40
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
< TRANSISTOR >
Q201 8-729-230-49 TRANSISTOR 2SC2712G-TE85L
Q216 8-729-230-49 TRANSISTOR 2SC2712G-TE85L
< RESISTOR >
R200 1-216-073-00 METAL CHIP 10K 5% 1/10W
R201 1-216-085-00 METAL CHIP 33K 5% 1/10W
R202 1-249-424-11 CARBON 3.9K 5% 1/4W F
R203 1-216-073-00 METAL CHIP 10K 5% 1/10W
R204 1-216-089-91 RES,CHIP 47K 5% 1/10W
R205 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R206 1-247-807-31 CARBON 100 5% 1/4W
R208 1-216-089-91 RES,CHIP 47K 5% 1/10W
R209 1-249-429-11 CARBON 10K 5% 1/4W
R210 1-216-073-00 METAL CHIP 10K 5% 1/10W
R211 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R212 1-216-073-00 METAL CHIP 10K 5% 1/10W
R222 1-249-429-11 CARBON 10K 5% 1/4W
R225 1-216-073-00 METAL CHIP 10K 5% 1/10W
R226 1-247-807-31 CARBON 100 5% 1/4W
R227 1-216-073-00 METAL CHIP 10K 5% 1/10W
R229 1-216-073-00 METAL CHIP 10K 5% 1/10W
R230 1-216-073-00 METAL CHIP 10K 5% 1/10W
R239 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R240 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R246 1-216-073-00 METAL CHIP 10K 5% 1/10W
R247 1-216-073-00 METAL CHIP 10K 5% 1/10W
R248 1-216-073-00 METAL CHIP 10K 5% 1/10W
R250 1-247-807-31 CARBON 100 5% 1/4W
R253 1-249-425-11 CARBON 4.7K 5% 1/4W F
(US,CND,AEP,UK,MY,SP,KR,TW,AUS)
R254 1-249-420-11 CARBON 1.8K 5% 1/4W F
(US,CND)
R254 1-249-418-11 CARBON 1.2K 5% 1/4W F
(AEP,UK,MY,SP,KR,TW)
R254 1-249-416-11 CARBON 820 5% 1/4W F
(AUS)
R255 1-216-041-00 METAL CHIP 470 5% 1/10W
R256 1-249-412-11 CARBON 390 5% 1/4W F
R257 1-216-039-00 METAL CHIP 390 5% 1/10W
R258 1-216-043-91 RES,CHIP 560 5% 1/10W
R259 1-216-045-00 METAL CHIP 680 5% 1/10W
R260 1-216-046-00 METAL CHIP 750 5% 1/10W
R261 1-216-047-91 RES,CHIP 820 5% 1/10W
R262 1-249-418-11 CARBON 1.2K 5% 1/4W F
R263 1-216-053-00 METAL CHIP 1.5K 5% 1/10W
R270 1-249-393-11 CARBON 10 5% 1/4W F
R272 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R274 1-247-807-31 CARBON 100 5% 1/4W
R275 1-216-025-91 RES,CHIP 100 5% 1/10W
R276 1-247-807-31 CARBON 100 5% 1/4W
R277 1-216-025-91 RES,CHIP 100 5% 1/10W
R278 1-216-025-91 RES,CHIP 100 5% 1/10W
R279 1-216-025-91 RES,CHIP 100 5% 1/10W
R280 1-216-025-91 RES,CHIP 100 5% 1/10W
R281 1-247-807-31 CARBON 100 5% 1/4W
R282 1-247-807-31 CARBON 100 5% 1/4W
R283 1-247-807-31 CARBON 100 5% 1/4W
R284 1-247-807-31 CARBON 100 5% 1/4W
R285 1-247-807-31 CARBON 100 5% 1/4W
R286 1-216-025-91 RES,CHIP 100 5% 1/10W
R287 1-216-025-91 RES,CHIP 100 5% 1/10W
R290 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R293 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R294 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R297 1-216-025-91 RES,CHIP 100 5% 1/10W
R210A 1-216-073-00 METAL CHIP 10K 5% 1/10W
R210B 1-249-429-11 CARBON 10K 5% 1/4W
R246A 1-216-073-00 METAL CHIP 10K 5% 1/10W
R247A 1-216-073-00 METAL CHIP 10K 5% 1/10W
R248A 1-216-073-00 METAL CHIP 10K 5% 1/10W
< SWITCH >
S200 1-571-760-11 SWITCH, KEY BOARD (I/u)
S201 1-571-760-11 SWITCH, KEY BOARD (VOL+)
S202 1-571-760-11 SWITCH, KEY BOARD (VOL-)
S203 1-571-760-11 SWITCH, KEY BOARD (TUNING+/=0)
S204 1-571-760-11 SWITCH, KEY BOARD (TUNING-/)+)
S205 1-571-760-11 SWITCH, KEY BOARD (FM/()
S206 1-571-760-11 SWITCH, KEY BOARD (AM/9)
S207 1-571-760-11 SWITCH, KEY BOARD (p)
S208 1-571-760-11 SWITCH, KEY BOARD (P)
S209 1-571-760-11 SWITCH, KEY BOARD (FUNCTION)
< VIBRATOR >
X201 1-781-705-11 OSCILLATOR, CRYSTAL (131-8MHZ) (8MHz)
< FLUORESCENT INDICATOR TUBE >
Z201 1-793-885-11 INDICATOR TUBE, FLUORESCENT
**************************************************************
A-4428-113-A FUNCTION BOARD, COMPLETE
*************************
< CAPACITOR >
C307 1-163-275-11 CERAMIC CHIP 0.001uF 5% 50V
C308 1-163-275-11 CERAMIC CHIP 0.001uF 5% 50V
C310 1-126-059-11 ELECT 10uF 20% 50V
C311 1-130-471-00 MYLAR 0.001uF 5% 50V
C312 1-130-495-00 MYLAR 0.1uF 5% 50V
C313 1-126-163-11 ELECT 4.7uF 20% 50V
C314 1-126-163-11 ELECT 4.7uF 20% 50V
C315 1-126-059-11 ELECT 10uF 20% 50V
C316 1-126-059-11 ELECT 10uF 20% 50V
C317 1-126-052-11 ELECT 100uF 20% 10V
C318 1-126-052-11 ELECT 100uF 20% 10V
C319 1-163-005-11 CERAMIC CHIP 470PF 10% 50V
C320 1-163-005-11 CERAMIC CHIP 470PF 10% 50V
C321 1-126-059-11 ELECT 10uF 20% 50V
C322 1-124-997-11 ELECT 470uF 20% 10V
C323 1-124-997-11 ELECT 470uF 20% 10V
C324 1-126-059-11 ELECT 10uF 20% 50V
C325 1-126-059-11 ELECT 10uF 20% 50V
C326 1-126-059-11 ELECT 10uF 20% 50V
C327 1-126-059-11 ELECT 10uF 20% 50V
DISPLAY FUNCTION
