Sony HCD-GNX780 - Front Panel Assy; Tuner Pack

9
HCD-GNX780/GNX880
3-4. FRONT PANEL ASSY
3-5. TUNER PACK
1 three screws
(+BVTP 3
× 10)
2 three screws
(+BVTP 3
× 10)
3 screw
(+BVTP 3
× 10)
4 screw
(+BVTP 3
× 10)
5 front panel assy
6 connector
(CN100)
7 wire (flat type)
(CN508)
8 wire (flat type)
(CN509)
9 connector
(CN503)
q; connector
(CN1102)
qa connector
(CN507)
1 two screws
(+BVTP 3 × 6)
2 wire (flat type)
(CN1)
3 tuner pack
