HCD-GX470/GX570
14
3-11. DRIVE BOARD, SW BOARD
3-10. CD BOARD
5
CD
board
4
Remove soldering from the four points.
3
flexible flat cable (16 core
)
(CN101)
1
two screws
(BVTP2.6
×
8)
2
cover (OP)
3
connector
(CN703)
4
DRIVER
board
6
SW board
2
wire (flat type) (5 core)
(CN702)
1
two
screws
(BTTP (M2.6))
5
screw
(BTTP (M2.6))
