Sony HCD-GNX780 - Front Panel Section-1

65
HCD-GNX780/GNX880
8-2. FRONT PANEL SECTION-1
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
not supplied
not supplied
not supplied
58
59
59
51
52
53
54
55
56
62
63
59
59
59
59
59
59
59
70
59
67
68
69
64
65
66
60
61
62
57
55
51 2-655-724-01 LID (TC)
52 2-655-732-01 SPRING (LID)
53 4-252-579-11 HOLDER TC-R
54 4-252-578-11 HOLDER TC-L
55 4-959-229-11 DETENT, CASSETTE
56 4-224-578-31 KNOB (MIC)
57 4-252-575-01 KNOB VOL
58 X-2103-230-1 KNOB JOG ASSY
59 3-087-053-01 +BVTP2.6 (3CR)
60 A-1156-244-A JOG BOARD, COMPLETE
61 2-655-717-01 WINDOW (FL)
62 4-224-104-11 DAMPER
63 A-1156-227-A FUNCTION BOARD, COMPLETE
64 A-1156-224-A PANEL BOARD, COMPLETE
65 1-828-990-11 WIRE (FLAT TYPE) (17 CORE) (80mm)
66 1-828-991-11 WIRE (FLAT TYPE) (17 CORE) (100mm)
67 1-417-656-11 MECHA DECK (CWN42FF601)
68 2-655-734-01 SPRING (R)
69 2-655-733-01 SPRING (L)
70 A-1156-233-A MIC BOARD, COMPLETE
