Sony HCD-GX570 - Cd Deck Receiver Component User Manual

Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
77
HCD-GX470/GX570
C260 1-124-261-00 ELECT 10uF 20% 25V
C263 1-126-935-11 ELECT 470uF 20% 16V
C264 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C265 1-126-963-11 ELECT 4.7uF 20% 50V
C266 1-126-963-11 ELECT 4.7uF 20% 50V
C267 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C268 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C271 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C273 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C274 1-124-261-00 ELECT 10uF 20% 25V
C275 1-164-362-11 CERAMIC CHIP 470PF 5% 50V
C276 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C278 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C281 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C305 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C308 1-126-963-11 ELECT 4.7uF 20% 50V
(GX570)
C309 1-126-963-11 ELECT 4.7uF 20% 50V
(GX570)
C310 1-164-156-11 CERAMIC CHIP 0.1uF 25V
(GX570)
C311 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
(GX570)
C312 1-107-726-91 CERAMIC CHIP 0.01uF 10% 16V
(GX570)
C313 1-126-934-11 ELECT 220uF 20% 16V
(GX570)
C317 1-126-926-11 ELECT 1000uF 20% 10V
C331 1-126-960-11 ELECT 1uF 20% 50V
(GX570)
C332 1-126-960-11 ELECT 1uF 20% 50V
(GX570)
C385 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C386 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C387 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C388 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C391 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C901 1-126-933-11 ELECT 100uF 20% 16V
C902 1-126-964-11 ELECT 10uF 20% 50V
C903 1-126-959-11 ELECT 0.47uF 20% 50V
C904 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C906 1-126-964-11 ELECT 10uF 20% 50V
C908 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C909 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C910 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C911 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C912 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C913 1-162-905-11 CERAMIC CHIP 1PF 0.25PF 50V
C914 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C916 1-114-154-11 DOUBLE LAYER 47000uF 5.5V
C917 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C918 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C919 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C920 1-162-905-11 CERAMIC CHIP 1PF 0.25PF 50V
C921 1-126-961-11 ELECT 2.2uF 20% 50V
C922 1-126-963-11 ELECT 4.7uF 20% 50V
C923 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C926 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C927 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
< CONNECTOR >
* CN031 1-573-094-11 SOCKET, CONNECTOR 13P
CN041 1-819-131-11 PIN, CONNECTOR 3P
CN061 1-568-828-11 CONNECTOR, FFC 9P
CN091 1-568-828-11 CONNECTOR, FFC 9P
CN201 1-568-830-11 CONNECTOR, FFC 11P
CN301 1-779-291-11 CONNECTOR, FFC (LIF (NON-ZIF)) 23P
* CN333 1-691-047-21 HOUSING, CONNECTOR 15P (GX570)
CN991 1-784-780-11 CONNECTOR, FFC 19P
< DIODE >
D001 6-500-522-21 DIODE 10EDB40-TB3
D002 6-500-522-21 DIODE 10EDB40-TB3
D003 6-500-522-21 DIODE 10EDB40-TB3
D004 6-500-522-21 DIODE 10EDB40-TB3
D005 8-719-085-36 DIODE 11EQS04-TB5 (GX570)
D006 8-719-988-61 DIODE 1SS355TE-17
D007 6-501-166-01 DIODE UDZW-TE17-4.7B
D008 8-719-000-08 DIODE MC2838
D009 6-500-335-01 DIODE MC2838-T112-1
D011 6-500-522-21 DIODE 10EDB40-TB3
D012 6-500-522-21 DIODE 10EDB40-TB3
D013 6-500-522-21 DIODE 10EDB40-TB3
D014 6-500-522-21 DIODE 10EDB40-TB3
D021 6-500-522-21 DIODE 10EDB40-TB3
D022 6-500-522-21 DIODE 10EDB40-TB3
D023 6-500-522-21 DIODE 10EDB40-TB3
D024 6-500-522-21 DIODE 10EDB40-TB3
D031 8-719-988-61 DIODE 1SS355TE-17
D035 8-719-000-08 DIODE MC2838
D036 8-719-000-07 DIODE MC2836
D301 6-500-522-21 DIODE 10EDB40-TB3
D302 6-500-522-21 DIODE 10EDB40-TB3
D901 6-501-166-01 DIODE UDZW-TE17-4.7B
D902 8-719-000-07 DIODE MC2836
D905 8-719-988-61 DIODE 1SS355TE-17
D910 8-719-988-61 DIODE 1SS355TE-17
D921 6-500-848-01 DIODE MC2840-T112-1
D923 6-500-848-01 DIODE MC2840-T112-1
D943 8-719-000-08 DIODE MC2838
D947 8-719-988-61 DIODE 1SS355TE-17
< IC >
IC006 6-702-771-01 IC TA78033LS
IC007 6-703-547-01 IC TA7805LS (GX570)
IC011 8-759-701-59 IC NJM78M09FA
IC021 8-759-701-59 IC NJM78M09FA
IC101 6-709-331-01 IC R2S15207FP
IC251 8-759-909-71 IC BA4558F
IC301 6-707-282-01 IC MM1615ANLE (GX570)
IC901 6-808-127-01 IC uPD78F0547GC-RGXMA-UBT-A
(for SERVICE) (GX570)
IC901 6-808-402-01 IC uPD78F0547GC-RGSTDA-UBT-A
(for SERVICE) (GX470)
IC902 8-759-713-61 IC PST3429UL
MAIN
Ver. 1.3
