• This set can be disassembled in the order shown below.
3-1. DISASSEMBLY FLOW
SECTION 3
DISASSEMBLY
SET
3-2. CASE (SIDE-L), CASE (SIDE-R)
(Page 10)
3-3. CASE (TOP)
(Page 10)
3-4. LID (CD)
(Page 10)
3-9. MAIN BOARD
(Page 13)
3-14. MOTOR (TB) BOARD
(Page 15)
3-15. MOTOR (LD) BOARD
(Page 16)
3-11. DRIVER BOARD,
SW BOARD
(Page 14)
3-6. FRONT PANEL BLOCK
(Page 11)
3-7. MECHANICAL DECK
(CWM42FF609)
(Page 11)
3-5. CD MECHANISM DECK
(CDM74KF-K6BD83S)
(Page 12)
3-10. CD BOARD
(Page 13)
3-12. OPTICAL PICK-UP BLOCK
(Page 14)
3-13. SENSOR BOARD
(Page 15)
3-8. BACK PANEL SECTION
(Page 12)
