-11 INDUCTOR 10uH (DZ500KF)
L301 1-414-754-11 INDUCTOR 10uH
L302 1-412-939-11 INDUCTOR 1uH
L303 1-216-295-91 SHORT CHIP 0
L501 1-414-754-11 INDUCTOR 10uH
L502 1-414-754-11 INDUCTOR 10uH
L503 1-216-295-91 SHORT CHIP 0
L504 1-216-295-91 SHORT CHIP 0
L931 1-457-058-11 INDUCTOR 10.8uH
L941 1-414-398-11 INDUCTOR 10uH
L942 1-414-398-11 INDUCTOR 10uH
L945 1-414-398-11 INDUCTOR 10uH
L947 1-414-398-11 INDUCTOR 10uH
L948 1-414-398-11 INDUCTOR 10uH
L951 1-414-398-11 INDUCTOR 10uH
< LINE FILTER >
0 LF901 1-457-079-11 LINE FILTER COIL
< IC >
0 PC901 6-600-438-01 IC TLP421F (D4-GR)
0 PC902 6-600-438-01 IC TLP421F (D4-GR)
0 PC903 6-600-438-01 IC TLP421F (D4-GR)
< TRANSISTOR >
Q101 8-729-600-22 TRANSISTOR 2SA1235-F
Q102 8-729-600-22 TRANSISTOR 2SA1235-F
Q103 8-729-600-22 TRANSISTOR 2SA1235-F
Q104 8-729-600-22 TRANSISTOR 2SA1235-F
Q105 8-729-600-22 TRANSISTOR 2SA1235-F
Q106 8-729-600-22 TRANSISTOR 2SA1235-F
Q107 8-729-600-22 TRANSISTOR 2SA1235-F
Q108 8-729-600-22 TRANSISTOR 2SA1235-F
Q109 8-729-600-22 TRANSISTOR 2SA1235-F
Q110 8-729-600-22 TRANSISTOR 2SA1235-F
Q111 8-729-600-22 TRANSISTOR 2SA1235-F
Q112 8-729-600-22 TRANSISTOR 2SA1235-F
Q301 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q302 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q303 6-550-702-01 TRANSISTOR 2SC3243-TP-E
Q304 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q506 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q507 8-729-027-23 TRANSISTOR DTA114EKA-T146
0 Q901 8-729-140-04 TRANSISTOR 2SB1116A-L
0 Q921 8-729-142-51 TRANSISTOR 2SD1616A-TP-LK
Q943 1-801-806-11 TR DTC144EKA
Q945 6-550-718-01 TRANSISTOR RSR025N03TL
Q947 1-801-806-11 TR DTC144EKA
< RESISTOR >
R108 1-216-837-11 METAL CHIP 22K 5% 1/10W
R109 1-216-837-11 METAL CHIP 22K 5% 1/10W
R110 1-216-837-11 METAL CHIP 22K 5% 1/10W
R111 1-216-837-11 METAL CHIP 22K 5% 1/10W
R112 1-216-837-11 METAL CHIP 22K 5% 1/10W
R113 1-216-837-11 METAL CHIP 22K 5% 1/10W
R114 1-216-837-11 METAL CHIP 22K 5% 1/10W
R115 1-216-837-11 METAL CHIP 22K 5% 1/10W
R116 1-216-837-11 METAL CHIP 22K 5% 1/10W
R117 1-216-837-11 METAL CHIP 22K 5% 1/10W
R118 1-216-837-11 METAL CHIP 22K 5% 1/10W
R119 1-216-837-11 METAL CHIP 22K 5% 1/10W
R120 1-216-837-11 METAL CHIP 22K 5% 1/10W
(DZ500KF)
R128 1-216-837-11 METAL CHIP 22K 5% 1/10W
(DZ500KF)
R131 1-216-864-11 SHORT CHIP 0
R132 1-216-864-11 SHORT CHIP 0
R133 1-216-864-11 SHORT CHIP 0
R134 1-216-864-11 SHORT CHIP 0
R135 1-216-864-11 SHORT CHIP 0
R136 1-216-864-11 SHORT CHIP 0
R137 1-216-864-11 SHORT CHIP 0 (DZ500KF)
