HCD-GX470/GX570
16
3-14. MOTOR (TB) BOARD
6
Remove the two solderings of motor.
8
MOTOR (TB) board
7
t
able motor assy (M741)
5
two
screws
(BTTP (M2.6))
4
3
wire (flat type) (5 core) (CN742)
1
stopper
2
stopper
3
Remove the two solderings of motor.
4
MOTOR (LD) board
1
b
elt (loading)
5
l
oading motor assy (M751)
2
two
screws
(BTTP (M2.6))
3-15. MOTOR (LD) BOARD
