Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HCD-DZ280/DZ680/HDZ284/HDZ485
9191
D4502 6-501-696-01 DIODE RSA39LTE25 (HDZ485)
D9712 6-501-817-01 DIODE MA2J1110GLS0
< FERRITE BEAD >
FB1106 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB1107 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB1108 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB1109 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB1111 1-469-670-21 FERRITE, EMI (SMD) (2012)
FB1112 1-469-670-21 FERRITE, EMI (SMD) (2012)
FB1113 1-469-670-21 FERRITE, EMI (SMD) (2012)
FB1115 1-469-670-21 FERRITE, EMI (SMD) (2012)
FB1116 1-469-670-21 FERRITE, EMI (SMD) (2012)
FB1117 1-469-670-21 FERRITE, EMI (SMD) (2012)
FB1118 1-469-670-21 FERRITE, EMI (SMD) (2012)
FB2101 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB2102 1-469-379-11 FERRITE, EMI (SMD) (2012) (DZ280/DZ680)
FB2103 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB2104 1-469-379-11 FERRITE, EMI (SMD) (2012) (DZ280/DZ680)
FB2105 1-469-379-11 FERRITE, EMI (SMD) (2012) (DZ280/DZ680)
FB2120 1-469-118-21 FERRITE, EMI (SMD) (1608)
FB2121 1-469-118-21 FERRITE, EMI (SMD) (1608)
FB2122 1-469-118-21 FERRITE, EMI (SMD) (1608)
FB2124 1-469-118-21 FERRITE, EMI (SMD) (1608)
FB2125 1-469-118-21 FERRITE, EMI (SMD) (1608)
FB3107 1-469-118-21 FERRITE, EMI (SMD) (1608)
FB3108 1-469-118-21 FERRITE, EMI (SMD) (1608)
FB3109 1-469-118-21 FERRITE, EMI (SMD) (1608)
< IC >
IC303 6-710-554-01 IC PCM1808PWR
IC304 8-759-825-15
IC LC89056W-E (EXCEPT DZ280)
IC307 8-759-680-48 IC TC7WH157FK(TE85R)
IC451 8-759-710-97 IC NJM4565M-D
IC452 6-712-613-01 IC SI-3010KM-TLS
IC471 6-707-853-01 IC TC74LCX541FT(EKJ)
IC501 6-706-492-01 IC TC7SHU04FU(T5RSOJF) (EXCEPT DZ280)
IC502 6-600-466-01 IC TORX147L(SONY)
(TV/VIDEO (DIGITAL IN OPTICAL))
(EXCEPT DZ280)
IC503 A-1602-136-A IC R5F3640DDFAR (for SERVICE)
IC504 6-705-338-01 IC TK11250CMCL-G
IC505 6-713-500-01 IC BR24S16F-WE2
IC506 6-705-203-01 IC S-80935CNMC-G85T2G
IC507 6-712-613-01 IC SI-3010KM-TLS
IC509 6-712-613-01 IC SI-3010KM-TLS (DZ280/DZ680)
IC510 6-712-613-01 IC SI-3010KM-TLS
IC1101 6-713-716-01 IC CXD9917R-A (DZ280:AEP/DZ680)
IC1101 6-713-717-01 IC CXD9927R-A (DZ280:UK/HDZ284/HDZ485)
IC1102 6-808-752-01 IC MX29LV320DBTI-70-OHI-0906UC
(HDZ284/HDZ485)
IC1102 6-808-753-01 IC MX29LV320DBTI-70-OHI-0906CE
(DZ280/DZ680)
IC1103 (Not supplied) IC BR24S64F-WE2
IC1104 6-711-090-01 IC K4S641632K-UC60T
IC1105 6-702-302-01 IC TK11133CSCL-G
IC1107 6-702-302-01 IC TK11133CSCL-G
IC1110 6-707-739-01 IC MM1661JTRE
IC1201 6-704-524-01 IC FAN8036L
IC1705 8-759-592-47 IC TC7SZ08FU(TE85R)
IC1707 6-705-337-01 IC TK11150CSCL-G
IC1708 6-702-302-01 IC TK11133CSCL-G
IC2101 8-759-700-07 IC NJM2903M (DZ280/DZ680)
IC3001 8-759-710-97 IC NJM4565M-D
IC3010 6-705-979-01 IC CXD9788AR
IC3020 6-705-979-01 IC CXD9788AR
IC3030 6-705-979-01 IC CXD9788AR
IC3050 6-702-300-01 IC TK11118CSCL-G
IC3051 6-709-888-01 IC TC7WHU04FK(T5RSOYF
IC3100 6-712-370-01 IC CXD9936TN
IC3150 6-712-370-01 IC CXD9936TN
IC3200 6-712-370-01 IC CXD9936TN
IC3250 6-712-370-01 IC CXD9936TN
IC3300 6-712-370-01 IC CXD9936TN
IC3400 6-712-370-01 IC CXD9936TN
IC3500 6-712-370-01 IC CXD9936TN (HDZ485)
< JACK >
J501 1-822-282-11 JACK, PIN 1P (TV/VIDEO (DIGITAL IN COAXIAL))
(EXCEPT DZ280)
< COIL >
L301 1-469-525-91 INDUCTOR 10uH (EXCEPT DZ280)
L302 1-469-525-91 INDUCTOR 10uH
L303 1-469-525-91 INDUCTOR 10uH (EXCEPT DZ280)
L451 1-469-525-91 INDUCTOR 10uH
L471 1-469-527-91 INDUCTOR 47uH
L501 1-469-525-91 INDUCTOR 10uH (EXCEPT DZ280)
L502 1-469-525-91 INDUCTOR 10uH (EXCEPT DZ280)
L1701 1-457-374-21 COIL, COMMON MODE CHOKE
L1702 1-457-374-21 COIL, COMMON MODE CHOKE
L1703 1-457-374-21 COIL, COMMON MODE CHOKE
L1704 1-457-374-21 COIL, COMMON MODE CHOKE
L2101 1-457-374-21 COIL, COMMON MODE CHOKE (DZ280/DZ680)
L3000 1-469-527-91 INDUCTOR 47uH
L3051 1-469-525-91 INDUCTOR 10uH
L3052 1-469-525-91 INDUCTOR 10uH
L3053 1-469-525-91 INDUCTOR 10uH
L3054 1-412-939-11 INDUCTOR 1uH
L3101 1-457-579-21 COIL, CHOKE 10uH
L3102 1-457-579-21 COIL, CHOKE 10uH
L3201 1-457-579-21 COIL, CHOKE 10uH
L3202 1-457-579-21 COIL, CHOKE 10uH
L3301 1-457-579-21 COIL, CHOKE 10uH
L3401 1-457-579-21 COIL, CHOKE 10uH
L3501 1-457-579-21 COIL, CHOKE 10uH (HDZ485)
L3901 1-457-078-11 COIL, AIR-CORE
L3902 1-457-077-11 COIL, AIR-CORE
L3903 1-457-078-11 COIL, AIR-CORE
L3904 1-457-077-11 COIL, AIR-CORE
< TRANSISTOR >
Q501 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q502 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q503 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q1101 6-550-008-01 FET UM6K1N-TN
Q1102 6-550-653-01 TRANSISTOR QST8TR
Q1103 8-729-027-52 TRANSISTOR DTC124EKA-T146
Q1701 6-550-008-01 FET UM6K1N-TN
Q3000 8-729-111-29 TRANSISTOR 2SD1616A-K
Q3001 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
MAIN
When IC1103 on the Main board is damaged, exchange
the new Main board for the Main board which IC damaged.
Ver. 1.1
