97
HCD-DZ830W/DZ850KW
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
R43 1-216-833-11 METAL CHIP 10K 5% 1/10W
R45 1-216-833-11 METAL CHIP 10K 5% 1/10W
R47 1-216-821-11 METAL CHIP 1K 5% 1/10W
R048 1-216-809-11 METAL CHIP 100 5% 1/10W
R49 1-216-864-11 SHORT CHIP 0
R50 1-216-821-11 METAL CHIP 1K 5% 1/10W
R51 1-216-864-11 SHORT CHIP 0
R52 1-216-864-11 SHORT CHIP 0
R53 1-216-801-11 METAL CHIP 22 5% 1/10W
R54 1-216-801-11 METAL CHIP 22 5% 1/10W
R58 1-216-864-11 SHORT CHIP 0
R59 1-216-864-11 SHORT CHIP 0
R60 1-216-864-11 SHORT CHIP 0
R65 1-216-801-11 METAL CHIP 22 5% 1/10W
R66 1-216-801-11 METAL CHIP 22 5% 1/10W
R67 1-216-801-11 METAL CHIP 22 5% 1/10W
R90 1-216-809-11 METAL CHIP 100 5% 1/10W
R91 1-216-809-11 METAL CHIP 100 5% 1/10W
R92 1-216-809-11 METAL CHIP 100 5% 1/10W
R742 1-216-821-11 METAL CHIP 1K 5% 1/10W
R744 1-216-833-11 METAL CHIP 10K 5% 1/10W
R745 1-216-835-11 METAL CHIP 15K 5% 1/10W
R781 1-216-849-11 METAL CHIP 220K 5% 1/10W
R782 1-216-809-11 METAL CHIP 100 5% 1/10W
R783 1-216-295-91 SHORT CHIP 0
R784 1-216-821-11 METAL CHIP 1K 5% 1/10W
R785 1-216-864-11 SHORT CHIP 0
R788 1-216-864-11 SHORT CHIP 0
< VIBRATOR >
X1 1-795-807-11 VIBRATOR, CRYSTAL (25MHz)
************************************************************
A-1222-498-A FL BOARD, COMPLETE
******************
< CAPACITOR >
C800 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C801 1-163-037-11 CERAMIC CHIP 0.022uF 10% 50V
C802 1-126-947-11 ELECT 47uF 20% 35V
C803 1-126-933-11 ELECT 100uF 20% 16V
C804 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C805 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C809 1-126-157-11 ELECT 10uF 20% 16V
C811 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C814 1-126-157-11 ELECT 10uF 20% 16V
C829 1-124-259-11 ELECT 4.7uF 20% 50V
< CONNECTOR >
CN801 1-779-558-11 CONNECTOR, FFC (LIF (NON-ZIF)) 21P
CN805 1-794-506-51 CONNECTOR, FFC/FPC 13P
< DIODE >
D801 6-501-193-01 DIODE 1SS355WTE-17
D802 6-501-193-01 DIODE 1SS355WTE-17
D803 6-501-169-01 DIODE UDZW-TE17-6.2B
D804 6-501-193-01 DIODE 1SS355WTE-17
D805 6-501-193-01 DIODE 1SS355WTE-17
< IC >
IC801 6-600-349-21 IC NJL23H400A
IC802 8-759-643-83 IC uPD16315GB-3BS
< JUMPER RESISTOR >
JR801 1-216-864-11 SHORT CHIP 0
JR802 1-216-864-11 SHORT CHIP 0
JR807 1-216-864-11 SHORT CHIP 0
JR808 1-216-864-11 SHORT CHIP 0
< COIL >
L801 1-410-671-31 INDUCTOR 47uH
L802 1-410-671-31 INDUCTOR 47uH
< FLUORESCENT INDICATOR TUBE >
ND001 1-451-590-11 VACUUM FLUORESCENT DISPLAYS
< TRANSISTOR >
Q801 6-550-065-01 TRANSISTOR CPH5504-TL-E
< RESISTOR >
R800 1-216-864-11 SHORT CHIP 0
R801 1-216-839-11 METAL CHIP 33K 5% 1/10W
R802 1-216-809-11 METAL CHIP 100 5% 1/10W
R804 1-216-828-11 METAL CHIP 3.9K 5% 1/10W
R805 1-216-295-91 SHORT CHIP 0
R811 1-216-844-11 METAL CHIP 82K 5% 1/10W
R812 1-216-845-11 METAL CHIP 100K 5% 1/10W
R813 1-216-845-11 METAL CHIP 100K 5% 1/10W
R814 1-216-809-11 METAL CHIP 100 5% 1/10W
R815 1-216-809-11 METAL CHIP 100 5% 1/10W
R816 1-216-809-11 METAL CHIP 100 5% 1/10W
R819 1-216-805-11 METAL CHIP 47 5% 1/10W
R820 1-216-845-11 METAL CHIP 100K 5% 1/10W
< TRANSFORMER >
T801 1-443-645-11 TRANSFORMER, DC CONVERTER
************************************************************
A-1231-251-A IO-SCART BOARD, COMPLETE (DZ830W)
************************
< CAPACITOR >
C201 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C202 1-126-925-91 ELECT 470uF 20% 10V
C203 1-126-933-11 ELECT 100uF 20% 16V
C204 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C206 1-126-964-11 ELECT 10uF 20% 50V
C208 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C209 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C210 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C211 1-126-964-11 ELECT 10uF 20% 50V
C214 1-126-916-11 ELECT 1000uF 20% 6.3V
C215 1-126-933-11 ELECT 100uF 20% 16V
C216 1-126-933-11 ELECT 100uF 20% 16V
C221 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C222 1-104-658-91 ELECT 100uF 20% 10V
