77
HCD-GNX780/GNX880
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
MAIN
* CN507 1-564-710-11 PIN, CONNECTOR (SMALL TYPE) 8P
* CN508 1-569-934-11 SOCKET, CONNECTOR 17P
CN509 1-569-928-11 SOCKET, CONNECTOR 11P
* CN510 1-568-449-11 HOUSING, CONNECTOR (PC BOARD) 3P
CN511 1-784-735-11 CONNECTOR, FFC 13P
CN512 1-779-285-11 CONNECTOR, FFC (LIF (NON-ZIF)) 17P
CN513 1-784-038-21 CONNECTOR, BOARD TO BOARD 9P (GNX880)
CN560 1-785-314-11 PIN, CONNECTOR (STRAIGHT) 2P
CN580 1-564-506-11 PLUG, CONNECTOR 3P
< DIODE >
D101 6-501-193-01 DIODE 1SS355WTE-17
D102 6-501-193-01 DIODE 1SS355WTE-17
D103 6-501-193-01 DIODE 1SS355WTE-17
D104 6-501-193-01 DIODE 1SS355WTE-17
D325 8-719-083-60 DIODE UDZSTE-174.7B
D340 6-501-193-01 DIODE 1SS355WTE-17
D341 6-501-193-01 DIODE 1SS355WTE-17
D342 6-501-193-01 DIODE 1SS355WTE-17
D401 6-501-193-01 DIODE 1SS355WTE-17
D402 6-501-193-01 DIODE 1SS355WTE-17
D403 6-501-193-01 DIODE 1SS355WTE-17
D404 6-501-193-01 DIODE 1SS355WTE-17
D501 6-501-193-01 DIODE 1SS355WTE-17
D502 6-501-193-01 DIODE 1SS355WTE-17
D503 6-501-193-01 DIODE 1SS355WTE-17
D504 6-501-193-01 DIODE 1SS355WTE-17
D505 6-501-193-01 DIODE 1SS355WTE-17
D550 6-501-193-01 DIODE 1SS355WTE-17
D560 8-719-028-23 DIODE D3SBA20-4101
D561 6-500-522-21 DIODE 10EDB40-TB3
D562 6-500-522-21 DIODE 10EDB40-TB3
D581 8-719-069-56 DIODE UDZSTE-176.2B
D583 8-719-978-33 DIODE DTZ-TT11-6.8B
D584 8-719-071-54 DIODE HZU2.0BTRF
< FERRITE BEAD >
FB150 1-216-864-11 SHORT CHIP 0
FB260 1-216-864-11 SHORT CHIP 0
FB261 1-216-864-11 SHORT CHIP 0
FB262 1-216-864-11 SHORT CHIP 0
FB263 1-216-864-11 SHORT CHIP 0
FB506 1-500-283-11 INDUCTOR, FERRITE BEAD
FB507 1-500-283-11 INDUCTOR, FERRITE BEAD
FB508 1-500-283-11 INDUCTOR, FERRITE BEAD
FB509 1-500-283-11 INDUCTOR, FERRITE BEAD
FB510 1-500-283-11 INDUCTOR, FERRITE BEAD
FB512 1-500-283-11 INDUCTOR, FERRITE BEAD
< IC >
IC101 6-703-650-11 IC M61529FP-D60G
IC201 6-703-651-11 IC M61530FP-D60G (GNX880)
IC210 6-600-465-11 IC TOTX147 (CD DIGITAL OUT OPTICAL)
IC301 6-702-130-01 IC HA12237F
IC401 6-806-610-01 IC M30622MEP-A75FPU0
IC402 6-705-809-01 IC BD4929G-TR
IC550 6-703-610-01 IC RT8H015C-T112-1
IC560 8-759-394-36 IC BA09T
IC561 8-759-394-36 IC BA09T
IC562 6-702-771-01 IC TA78033LS
< JACK >
J101 1-794-981-11 JACK, PIN 4P (AUDIO IN)
J103 1-820-048-11 CONNECTOR (LIGHTING) (D-LIGHT SYNC)
< JUMPER RESISTOR >
JR101 1-216-864-11 SHORT CHIP 0
JR102 1-216-864-11 SHORT CHIP 0
JR104 1-216-864-11 SHORT CHIP 0
JR107 1-216-864-11 SHORT CHIP 0
JR108 1-216-864-11 SHORT CHIP 0
JR109 1-216-864-11 SHORT CHIP 0
JR110 1-216-864-11 SHORT CHIP 0
JR112 1-216-864-11 SHORT CHIP 0
JR113 1-216-864-11 SHORT CHIP 0
JR114 1-216-864-11 SHORT CHIP 0
JR115 1-216-864-11 SHORT CHIP 0
JR116 1-216-864-11 SHORT CHIP 0
JR117 1-216-864-11 SHORT CHIP 0
JR119 1-216-864-11 SHORT CHIP 0
JR120 1-216-864-11 SHORT CHIP 0
JR121 1-216-864-11 SHORT CHIP 0
JR122 1-216-864-11 SHORT CHIP 0
JR123 1-216-864-11 SHORT CHIP 0
JR124 1-216-296-11 SHORT CHIP 0
JR125 1-216-296-11 SHORT CHIP 0
JR126 1-216-296-11 SHORT CHIP 0
JR127 1-216-864-11 SHORT CHIP 0
JR129 1-216-864-11 SHORT CHIP 0
JR130 1-216-864-11 SHORT CHIP 0
JR131 1-216-864-11 SHORT CHIP 0
< COIL >
L101 1-420-872-52 COIL, AIR-CORE (GNX880)
L102 1-420-872-52 COIL, AIR-CORE (GNX880)
L302 1-414-189-31 INDUCTOR 100uH
L370 1-410-780-11 INDUCTOR 27mH
L371 1-410-780-11 INDUCTOR 27mH
L372 1-414-189-31 INDUCTOR 100uH
< TRANSISTOR >
Q101 8-729-230-49 TRANSISTOR 2SC2712-YG
Q151 8-729-230-49 TRANSISTOR 2SC2712-YG
Q180 8-729-023-22 TRANSISTOR 2SD2114K
Q181 8-729-023-22 TRANSISTOR 2SD2114K
Q250 8-729-023-22 TRANSISTOR 2SD2114K
Q251 8-729-023-22 TRANSISTOR 2SD2114K
Q325 8-729-056-46 TRANSISTOR 2SC5053T100Q
Q340 8-729-903-46 TRANSISTOR 2SB1132-P
Q341 8-729-903-46 TRANSISTOR 2SB1132-P
Q342 8-729-903-46 TRANSISTOR 2SB1132-P
Q343 8-729-027-43 TRANSISTOR DTC114EKA-T146
Q344 8-729-027-43 TRANSISTOR DTC114EKA-T146
Q345 8-729-027-43 TRANSISTOR DTC114EKA-T146
Q370 8-729-141-75 TRANSISTOR 2SD596DV345
Q371 6-551-287-01 TRANSISTOR 2SD2704K-T146
Ver. 1.1
To Next Page
