72
HCD-GNX780/GNX880
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
CN1003 1-785-314-11 PIN, CONNECTOR (STRAIGHT) 2P
< DIODE >
D1003 6-501-193-01 DIODE 1SS355WTE-17
D1004 6-501-193-01 DIODE 1SS355WTE-17
< FERRITE BEAD >
FB1001 1-216-864-11 SHORT CHIP 0
< IC >
IC1001 6-707-420-01 IC TC9411AFG (BS, K)
IC1002 6-704-474-01 IC MSM514400E-60TS-K
IC1003 6-703-547-01 IC TA7805LS
IC1005 8-759-584-98 IC SN74AHCT04NSR
IC1006 6-703-378-01 IC NJM2575F1-TE2
< JACK >
J1001 1-794-970-11 JACK, PIN 1P (VIDEO OUT)
< COIL >
L1001 1-216-296-11 SHORT CHIP 0
L1002 1-216-296-11 SHORT CHIP 0
< TRANSISTOR >
Q1001 8-729-027-43 TRANSISTOR DTC114EKA-T146
Q1002 8-729-027-43 TRANSISTOR DTC114EKA-T146
Q1004 8-729-027-43 TRANSISTOR DTC114EKA-T146
Q1005 8-729-027-43 TRANSISTOR DTC114EKA-T146
Q1006 8-729-027-23 TRANSISTOR DTA114EKA-T146
Q1007 8-729-027-43 TRANSISTOR DTC114EKA-T146
Q1009 8-729-027-23 TRANSISTOR DTA114EKA-T146
Q1010 8-729-027-43 TRANSISTOR DTC114EKA-T146
Q1008 8-729-140-04 TRANSISTOR 2SB1116A-L
< RESISTOR >
R1003 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R1004 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R1005 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R1006 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R1011 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R1012 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R1013 1-216-820-11 METAL CHIP 820 5% 1/10W
R1015 1-216-864-11 SHORT CHIP 0
R1016 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1017 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1018 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1019 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1020 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1021 1-216-813-11 METAL CHIP 220 5% 1/10W
R1022 1-216-813-11 METAL CHIP 220 5% 1/10W
R1023 1-216-813-11 METAL CHIP 220 5% 1/10W
R1029 1-216-809-11 METAL CHIP 100 5% 1/10W
R1030 1-216-837-11 METAL CHIP 22K 5% 1/10W
R1031 1-218-285-11 METAL CHIP 75 5% 1/10W
R1032 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1033 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R1034 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
< VIBRATOR >
X1002 1-795-153-11 VIBRATOR, CRYSTAL (14.31818 MHz)
************************************************************
CD-SW BOARD
************
< RESISTOR >
R1166 1-216-817-11 METAL CHIP 470 5% 1/10W
R1167 1-216-819-11 METAL CHIP 680 5% 1/10W
R1168 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1169 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R1170 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
< SWITCH >
S1166 1-762-875-21 SWITCH, KEYBOARD (Z OPEN/CLOSE)
S1167 1-762-875-21 SWITCH, KEYBOARD (EX-CHANGE/DISC SKIP)
S1168 1-762-875-21 SWITCH, KEYBOARD (DISC 3)
S1169 1-762-875-21 SWITCH, KEYBOARD (DISC 2)
S1170 1-762-875-21 SWITCH, KEYBOARD (DISC 1)
************************************************************
DRIVER BOARD
*************
< CAPACITOR >
C715 1-126-933-11 ELECT 100uF 20% 16V
C731 1-126-964-11 ELECT 10uF 20% 50V
C735 1-164-159-11 CERAMIC 0.1uF 50V
C736 1-164-159-11 CERAMIC 0.1uF 50V
C737 1-164-159-11 CERAMIC 0.1uF 50V
C741 1-162-306-11 CERAMIC 0.01uF 20% 16V
C751 1-162-306-11 CERAMIC 0.01uF 20% 16V
C752 1-164-159-11 CERAMIC 0.1uF 50V
< CONNECTOR >
CN701 1-784-735-11 CONNECTOR, FFC 13P
CN702 1-784-766-11 CONNECTOR, FFC 5P
* CN703 1-564-720-11 PIN, CONNECTOR (SMALL TYPE) 4P
CN704 1-785-328-11 PIN, CONNECTOR (LIGHT ANGRE) 2P
< DIODE >
D701 8-719-947-16 DIODE MTZJ-T-72-5.1A
D711 8-719-983-66 DIODE MTZJ-T-72-3.6B
< IC >
IC701 8-759-598-69 IC BA6956AN
IC712 8-759-598-69 IC BA6956AN
< TRANSISTOR >
Q731 8-729-029-66 TRANSISTOR DTC114ESA
< RESISTOR >
R701 1-249-413-11 CARBON 470 5% 1/4W
R702 1-247-807-31 CARBON 100 5% 1/4W
R711 1-247-831-91 CARBON 1K 5% 1/4W
R712 1-247-847-91 CARBON 4.7K 5% 1/4W
R713 1-247-863-91 CARBON 22K 5% 1/4W
CDG DRIVERCD-SW
