Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HCD-DZ280/DZ680/HDZ284/HDZ485
8383
R5062 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
(EXCEPT DZ280:AEP)
R5067 1-216-835-11 METAL CHIP 15K 5% 1/10W
(EXCEPT DZ280:AEP)
R5083 1-216-813-11 METAL CHIP 220 5% 1/10W
R5084 1-216-813-11 METAL CHIP 220 5% 1/10W
R5085 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R5086 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R5087 1-216-837-11 METAL CHIP 22K 5% 1/10W
R5088 1-216-841-11 METAL CHIP 47K 5% 1/10W
R5089 1-216-864-11 SHORT CHIP 0
< SWITCH >
S5000 1-762-875-21 SWITCH, KEYBOARD (i-ENHANCER)
< TRANSFORMER >
T5000 1-443-645-11 TRANSFORMER, DC CONVERTER
*************************************************************
A-1579-734-A IO-COMPONENT BOARD, COMPLETE (HDZ284)
A-1602-595-A IO-COMPONENT BOARD, COMPLETE (HDZ485)
******************************
< CAPACITOR >
C4028 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C4030 1-126-933-11 ELECT 100uF 20% 16V
C4031 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C4033 1-126-933-11 ELECT 100uF 20% 16V
C4034 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C4036 1-126-916-11 ELECT 1000uF 20% 6.3V
C4037 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C4038 1-126-965-11 ELECT 22uF 20% 50V
(HDZ284)
C4039 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C4040 1-126-916-11 ELECT 1000uF 20% 6.3V
C4041 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C4042 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C4043 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C4044 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C4045 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C4046 1-126-925-11 ELECT 470uF 20% 10V
C4047 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C4048 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C4049 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C4050 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C4053 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C4054 1-104-662-11 ELECT 22uF 20% 25V
C4055 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C4056 1-126-964-11 ELECT 10uF 20% 50V
(HDZ485)
C4057 1-104-662-11 ELECT 22uF 20% 25V
C4059 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
(HDZ485)
C4070 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C4077 1-104-662-11 ELECT 22uF 20% 25V
C4078 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C4083 1-104-662-11 ELECT 22uF 20% 25V
C4087 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C4088 1-104-662-11 ELECT 22uF 20% 25V
C4089 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C4090 1-104-662-11 ELECT 22uF 20% 25V
C4093 1-126-933-11 ELECT 100uF 20% 16V
C4094 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C4100 1-127-573-11 CERAMIC CHIP 1uF 10% 16V
C4101 1-126-947-11 ELECT 47uF 20% 35V
C4104 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C4109 1-104-662-11 ELECT 22uF 20% 25V
C4110 1-104-662-11 ELECT 22uF 20% 25V
C4113 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C4116 1-126-933-11 ELECT 100uF 20% 16V
C4123 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
(HDZ485)
< CONNECTOR >
CN4003 1-779-285-11 CONNECTOR, FFC (LIF(NON-ZIF)) 17P
CN4006 1-779-285-11 CONNECTOR, FFC (LIF(NON-ZIF)) 17P
CN4012 1-779-273-11 CONNECTOR, FFC (LIF(NON-ZIF)) 5P
CN4014 1-564-706-11 PIN, CONNECTOR (SMALL TYPE) 4P
CN4016 1-784-770-11 CONNECTOR, FFC 9P
< DIODE >
D4003 6-500-848-01 DIODE MC2840-T112-1
D4004 6-501-728-01 DIODE MAZ8051G0LS0 (HDZ485)
D4006 6-501-817-01 DIODE MA2J1110GLS0
< IC >
IC4002 6-710-470-01 IC MM1758AFBE
IC4003 6-705-337-01 IC
TK11150CSCL-G
IC4004 8-759-385-76 IC MC14052 BDR2 (HDZ485)
IC4007 8-759-385-76 IC MC14052 BDR2
IC4009 6-713-032-01 IC KIA7809API-U/PF
< JACK >
J4000 1-822-283-11 JACK, PIN 3P (COMPONENT VIDEO OUT)
J4001 1-822-280-11 JACK, PIN 3P (VIDEO OUT,
TV/VIDEO (AUDIO IN))
< JUMPER RESISTOR >
JR4001 1-216-864-11 SHORT CHIP 0
JR4002 1-216-864-11 SHORT CHIP 0
JR4003 1-216-864-11 SHORT CHIP 0
JR4004 1-216-864-11 SHORT CHIP 0
JR4006 1-216-864-11 SHORT CHIP 0
JR4007 1-216-864-11 SHORT CHIP 0
JR4502 1-216-864-11 SHORT CHIP 0
JR4503 1-216-864-11 SHORT CHIP 0
JR4504 1-216-864-11 SHORT CHIP 0
JR4505 1-216-864-11 SHORT CHIP 0
JR4506 1-216-864-11 SHORT CHIP 0
JR4507 1-216-864-11 SHORT CHIP 0
JR4508 1-216-864-11 SHORT CHIP 0
JR4515 1-216-864-11 SHORT CHIP 0
JR4516 1-216-864-11 SHORT CHIP 0
< COIL >
L4000 1-469-525-91 INDUCTOR 10uH
< TRANSISTOR >
Q4007 8-729-027-52 TRANSISTOR DTC124EKA-T146 (HDZ485)
Q4008 8-729-027-52 TRANSISTOR DTC124EKA-T146 (HDZ485)
Q4011 8-729-027-52 TRANSISTOR DTC124EKA-T146
Q4012 8-729-027-52 TRANSISTOR DTC124EKA-T146
IO-COMPONENTFL-JACK
