100
HCD-DZ830W/DZ850KW
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
C303 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C309 1-126-957-11 ELECT 0.22uF 20% 50V
C311 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C312 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C313 1-126-933-11 ELECT 100uF 20% 16V
C314 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C315 1-126-933-11 ELECT 100uF 20% 16V
C317 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C320 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
(EXCEPT E32, MX)
C321 1-104-662-91 ELECT 22uF 20% 25V
C322 1-104-662-91 ELECT 22uF 20% 25V
C324 1-104-662-91 ELECT 22uF 20% 25V
(EXCEPT E32, MX)
C325 1-104-662-91 ELECT 22uF 20% 25V
C326 1-104-662-91 ELECT 22uF 20% 25V
C327 1-104-662-91 ELECT 22uF 20% 25V
(EXCEPT E32, MX)
C328 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
(EXCEPT E32, MX)
C329 1-126-933-11 ELECT 100uF 20% 16V
C330 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C331 1-126-916-11 ELECT 1000uF 20% 6.3V
C332 1-126-933-11 ELECT 100uF 20% 16V
C333 1-126-933-11 ELECT 100uF 20% 16V
C334 1-126-916-11 ELECT 1000uF 20% 6.3V
C335 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C337 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C338 1-126-933-11 ELECT 100uF 20% 16V
C339 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C340 1-104-662-91 ELECT 22uF 20% 25V
C341 1-104-662-91 ELECT 22uF 20% 25V
C342 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C343 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C344 1-126-964-11 ELECT 10uF 20% 50V
(EXCEPT E32, MX)
C345 1-126-933-11 ELECT 100uF 20% 16V
C346 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C347 1-126-925-91 ELECT 470uF 20% 10V
C348 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C349 1-126-933-11 ELECT 100uF 20% 16V
C350 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C351 1-126-933-11 ELECT 100uF 20% 16V
C352 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C353 1-126-933-11 ELECT 100uF 20% 16V
C354 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C355 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C356 1-126-966-11 ELECT 33uF 20% 50V
C357 1-126-964-11 ELECT 10uF 20% 50V
C358 1-126-964-11 ELECT 10uF 20% 50V
C359 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C360 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C361 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C362 1-126-964-11 ELECT 10uF 20% 50V
C363 1-126-933-11 ELECT 100uF 20% 16V
C364 1-126-933-11 ELECT 100uF 20% 16V
C365 1-162-921-11 CERAMIC CHIP 33PF 5% 50V
C367 1-126-964-11 ELECT 10uF 20% 50V
C368 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C369 1-126-933-11 ELECT 100uF 20% 16V
C371 1-104-662-91 ELECT 22uF 20% 25V
C372 1-104-662-91 ELECT 22uF 20% 25V
C373 1-104-662-91 ELECT 22uF 20% 25V
C374 1-104-662-91 ELECT 22uF 20% 25V
C376 1-104-662-91 ELECT 22uF 20% 25V
C383 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C384 1-126-933-11 ELECT 100uF 20% 16V
C385 1-126-960-11 ELECT 1uF 20% 50V
C386 1-126-960-11 ELECT 1uF 20% 50V
C387 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C388 1-127-573-11 CERAMIC CHIP 1uF 10% 16V
C389 1-126-947-11 ELECT 47uF 20% 35V
C390 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C391 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C392 1-126-933-11 ELECT 100uF 20% 16V
C393 1-126-960-11 ELECT 1uF 20% 50V
C394 1-126-957-11 ELECT 0.22uF 20% 50V
C396 1-126-960-11 ELECT 1uF 20% 50V
C397 1-126-964-11 ELECT 10uF 20% 50V
C400 1-126-964-11 ELECT 10uF 20% 50V
< CONNECTOR >
CN301 1-779-277-11 CONNECTOR, FFC (LIF (NON-ZIF)) 9P
(EXCEPT E32, MX)
CN302 1-564-707-11 PIN, CONNECTOR (SMALL TYPE) 5P
CN304 1-779-279-11 CONNECTOR, FFC (LIF (NON-ZIF)) 11P
CN305 1-568-828-11 CONNECTOR, FFC 9P
CN306 1-779-293-11 CONNECTOR, FFC (LIF (NON-ZIF)) 25P
(EXCEPT E32, MX)
CN307 1-779-273-11 CONNECTOR, FFC (LIF (NON-ZIF)) 5P
CN311 1-779-289-11 CONNECTOR, FFC (LIF (NON-ZIF)) 21P
(E32, MX)
< DIODE >
D280 6-501-193-01 DIODE 1SS355WTE-17
D281 6-501-193-01 DIODE 1SS355WTE-17
D300 6-501-193-01 DIODE 1SS355WTE-17
D301 6-501-193-01 DIODE 1SS355WTE-17
D306 8-719-069-54 DIODE UDZSTE-175.1B
D307 6-501-193-01 DIODE 1SS355WTE-17
D308 6-501-193-01 DIODE 1SS355WTE-17
D309 8-719-058-24 DIODE RB501V-40TE-17
< IC >
IC300 6-706-078-01 IC M62429FP-TP
IC301 6-600-466-01 IC TORX147L (SONY) (OPTICAL)
IC302 6-706-492-01 IC TC7SHU04FU (T5RSOJF)
IC303 8-759-385-76 IC MC14052 BDR2
IC304 8-759-385-76 IC MC14052 BDR2
IC305 8-759-832-10 IC LA3210 A/B-E
IC306 8-759-100-96 IC uPC4558G2
IC307 6-703-550-01 IC TA7809LS
IC308 6-710-470-01 IC MM1758AFBE
IC309 8-759-677-33 IC MM1228XFBE
< JACK >
J300 1-820-862-11 JACK, PIN 3P (SAT/CABLE)
IO-S-OUT
