101
HCD-DZ830W/DZ850KW
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
J301 1-694-920-11 TERMINAL BOARD (S TERMINAL+1P)
(MONITOR OUT)
J302 1-784-431-11 JACK, PIN 1P (COAXIAL)
J303 1-820-784-11 JACK, PIN 5P (COMPONENT VIDEO OUT/TV)
< COIL >
L201 1-469-525-91 INDUCTOR 10uH
L300 1-469-525-91 INDUCTOR 10uH
L301 1-469-525-91 INDUCTOR 10uH
L302 1-469-525-91 INDUCTOR 10uH
L304 1-469-525-91 INDUCTOR 10uH
L305 1-469-525-91 INDUCTOR 10uH
< TRANSISTOR >
Q302 8-729-027-52 TRANSISTOR DTC124EKA-T146
Q304 8-729-027-52 TRANSISTOR DTC124EKA-T146
Q305 8-729-027-52 TRANSISTOR DTC124EKA-T146
Q306 8-729-027-52 TRANSISTOR DTC124EKA-T146
Q307 8-729-027-52 TRANSISTOR DTC124EKA-T146
Q308 8-729-027-52 TRANSISTOR DTC124EKA-T146
(EXCEPT E32, MX)
< RESISTOR >
R227 1-218-285-11 METAL CHIP 75 5% 1/10W
R228 1-218-285-11 METAL CHIP 75 5% 1/10W
R229 1-218-285-11 METAL CHIP 75 5% 1/10W
R305 1-216-833-11 METAL CHIP 10K 5% 1/10W
R306 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R307 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R308 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
(EXCEPT E32, MX)
R309 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
(EXCEPT E32, MX)
R310 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R311 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R312 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R314 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R316 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R317 1-216-809-11 METAL CHIP 100 5% 1/10W
R318 1-216-809-11 METAL CHIP 100 5% 1/10W
R319 1-216-841-11 METAL CHIP 47K 5% 1/10W
R320 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R321 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R323 1-218-285-11 METAL CHIP 75 5% 1/10W
R324 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R326 1-218-285-11 METAL CHIP 75 5% 1/10W
R328 1-218-285-11 METAL CHIP 75 5% 1/10W
R329 1-216-817-11 METAL CHIP 470 5% 1/10W
R331 1-218-285-11 METAL CHIP 75 5% 1/10W
R332 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R333 1-216-841-11 METAL CHIP 47K 5% 1/10W
R334 1-216-841-11 METAL CHIP 47K 5% 1/10W
R335 1-216-841-11 METAL CHIP 47K 5% 1/10W
(EXCEPT E32, MX)
R336 1-216-841-11 METAL CHIP 47K 5% 1/10W
(EXCEPT E32, MX)
R337 1-216-841-11 METAL CHIP 47K 5% 1/10W
R338 1-216-841-11 METAL CHIP 47K 5% 1/10W
R339 1-218-285-11 METAL CHIP 75 5% 1/10W
R340 1-216-833-11 METAL CHIP 10K 5% 1/10W
R341 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R342 1-216-841-11 METAL CHIP 47K 5% 1/10W
R343 1-216-841-11 METAL CHIP 47K 5% 1/10W
R344 1-216-841-11 METAL CHIP 47K 5% 1/10W
(EXCEPT E32, MX)
R345 1-216-841-11 METAL CHIP 47K 5% 1/10W
(EXCEPT E32, MX)
R346 1-216-841-11 METAL CHIP 47K 5% 1/10W
R347 1-216-841-11 METAL CHIP 47K 5% 1/10W
R348 1-216-833-11 METAL CHIP 10K 5% 1/10W
R349 1-216-833-11 METAL CHIP 10K 5% 1/10W
R350 1-216-864-11 SHORT CHIP 0
R351 1-216-809-11 METAL CHIP 100 5% 1/10W
R352 1-216-833-11 METAL CHIP 10K 5% 1/10W
R353 1-216-833-11 METAL CHIP 10K 5% 1/10W
R356 1-216-833-11 METAL CHIP 10K 5% 1/10W
R359 1-218-285-11 METAL CHIP 75 5% 1/10W
R360 1-216-821-11 METAL CHIP 1K 5% 1/10W
R361 1-216-809-11 METAL CHIP 100 5% 1/10W
R363 1-216-841-11 METAL CHIP 47K 5% 1/10W
R364 1-216-841-11 METAL CHIP 47K 5% 1/10W
R365 1-216-841-11 METAL CHIP 47K 5% 1/10W
R366 1-216-841-11 METAL CHIP 47K 5% 1/10W
R367 1-216-833-11 METAL CHIP 10K 5% 1/10W
R370 1-218-285-11 METAL CHIP 75 5% 1/10W
(EXCEPT E32, MX)
R372 1-218-285-11 METAL CHIP 75 5% 1/10W
R373 1-216-833-11 METAL CHIP 10K 5% 1/10W
R374 1-216-845-11 METAL CHIP 100K 5% 1/10W
R375 1-216-864-11 SHORT CHIP 0
R378 1-216-864-11 SHORT CHIP 0
R379 1-216-833-11 METAL CHIP 10K 5% 1/10W
R382 1-216-833-11 METAL CHIP 10K 5% 1/10W
R383 1-216-837-11 METAL CHIP 22K 5% 1/10W
R386 1-216-864-11 SHORT CHIP 0
R387 1-216-815-11 METAL CHIP 330 5% 1/10W
0R388 1-215-865-11 METAL OXIDE 220 5% 1W F
R390 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R391 1-216-864-11 SHORT CHIP 0
R392 1-216-833-11 METAL CHIP 10K 5% 1/10W
R393 1-216-833-11 METAL CHIP 10K 5% 1/10W
R394 1-216-821-11 METAL CHIP 1K 5% 1/10W
R395 1-216-821-11 METAL CHIP 1K 5% 1/10W
R396 1-216-833-11 METAL CHIP 10K 5% 1/10W
R397 1-216-833-11 METAL CHIP 10K 5% 1/10W
(EXCEPT E32, MX)
R398 1-216-833-11 METAL CHIP 10K 5% 1/10W
R399 1-216-833-11 METAL CHIP 10K 5% 1/10W
R400 1-216-821-11 METAL CHIP 1K 5% 1/10W
R401 1-216-821-11 METAL CHIP 1K 5% 1/10W
(EXCEPT E32, MX)
R402 1-218-827-11 METAL CHIP 150 0.5% 1/10W
R403 1-216-845-11 METAL CHIP 100K 5% 1/10W
R404 1-216-845-11 METAL CHIP 100K 5% 1/10W
R405 1-218-827-11 METAL CHIP 150 0.5% 1/10W
R406 1-216-845-11 METAL CHIP 100K 5% 1/10W
R407 1-216-845-11 METAL CHIP 100K 5% 1/10W
IO-S-OUT
Ver. 1.1
