Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HCD-DZ280/DZ680/HDZ284/HDZ485
84
< RESISTOR >
R4032 1-218-285-11 METAL CHIP 75 5% 1/10W
R4034 1-218-285-11 METAL CHIP 75 5% 1/10W
R4035 1-218-827-11 METAL CHIP 150 0.5% 1/10W
R4036 1-218-827-11 METAL CHIP 150 0.5% 1/10W
R4037 1-218-827-11 METAL CHIP 150 0.5% 1/10W
R4038 1-218-827-11 METAL CHIP 150 0.5% 1/10W
R4039 1-218-827-11 METAL CHIP 150 0.5% 1/10W
R4041 1-218-285-11 METAL CHIP 75 5% 1/10W
R4043 1-218-285-11 METAL CHIP 75 5% 1/10W
R4044 1-218-285-11 METAL CHIP 75 5% 1/10W
R4045 1-216-821-11 METAL CHIP 1K 5% 1/10W
R4048 1-216-845-11 METAL CHIP 100K 5% 1/10W
R4049 1-216-841-11 METAL CHIP 47K 5% 1/10W
R4050 1-216-841-11 METAL CHIP 47K 5% 1/10W
R4051 1-216-837-11 METAL CHIP 22K 5% 1/10W
R4052 1-216-845-11 METAL CHIP 100K 5% 1/10W
R4053 1-216-837-11 METAL CHIP 22K 5% 1/10W
R4054 1-216-841-11 METAL CHIP 47K 5% 1/10W
R4055 1-216-841-11 METAL CHIP 47K 5% 1/10W
0 R4056 1-215-865-11 METAL OXIDE 220 5% 1W F
(HDZ485)
R4058 1-216-833-11 METAL CHIP 10K 5% 1/10W
(HDZ485)
R4059 1-216-864-11 SHORT CHIP 0
R4060 1-216-864-11 SHORT CHIP 0
R4061 1-216-821-11 METAL CHIP 1K 5% 1/10W
(HDZ485)
R4070 1-216-821-11 METAL CHIP 1K 5% 1/10W
(HDZ485)
R4071 1-216-864-11 SHORT CHIP 0
R4072 1-216-864-11 SHORT CHIP 0
R4073 1-216-864-11 SHORT CHIP 0
R4074 1-216-864-11 SHORT CHIP 0
R4075 1-216-864-11 SHORT CHIP 0
R4076 1-216-864-11 SHORT CHIP 0
R4077 1-216-864-11 SHORT CHIP 0
R4082 1-216-864-11 SHORT CHIP 0
R4085 1-216-841-11 METAL CHIP 47K 5% 1/10W
R4086 1-216-841-11 METAL CHIP 47K 5% 1/10W
R4089 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R4093 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R4094 1-216-841-11 METAL CHIP 47K 5% 1/10W
R4095 1-216-841-11 METAL CHIP 47K 5% 1/10W
R4103 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R4104 1-216-841-11 METAL CHIP 47K 5% 1/10W
R4105 1-216-841-11 METAL CHIP 47K 5% 1/10W
R4108 1-216-864-11 SHORT CHIP 0
R4110 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R4111 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R4112 1-216-864-11 SHORT CHIP 0
R4114 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R4115 1-216-841-11 METAL CHIP 47K 5% 1/10W
R4116 1-216-841-11 METAL CHIP 47K 5% 1/10W
R4124 1-216-833-11 METAL CHIP 10K 5% 1/10W
R4125 1-216-864-11 SHORT CHIP 0
R4128 1-216-821-11 METAL CHIP 1K 5% 1/10W
R4131 1-216-833-11 METAL CHIP 10K 5% 1/10W
R4133 1-216-821-11 METAL CHIP 1K 5% 1/10W
R4144 1-216-833-11 METAL CHIP 10K 5% 1/10W
R4145 1-216-833-11 METAL CHIP 10K 5% 1/10W
R4146 1-216-845-11 METAL CHIP 100K 5% 1/10W
R4147 1-216-845-11 METAL CHIP 100K 5% 1/10W
R4148 1-216-864-11 SHORT CHIP 0
R4149 1-216-845-11 METAL CHIP 100K 5% 1/10W
R4150 1-216-845-11 METAL CHIP 100K 5% 1/10W
R4156 1-216-864-11 SHORT CHIP 0
R4157 1-216-864-11 SHORT CHIP 0
R4164 1-216-833-11 METAL CHIP 10K 5% 1/10W
(HDZ485)
R4166 1-216-864-11 SHORT CHIP 0
*************************************************************
A-1579-687-A IO-SCART BOARD, COMPLETE (DZ280)
A-1579-794-A IO-SCART BOARD, COMPLETE (DZ680)
************************
< CAPACITOR >
C4001 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C4002 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C4003 1-126-933-11 ELECT 100uF 20% 16V
C4004 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C4005 1-126-933-11 ELECT 100uF 20% 16V
C4006 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C4007 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C4008 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C4009 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C4010 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C4011 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C4012 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C4013 1-126-933-11 ELECT 100uF 20% 16V
C4014 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C4015 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C4016 1-126-933-11 ELECT 100uF 20% 16V
C4017 1-126-965-11 ELECT 22uF 20% 50V
(DZ280)
C4018 1-126-916-11 ELECT 1000uF 20% 6.3V
C4019 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C4020 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C4021 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C4022 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C4023 1-126-933-11 ELECT 100uF 20% 16V
C4024 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C4025 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C4026 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C4027 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C4053 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C4054 1-104-662-11 ELECT 22uF 20% 25V
C4055 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C4056 1-126-964-11 ELECT 10uF 20% 50V
(DZ680)
C4057 1-104-662-11 ELECT 22uF 20% 25V
C4059 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
(DZ680)
C4070 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C4077 1-104-662-11 ELECT 22uF 20% 25V
C4078 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C4083 1-104-662-11 ELECT 22uF 20% 25V
C4087 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C4088 1-104-662-11 ELECT 22uF 20% 25V
C4089 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C4090 1-104-662-11 ELECT 22uF 20% 25V
IO-COMPONENT IO-SCART
