39
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
BD CD SW
< RESISTOR >
R101 1-216-077-91 RES,CHIP 15K 5% 1/10W
R102 1-216-097-91 RES,CHIP 100K 5% 1/10W
R103 1-216-077-91 RES,CHIP 15K 5% 1/10W
R104 1-216-085-00 METAL CHIP 33K 5% 1/10W
R105 1-216-073-00 METAL CHIP 10K 5% 1/10W
R106 1-216-049-91 RES,CHIP 1K 5% 1/10W
R107 1-216-073-00 METAL CHIP 10K 5% 1/10W
R108 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R109 1-216-121-91 RES,CHIP 1M 5% 1/10W
R110 1-216-025-91 RES,CHIP 100 5% 1/10W
R111 1-216-121-91 RES,CHIP 1M 5% 1/10W
R113 1-216-121-91 RES,CHIP 1M 5% 1/10W
R114 1-216-073-00 METAL CHIP 10K 5% 1/10W
R116 1-216-001-00 METAL CHIP 10 5% 1/10W
R117 1-216-049-91 RES,CHIP 1K 5% 1/10W
R119 1-216-041-00 METAL CHIP 470 5% 1/10W
R123 1-216-049-91 RES,CHIP 1K 5% 1/10W
R124 1-216-097-91 RES,CHIP 100K 5% 1/10W
R131 1-216-037-00 METAL CHIP 330 5% 1/10W
R135 1-216-295-91 SHORT 0
R136 1-216-295-91 SHORT 0
R137 1-216-295-91 SHORT 0
R138 1-216-295-91 SHORT 0
R139 1-216-025-91 RES,CHIP 100 5% 1/10W
R143 1-216-103-00 METAL CHIP 180K 5% 1/10W
R144 1-216-103-00 METAL CHIP 180K 5% 1/10W
R147 1-216-069-00 METAL CHIP 6.8K 5% 1/10W
R148 1-216-001-00 METAL CHIP 10 5% 1/10W
R149 1-216-001-00 METAL CHIP 10 5% 1/10W
R158 1-216-111-00 METAL CHIP 390K 5% 1/10W
R159 1-216-101-00 METAL CHIP 150K 5% 1/10W
R161 1-216-308-00 METAL CHIP 4.7 5% 1/10W
R162 1-216-101-00 METAL CHIP 150K 5% 1/10W
R171 1-216-078-00 RES,CHIP 16K 5% 1/10W
R172 1-216-073-00 METAL CHIP 10K 5% 1/10W
R173 1-216-077-91 RES,CHIP 15K 5% 1/10W
R181 1-216-078-00 RES,CHIP 16K 5% 1/10W
R182 1-216-073-00 METAL CHIP 10K 5% 1/10W
R183 1-216-077-91 RES,CHIP 15K 5% 1/10W
< RESISTOR >
RN101 1-233-412-11 RES, CHIP NETWORK 1.0K (3216)
RN102 1-233-576-11 RES, CHIP NETWORK 100
< VIBRATOR >
X101 1-767-408-21 VIBRATOR, CRYSTAL (16.9344MHz)
**************************************************************
1-676-334-11 CD SW BOARD
************
< SWITCH >
SW601 1-571-300-21 SWITCH, ROTARY (CD DOOR SWITCH)
**************************************************************
A-4428-104-A DISPLAY BOARD, COMPLETE
************************
(AEP,UK,MY,SP,KR,TW)
A-4428-244-A DISPLAY BOARD, COMPLETE (US,CND)
************************
A-4428-248-A DISPLAY BOARD, COMPLETE (AUS)
************************
A-4428-249-A DISPLAY BOARD, COMPLETE (HK)
************************
4-225-851-01 LCD HOLDER
4-225-852-01 DISPLAY FILTER
4-225-853-01 LIGHT BAR
< CAPACITOR >
C121 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C200 1-124-584-00 ELECT 100uF 20% 10V
C201 1-102-962-00 CERAMIC 30PF 5% 50V
C202 1-102-953-00 CERAMIC 18PF 5% 50V
C203 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C204 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C205 1-126-916-11 ELECT 1000uF 20% 6.3V
C206 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C207 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C208 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C209 1-162-901-11 CERAMIC 0.1uF 99% 50V
C213 1-124-584-00 ELECT 100uF 20% 10V
C220 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C232 1-124-584-00 ELECT 100uF 20% 10V
C233 1-163-031-11 CERAMIC CHIP 0.01uF 50V
C234 1-163-031-11 CERAMIC CHIP 0.01uF 50V
< CONNECTOR >
CN1 1-784-737-11 CONNECTOR, FFC 15P
M201 1-793-882-11 CONNECTOR (197-K310-07)
M202 1-793-883-11 CONNECTOR (197-K310-14)
M203 1-793-884-11 CONNECTOR (197-K310-25)
< DIODE >
D201 8-719-937-56 DIODE RLS-73-TE-11
D202 8-719-937-56 DIODE RLS-73-TE-11
D203 8-719-937-56 DIODE RLS-73-TE-11
D210 8-719-937-56 DIODE RLS-73-TE-11
D211 8-719-937-56 DIODE RLS-73-TE-11
D212 8-719-937-56 DIODE RLS-73-TE-11
D216 8-719-937-56 DIODE RLS-73-TE-11
< IC >
IC201 8-759-653-24 IC TMP87CM23F-1C04
IC202 8-742-132-00 HYB IC SBX1976-51P
IC203 8-759-165-80 IC PST600C-T
< COIL >
L201 1-410-521-11 INDUCTOR 100uH
DISPLAY
