Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
65
HCD-GPZ6/GPZ7
AU-TC
C211 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C212 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C213 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C214 1-126-964-11 ELECT 10uF 20% 50V
C215 1-126-964-11 ELECT 10uF 20% 50V
C216 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C217 1-126-964-11 ELECT 10uF 20% 50V
C220 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C221 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C222 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C223 1-165-128-11 CERAMIC CHIP 0.22uF 16V
C224 1-126-947-11 ELECT 47uF 20% 35V
C225 1-126-965-11 ELECT 22uF 20% 50V
C227 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C317 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C324 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C328 1-126-933-11 ELECT 100uF 20% 16V
C360 1-130-479-00 MYLAR 0.0047uF 5% 50V
C361 1-130-479-00 MYLAR 0.0047uF 5% 50V
C362 1-130-487-00 MYLAR 0.022uF 5% 50V
C363 1-130-483-00 MYLAR 0.01uF 5% 50V
C368 1-126-947-11 ELECT 47uF 20% 35V
C371 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C372 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C374 1-130-483-00 MYLAR 0.01uF 5% 50V
C375 1-126-965-11 ELECT 22uF 20% 50V
C381 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C382 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C383 1-126-935-11 ELECT 470uF 20% 16V
C384 1-126-935-11 ELECT 470uF 20% 16V
C385 1-104-665-11 ELECT 100uF 20% 25V
< CONNECTOR >
* CN301 1-564-510-11 PLUG, CONNECTOR 7P
< DIODE >
D318 8-719-063-79 DIODE 1N4002B
D331 8-719-988-61 DIODE 1SS355TE-17
< EARTH TERMINAL >
EP301 1-537-770-21 TERMINAL BOARD, GROUND
< IC >
IC302 6-708-013-01 IC BD3402AKS2
< JUMPER RESISTOR >
JR301 1-216-864-11 SHORT CHIP 0
JR302 1-216-864-11 SHORT CHIP 0
< TRANSISTOR >
Q101 8-729-920-31 TRANSISTOR DTC343TK
Q103 8-729-920-31 TRANSISTOR DTC343TK
Q104 8-729-920-31 TRANSISTOR DTC343TK
Q201 8-729-920-31 TRANSISTOR DTC343TK
Q203 8-729-920-31 TRANSISTOR DTC343TK
Q204 8-729-920-31 TRANSISTOR DTC343TK
Q306 8-729-600-22 TRANSISTOR 2SA1235-F
Q307 8-729-027-43 TRANSISTOR DTC114EKA-T146
Q321 8-729-028-54 TRANSISTOR KTC3205
Q322 8-729-027-43 TRANSISTOR DTC114EKA-T146
Q323 8-729-027-31 TRANSISTOR DTA124EKA-T146
< RESISTOR >
R103 1-216-833-11 METAL CHIP 10K 5% 1/10W
R104 1-216-833-11 METAL CHIP 10K 5% 1/10W
R105 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R106 1-216-841-11 METAL CHIP 47K 5% 1/10W
R107 1-216-841-11 METAL CHIP 47K 5% 1/10W
R108 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R109 1-216-849-11 METAL CHIP 220K 5% 1/10W
R110 1-216-853-11 METAL CHIP 470K 5% 1/10W
R111 1-216-813-11 METAL CHIP 220 5% 1/10W
R112 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R113 1-216-845-11 METAL CHIP 100K 5% 1/10W
R114 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R115 1-216-821-11 METAL CHIP 1K 5% 1/10W
(GPZ6: UK, SP, KR, AUS/GPZ7: AEP, EE, RU)
R115 1-216-864-11 SHORT CHIP 0
(GPZ6: AR/GPZ7: E, E51, MX, AR)
R116 1-216-841-11 METAL CHIP 47K 5% 1/10W
R117 1-216-821-11 METAL CHIP 1K 5% 1/10W
R119 1-216-821-11 METAL CHIP 1K 5% 1/10W
R126 1-216-837-11 METAL CHIP 22K 5% 1/10W
R127 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R129 1-216-845-11 METAL CHIP 100K 5% 1/10W
R131 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R132 1-216-837-11 METAL CHIP 22K 5% 1/10W
R133 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R134 1-216-809-11 METAL CHIP 100 5% 1/10W
R135 1-216-833-11 METAL CHIP 10K 5% 1/10W
R136 1-216-821-11 METAL CHIP 1K 5% 1/10W
R203 1-216-833-11 METAL CHIP 10K 5% 1/10W
R204 1-216-833-11 METAL CHIP 10K 5% 1/10W
R205 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R206 1-216-841-11 METAL CHIP 47K 5% 1/10W
R207 1-216-841-11 METAL CHIP 47K 5% 1/10W
R208 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R209 1-216-849-11 METAL CHIP 220K 5% 1/10W
R210 1-216-853-11 METAL CHIP 470K 5% 1/10W
R211 1-216-813-11 METAL CHIP 220 5% 1/10W
R212 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R213 1-216-845-11 METAL CHIP 100K 5% 1/10W
R214 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R215 1-216-821-11 METAL CHIP 1K 5% 1/10W
(GPZ6: UK, SP, KR, AUS/GPZ7: AEP, EE, RU)
R215 1-216-864-11 SHORT CHIP 0
(GPZ6: AR/GPZ7: E, E51, MX, AR)
R216 1-216-841-11 METAL CHIP 47K 5% 1/10W
R217 1-216-821-11 METAL CHIP 1K 5% 1/10W
R219 1-216-821-11 METAL CHIP 1K 5% 1/10W
R226 1-216-837-11 METAL CHIP 22K 5% 1/10W
R227 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R229 1-216-845-11 METAL CHIP 100K 5% 1/10W
Ver. 1.1
