98
HCD-DZ830W/DZ850KW
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
C224 1-126-964-11 ELECT 10uF 20% 50V
C225 1-126-916-11 ELECT 1000uF 20% 6.3V
C231 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C232 1-126-933-11 ELECT 100uF 20% 16V
C233 1-126-933-11 ELECT 100uF 20% 16V
C234 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C238 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C239 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C240 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C244 1-126-916-11 ELECT 1000uF 20% 6.3V
C245 1-126-916-11 ELECT 1000uF 20% 6.3V
C246 1-126-916-11 ELECT 1000uF 20% 6.3V
C271 1-126-933-11 ELECT 100uF 20% 16V
C295 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C296 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C304 1-126-947-11 ELECT 47uF 20% 35V
C311 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C312 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C313 1-126-933-11 ELECT 100uF 20% 16V
C314 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C315 1-126-933-11 ELECT 100uF 20% 16V
C317 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C320 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C321 1-104-662-91 ELECT 22uF 20% 25V
C324 1-104-662-91 ELECT 22uF 20% 25V
C325 1-104-662-91 ELECT 22uF 20% 25V
C326 1-104-662-91 ELECT 22uF 20% 25V
C327 1-104-662-91 ELECT 22uF 20% 25V
C328 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C330 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C340 1-104-662-91 ELECT 22uF 20% 25V
C341 1-104-662-91 ELECT 22uF 20% 25V
C342 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C343 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C345 1-104-662-91 ELECT 22uF 20% 25V
C349 1-126-933-11 ELECT 100uF 20% 16V
C350 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C353 1-126-933-11 ELECT 100uF 20% 16V
C354 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C356 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C360 1-126-959-11 ELECT 0.47uF 20% 50V
C362 1-126-933-11 ELECT 100uF 20% 16V
C363 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C365 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C367 1-104-662-91 ELECT 22uF 20% 25V
C368 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C369 1-126-933-11 ELECT 100uF 20% 16V
C371 1-104-662-91 ELECT 22uF 20% 25V
C372 1-104-662-91 ELECT 22uF 20% 25V
C373 1-104-662-91 ELECT 22uF 20% 25V
C374 1-104-662-91 ELECT 22uF 20% 25V
C376 1-104-662-91 ELECT 22uF 20% 25V
C383 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C384 1-126-933-11 ELECT 100uF 20% 16V
C385 1-126-960-11 ELECT 1uF 20% 50V
C386 1-126-960-11 ELECT 1uF 20% 50V
C387 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C388 1-127-573-11 CERAMIC CHIP 1uF 10% 16V
C389 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C390 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C391 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C392 1-126-933-11 ELECT 100uF 20% 16V
< CONNECTOR >
CN301 1-779-277-11 CONNECTOR, FFC (LIF (NON-ZIF)) 9P
CN302 1-564-706-11 PIN, CONNECTOR (SMALL TYPE) 4P
CN304 1-779-281-11 CONNECTOR, FFC (LIF (NON-ZIF)) 13P
CN305 1-568-830-11 CONNECTOR, FFC 11P
CN306 1-779-293-11 CONNECTOR, FFC (LIF (NON-ZIF)) 25P
CN307 1-779-273-11 CONNECTOR, FFC (LIF (NON-ZIF)) 5P
< DIODE >
D271 6-501-193-01 DIODE 1SS355WTE-17
D272 6-501-193-01 DIODE 1SS355WTE-17
D280 6-501-193-01 DIODE 1SS355WTE-17
D281 6-501-193-01 DIODE 1SS355WTE-17
D309 8-719-058-24 DIODE RB501V-40TE-17
< IC >
IC201 6-707-489-01 IC BH7868FS-E2
IC202 6-703-622-01 IC MM1508XNRE
IC230 6-707-489-01 IC BH7868FS-E2
IC301 6-600-466-01 IC TORX147L (SONY) (OPTICAL)
IC302 6-706-492-01 IC TC7SHU04FU (T5RSOJF)
IC303 8-759-385-76 IC MC14052 BDR2
IC304 8-759-385-76 IC MC14052 BDR2
IC305 8-759-100-96 IC uPC4558G2
IC306 8-759-100-96 IC uPC4558G2
IC307 6-703-550-01 IC TA7809LS
< JACK >
J203 1-820-784-11 JACK, PIN 5P
(COMPONENT VIDEO OUT//SAT/CABLE)
J230 1-816-044-11 CONNECTOR, SQUARE TYPE 21P (EURO AV)
J302 1-784-431-11 JACK, PIN 1P (COAXIAL)
< COIL >
L201 1-469-525-91 INDUCTOR 10uH
L221 1-469-525-91 INDUCTOR 10uH
L231 1-469-525-91 INDUCTOR 10uH
L301 1-469-525-91 INDUCTOR 10uH
L302 1-469-525-91 INDUCTOR 10uH
L304 1-469-525-91 INDUCTOR 10uH
L305 1-469-525-91 INDUCTOR 10uH
< TRANSISTOR >
Q271 8-729-038-28 TRANSISTOR RT1N441C-TP-1
Q272 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q273 8-729-027-23 TRANSISTOR DTA114EKA-T146
Q274 8-729-038-28 TRANSISTOR RT1N441C-TP-1
Q275 8-729-027-23 TRANSISTOR DTA114EKA-T146
Q276 8-729-038-28 TRANSISTOR RT1N441C-TP-1
Q277 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q279 8-729-027-52 TRANSISTOR DTC124EKA-T146
Q305 8-729-027-52 TRANSISTOR DTC124EKA-T146
