Sony HCD-ED2 - Page 29

29
• RDS Board
IC451 BU1922
QUALITY BIT
GENERATOR
DEFFERENTIAL
DECODER
BIPHASE
SYMBOL
DECODER
OSCILLATOR
AND
DIVIDER
57kHz
BANDPASS
(8th ORDER)
CONTAS LOOP
VARIABLE AND
FIXED DIVIDER
REFERENCE
VOLTAGE
ANTI-
ALIASING
FILTER
CLOCKED
COMPARATOR
TEST LOGIC AND OUTPUT
SELECTOR SWITCH
RECONSTRUCTION
FILTER
141516 13 12 11 10 9
321 4 5 6 7 8
CLOCK REGENERATION
AND SYNC
VP1
RDCL TS7 OSCO OSCI V
DDD
V
SSD
TEST TSTL
D
QUAL
RDDA
Vref
MUX
V
DDA
V
SSA
CIN
SCOUT
• TAPE PREAMP Board
IC191 BA6218
1
2 3 4
6
5
9
8
7
A OUT
POW
GND
B OUT
A IN
GND
B IN
NC
GND
VCC
