Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HCD-DZ280/DZ680/HDZ284/HDZ485
98
C975 1-100-566-11 CERAMIC CHIP 0.1uF 10% 25V
C976 1-126-933-11 ELECT 100uF 20% 16V
0 C980 1-117-828-11 FILM 0.0033uF 3% 1.5KV
(CND)
C981 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C983 1-100-756-11 CERAMIC CHIP 0.047uF 10% 50V
C984 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C987 1-100-566-11 CERAMIC CHIP 0.1uF 10% 25V
(DZ680/HDZ485)
C990 1-100-566-11 CERAMIC CHIP 0.1uF 10% 25V
C991 1-100-566-11 CERAMIC CHIP 0.1uF 10% 25V
C992 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C993 1-100-566-11 CERAMIC CHIP 0.1uF 10% 25V
0 C994 1-112-869-51 CERAMIC 470PF 10% 250V (PX)
C997 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
(DZ280/DZ680)
C997 1-116-078-11 CERAMIC CHIP 1uF 10% 50V
(HDZ284/HDZ485)
< CONNECTOR >
CN901 1-564-321-00 PIN, CONNECTOR (3.96mm PITCH) 2P
CN904 1-785-102-11 PIN, CONNECTOR (3.96mm PITCH) 4P
CN906 1-564-715-11 PIN, CONNECTOR (SMALL TYPE) 13P
CN908 1-564-505-11 PLUG, CONNECTOR 2P (DZ680/HDZ485)
< DIODE >
D901 8-719-082-57 DIODE D5SBA60F01
D902 8-719-063-74 DIODE D1NL20U-TR2
D905 8-719-063-74 DIODE D1NL20U-TR2
D906 6-501-817-01 DIODE MA2J1110GLS0
D907 6-501-817-01 DIODE MA2J1110GLS0
D908 6-501-817-01 DIODE MA2J1110GLS0
D909 6-501-817-01 DIODE MA2J1110GLS0
D910 6-501-817-01 DIODE MA2J1110GLS0
D911 6-502-484-21 DIODE SG10SC6M-5600
D912 6-501-917-11 DIODE SG10SC9-5600
D913 6-500-241-01 DIODE SARS03
D914 6-501-817-01 DIODE MA2J1110GLS0
D916 6-502-484-21 DIODE SG10SC6M-5600
D921 6-502-234-01 DIODE EG01C LF-F7
D922 6-501-817-01 DIODE MA2J1110GLS0
D923 6-501-817-01 DIODE MA2J1110GLS0
D924 6-501-817-01 DIODE MA2J1110GLS0
D931 6-501-849-01 DIODE FMX-22SL
D946 6-502-234-01 DIODE EG01C LF-F7
D947 6-502-484-21 DIODE SG10SC6M-5600
D948 6-501-817-01 DIODE MA2J1110GLS0
D949 6-501-817-01 DIODE MA2J1110GLS0
D951 8-719-083-71 DIODE UDZSUSTE-1730B (CND)
DZ901 6-501-782-01 DIODE MAZ8180GMLS0
DZ902 6-502-231-01 DIODE MAZ8220GLLSO
DZ903 6-501-768-01 DIODE MAZ8120GMLS0
DZ904 6-501-734-01 DIODE MAZ8056GMLS0
DZ915 6-501-760-01 DIODE MAZ8100GMLS0
DZ932 6-501-734-01 DIODE MAZ8056GMLS0
DZ953 6-501-713-01 DIODE MAZ8033G0LS0
< TERMINAL BOARD >
EB902 1-537-770-21 TERMINAL BOARD (GROUND)
EB904 1-537-770-21 TERMINAL BOARD (GROUND)
EB907 1-537-770-21 TERMINAL BOARD (GROUND)
< FUSE >
0 F945 1-576-794-11 FUSE, MICRO (1608) 2A
< RESISTOR >
0 FR929 1-246-373-11 FUSIBLE 1 10% 1/2W F
< IC >
IC901 6-707-741-01 IC STR-F6138-LF1352 (CND)
IC901 6-707-742-01
IC STR-F6168-LF1352 (EXCEPT CND)
IC921 6-711-790-01 IC MR4020-7103
IC923 6-711-947-01 IC MM1431CURE
IC932 6-711-947-01 IC MM1431CURE
IC941 6-712-613-01 IC SI-3010KM-TLS
< JUMPER RESISTOR >
JR930 1-216-864-11
SHORT CHIP 0
JR931 1-216-864-11 SHORT CHIP 0
< COIL >
L931 1-457-438-11 COIL, CHOKE 5.6uH
L944 1-414-398-11 INDUCTOR 10uH
L945 1-414-398-11 INDUCTOR 10uH
L947 1-414-398-11 INDUCTOR 10uH
L948 1-414-398-11 INDUCTOR 10uH
L953 1-414-398-11 INDUCTOR 10uH
L954 1-457-578-11 COIL, CHOKE 10uH
L956 1-457-578-11 COIL, CHOKE 10uH
< LINE FILTER >
0 LF901 1-457-054-21 COIL, LINE FILTER (DZ280/DZ680)
0 LF901 1-457-449-11 COIL, LINE FILTER (HDZ284/HDZ485)
0 LF902 1-457-054-21 COIL, LINE FILTER (DZ280/DZ680)
0 LF902 1-457-449-11 COIL, LINE FILTER (HDZ284/HDZ485)
< PHOTO COUPLER >
PC901 6-600-276-01 PHOTO COUPLER PS2561AL1-1-V-W
PC902 6-600-276-01 PHOTO COUPLER PS2561AL1-1-V-W
PC903 6-600-276-01 PHOTO COUPLER PS2561AL1-1-V-W
PC904 6-600-276-01 PHOTO COUPLER PS2561AL1-1-V-W
< THERMISTOR (POSITIVE) >
PS954 1-802-595-11 THERMISTOR, POSITIVE MF-R250
PS956 1-802-596-11 THERMISTOR, POSITIVE MF-R300
< TRANSISTOR >
Q901 8-729-201-53 TRANSISTOR 2SA1015-GR
Q921 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q922 6-550-702-01 TRANSISTOR 2SC3243-TP-E
Q930 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q943 8-729-038-28 TRANSISTOR RT1N441C-TP-1
Q945 6-550-718-01 FET RSR025N03TL
Q947 8-729-038-28 TRANSISTOR RT1N441C-TP-1
Q949 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q950 8-729-038-28 TRANSISTOR RT1N441C-TP-1
< RESISTOR >
0 R901 1-219-759-11 METAL 1M 5% 1/2W F
(CND)
POWER
