Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HCD-DZ280/DZ680/HDZ284/HDZ485
9797
< NETWORK RESISTOR >
RB1103 1-234-944-21 RES, NETWORK 47X4 (1005)
RB1104 1-234-944-21 RES, NETWORK 47X4 (1005)
RB1105 1-234-944-21 RES, NETWORK 47X4 (1005)
RB1106 1-234-944-21 RES, NETWORK 47X4 (1005)
RB1109 1-234-944-21 RES, NETWORK 47X4 (1005)
RB1110 1-234-944-21 RES, NETWORK 47X4 (1005)
RB1111 1-234-944-21 RES, NETWORK 47X4 (1005)
RB1112 1-234-400-21 CONDUCTOR, NETWORK 0X4 (1005)
RB1113 1-234-400-21 CONDUCTOR, NETWORK 0X4 (1005)
RB1114 1-234-943-21 RES, NETWORK 22X4 (1005)
RB1115 1-234-943-21 RES, NETWORK 22X4 (1005)
< TERMINAL BOARD >
TB3901 1-780-453-11 TERMINAL BOARD (SPEAKER) 2P
(SPEAKER (CENTER,SUBWOOFER))
< VIBRATOR >
X301 1-814-106-21 VIBRATOR, CRYSTAL (24.576MHz)
(EXCEPT DZ280)
X501 1-795-058-21 VIBRATOR, CERAMIC (5MHz)
X1101 1-814-103-21 VIBRATOR, CRYSTAL (27MHz)
X3051 1-814-108-21 VIBRATOR, CRYSTAL (49.58MHz)
*************************************************************
MS-203 BOARD
************
< CONNECTOR >
CN001 1-815-412-11 CONNECTOR, FFC/FPC 5P
< SWITCH >
S001 1-786-693-11 SWITCH, DETECTION (CHUCK/TRAY DETECT)
*************************************************************
P-SW BOARD
***********
< CAPACITOR >
C5400 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
< SWITCH >
S5400 1-762-875-21 SWITCH, KEYBOARD (|/1)
*************************************************************
A-1568-846-A POWER BOARD, COMPLETE (DZ680)
A-1568-850-A POWER BOARD, COMPLETE (HDZ485:CND)
A-1568-854-A POWER BOARD, COMPLETE (HDZ485:PX)
A-1650-274-A POWER BOARD, COMPLETE (DZ280)
A-1650-278-A POWER BOARD, COMPLETE (HDZ284)
***********************
1-533-217-41 HOLDER, FUSE
7-685-646-79 SCREW +BVTP 3X8 TYPE2 IT-3
7-685-647-79 SCREW +BVTP 3X10 TYPE2 IT-3
< CAPACITOR >
0 C901 1-165-529-11 MYLAR 0.22uF 10% 275V
0 C902 1-165-529-11 MYLAR 0.22uF 10% 275V
0 C903 1-112-330-11 ELECT(BLOCK) 1000uF 20% 200V
(HDZ485:CND)
0 C903 1-114-345-11 ELECT(BLOCK) 1000uF 20% 200V
(HDZ284)
0 C903 1-114-346-11 ELECT(BLOCK) 330uF 20% 630V
(DZ280/DZ680)
0 C903 1-114-347-11 ELECT(BLOCK) 330uF 20% 450V
(HDZ485:PX)
0 C905 1-136-557-11 FILM 0.0033uF 5% 630V
(EXCEPT CND)
0 C905 1-136-601-11 FILM 0.01uF 5% 630V
(CND)
0 C906 1-117-815-11 FILM 0.001uF 3% 1.5KV
(EXCEPT CND)
C907 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
(EXCEPT CND)
C907 1-162-965-11 CERAMIC CHIP 0.0015uF 10% 50V
(CND)
C908 1-107-909-11 ELECT 47uF 20% 50V
C909 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C910 1-126-965-11 ELECT 22uF 20% 50V
(EXCEPT PX)
C910 1-126-967-11 ELECT 47uF 20% 50V (PX)
C912 1-126-947-11 ELECT 47uF 20% 35V
0 C913 1-112-866-51 CERAMIC 100PF 10% 250V
C916 1-100-566-11 CERAMIC CHIP 0.1uF 10% 25V
0 C918 1-112-887-51 CERAMIC 0.01uF 20% 250V
0 C920 1-112-887-51 CERAMIC 0.01uF 20% 250V
0 C921 1-117-220-81 CERAMIC 150PF 5% 2KV
C922 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C923 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
0 C924 1-112-335-11 FILM 0.0033uF 5% 400V
0 C926 1-107-930-11 ELECT 22uF 20% 100V
C927 1-112-223-11 ELECT 3300uF 20% 10V
C928 1-112-232-11 ELECT 2700uF 20% 16V
C929 1-112-241-21 ELECT 1000uF 20% 25V
0 C930 1-112-866-51 CERAMIC 100PF 10% 250V
C932 1-114-994-11 ELECT 2200uF 20% 35V
C933 1-114-994-11 ELECT 2200uF 20% 35V
C934 1-112-831-31 ELECT 2200uF 20% 35V
C935 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C936 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C937 1-100-756-11 CERAMIC CHIP 0.047uF 10% 50V
0 C938 1-112-869-51 CERAMIC 470PF 10% 250V
C939 1-136-165-00 FILM 0.1uF 5% 50V
C940 1-112-228-21 ELECT 1000uF 20% 16V
0 C941 1-114-128-11 CERAMIC CHIP 47PF 5% 100V
C942 1-126-941-11 ELECT 470uF 20% 25V
C943 1-126-934-11 ELECT 220uF 20% 16V
(DZ280/DZ680)
C943 1-126-935-11 ELECT 470uF 20% 16V
(HDZ284/HDZ485)
C950 1-100-566-11 CERAMIC CHIP 0.1uF 10% 25V
C951 1-100-566-11 CERAMIC CHIP 0.1uF 10% 25V
C956 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
0 C963 1-112-869-51 CERAMIC 470PF 10% 250V
(EXCEPT CND)
0 C963 1-112-871-51 CERAMIC 0.0022uF 20% 250V
(CND)
0 C964 1-112-869-51 CERAMIC 470PF 10% 250V
(EXCEPT CND)
0 C964 1-112-871-51 CERAMIC 0.0022uF 20% 250V
(CND)
C969 1-100-566-11 CERAMIC CHIP 0.1uF 10% 25V
C970 1-100-566-11 CERAMIC CHIP 0.1uF 10% 25V
C971 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C972 1-100-566-11 CERAMIC CHIP 0.1uF 10% 25V
C973 1-100-566-11 CERAMIC CHIP 0.1uF 10% 25V
MAIN MS-203 P-SW POWER
Ver. 1.1
