47
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
R650 1-216-689-11 METAL CHIP 39K 0.5% 1/10W
R651 1-216-091-00 METAL CHIP 56K 5% 1/10W
R652 1-216-025-91 RES,CHIP 100 5% 1/10W
R701 1-216-025-91 RES,CHIP 100 5% 1/10W
R702 1-247-807-31 CARBON 100 5% 1/4W
R703 1-216-107-00 METAL CHIP 270K 5% 1/10W
R704 1-216-107-00 METAL CHIP 270K 5% 1/10W
R705 1-249-404-00 CARBON 82 5% 1/4W F
R706 1-249-404-00 CARBON 82 5% 1/4W F
R707 1-216-081-00 METAL CHIP 22K 5% 1/10W
R708 1-216-081-00 METAL CHIP 22K 5% 1/10W
R709 1-216-100-00 RES,CHIP 130K 5% 1/10W
R710 1-216-100-00 RES,CHIP 130K 5% 1/10W
R711 1-216-068-00 METAL CHIP 6.2K 5% 1/10W
R712 1-216-068-00 METAL CHIP 6.2K 5% 1/10W
R713 1-247-815-91 CARBON 220 5% 1/4W
R714 1-216-033-00 METAL CHIP 220 5% 1/10W
R715 1-249-437-11 CARBON 47K 5% 1/4W
R716 1-247-815-91 CARBON 220 5% 1/4W
R717 1-249-430-11 CARBON 12K 5% 1/4W
R718 1-249-430-11 CARBON 12K 5% 1/4W
R719 1-216-308-00 METAL CHIP 4.7 5% 1/10W
R720 1-216-308-00 METAL CHIP 4.7 5% 1/10W
R721 1-216-081-00 METAL CHIP 22K 5% 1/10W
R722 1-247-863-91 CARBON 22K 5% 1/4W
R723 1-249-381-11 CARBON 1 5% 1/4W F
R724 1-216-081-00 METAL CHIP 22K 5% 1/10W
R725 1-216-073-00 METAL CHIP 10K 5% 1/10W
R741 1-249-435-11 CARBON 33K 5% 1/4W
R742 1-247-863-91 CARBON 22K 5% 1/4W
R743 1-216-049-91 RES,CHIP 1K 5% 1/10W
R744 1-216-049-91 RES,CHIP 1K 5% 1/10W
R745 1-216-067-00 METAL CHIP 5.6K 5% 1/10W
R746 1-216-067-00 METAL CHIP 5.6K 5% 1/10W
R749 1-216-097-91 RES,CHIP 100K 5% 1/10W
R750 1-216-109-00 METAL CHIP 330K 5% 1/10W
R751 1-249-429-11 CARBON 10K 5% 1/4W
R752 1-216-083-00 METAL CHIP 27K 5% 1/10W
R753 1-249-429-11 CARBON 10K 5% 1/4W
R754 1-216-049-91 RES,CHIP 1K 5% 1/10W
R757 1-247-885-00 CARBON 180K 5% 1/4W
R758 1-247-840-00 CARBON 2.4K 5% 1/4W
R759 1-249-432-11 CARBON 18K 5% 1/4W
R760 1-247-840-00 CARBON 2.4K 5% 1/4W
R761 1-247-866-11 CARBON 30K 5% 1/4W
R762 1-247-866-11 CARBON 30K 5% 1/4W
R763 1-216-089-91 RES,CHIP 47K 5% 1/10W
R764 1-249-437-11 CARBON 47K 5% 1/4W
R765 1-216-089-91 RES,CHIP 47K 5% 1/10W
R766 1-249-437-11 CARBON 47K 5% 1/4W
< VARIABLE RESISTOR >
VR701 1-230-499-11 RES, ADJ, CARBON 100K (REC LEVEL L)
VR702 1-230-499-11 RES, ADJ, CARBON 100K (REC LEVEL R)
VR703 1-230-497-11 RES, ADJ, CARBON 22K (PB LEVEL L)
VR704 1-230-497-11 RES, ADJ, CARBON 22K (PB LEVEL R)
VR705 1-230-495-11 RES, ADJ, CARBON 2K (REC BIAS L)
VR706 1-230-495-11 RES, ADJ, CARBON 2K (REC BIAS R)
**************************************************************
1-676-335-11 TOUCH SENSOR BOARD
*******************
< CAPACITOR >
C601 1-163-239-11 CERAMIC CHIP 33PF 5% 50V
< RESISTOR >
R601 1-216-049-91 RES,CHIP 1K 5% 1/10W
**************************************************************
MISCELLANEOUS
**************
51 1-693-407-12 TUNER (US,CND)
51 1-693-408-12 TUNER (EXCEPT US,CND)
! 54 1-555-750-11 CORD, POWER, EULO PLUG
(AEP,MY,SP,HK,KR,TW)
! 54 1-783-531-51 CORD, POWER (US,CND)
! 54 1-696-966-31 CORD, POWER (AUS)
! 54 1-751-535-11 CORD, POWER (UK)
! 63 1-770-019-11 ADAPTOR, CONVERSION PLUG 3P (HK)
104 1-791-958-11 WIRE (FLAT TYPE)(15CORE)
117 1-791-959-11 FFC (184-F312F5508),12P
121 1-418-482-11 ILLUMINATION BLOCK, LED
151 1-772-264-11 DECK, MECHANICAL
! 201 8-848-289-31 DEVICE, OPTICAL KSS-331A (RP)
M101 X-2625-911-1 MOTOR ASSY (TT) (SPINDLE)
M102 X-2625-171-1 MOTOR ASSY (SLED)
M901 X-4952-489-1 MTR MAIN BLK ASSY(CAPSTAN/REEL)
M903 1-541-632-11 MOTOR,DC (DOOR)
S101 1-762-571-11 SWITCH (LIMIT)
S501 1-771-871-11 SELECTOR, VOLTAGE (202-L16-12A)
(MY,SP,TW,HK)
! T501 1-435-254-11 TRANSFORMER,POWER (200-99Y0282)
(AEP,UK)
! T501 1-435-255-11 TRANSFORMER,POWER (200-99Y0283)
(US,CND)
! T501 1-435-256-11 TRANSFORMER,POWER (200-99Y0320)
(MY,SP,HK,TW)
! T501 1-435-317-11 TRANSFORMER,POWER (200-99Y0380) (AUS)
! T501 1-435-331-11 TRANSFORMER,POWER (200-99Y0467) (KR)
Z201 1-793-885-11 INDICATOR TUBE,FLUORESCENT
**************************************************************
**************
HARDWARE LIST
**************
#1 7-685-246-19 SCREW + KTP 3x8 TYPE2 SLIT
#2 7-685-547-19 SCREW + BTP 3x10 TYPE2 N-S
#3 7-685-534-19 SCREW + BTP 2.6x8 TYPE2 N-S
#4 7-621-775-10 SCREW + B 2.6x4 TYPE2 N-S
#5 7-685-546-19 SCREW + BTP 3x8 TYPE2 N-S
#6 7-623-553-88 SCREW, PRECISION + P 2x7
#7 7-627-554-28 SCREW, PRECISION + P M2x5 TYPE1
#8 7-685-105-19 SCREW (2x8) ,TAPPING (B)
#9 7-685-104-19 SCREW (2x6) ,TAPPING (B)
#10 7-627-852-18 SCREW, PRECISION + P 1.7x4 TYPE3
#11 7-627-852-17 + P 1.7x4
TAPE PREAMP
TOUCH SENSOR
Ver 1.1 2002.05
