HCD-GX470/GX570
10
Note: Follow the disassembly procedure in the numerical order given.
3-2. CASE (SIDE-L), CASE (SIDE-R)
3-3. CASE (TOP)
4
three screws
(case 3 TP2)
1
three screws
(case 3 TP2)
5
two screw
s
(B3)
2
two screws
(B3)
3
case (side-L)
6
case (side-R)
1
two screws
(B3)
3
2
Open the case (top).
2
Open the case (top).
2
Open the case (top).
5
case (top)
4
four claws
