Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
81
HCD-GX470/GX570
R978 1-216-809-11 METAL CHIP 100 5% 1/10W
(GX570)
R979 1-216-809-11 METAL CHIP 100 5% 1/10W
R980 1-216-809-11 METAL CHIP 100 5% 1/10W
R981 1-216-809-11 METAL CHIP 100 5% 1/10W
R982 1-216-817-11 METAL CHIP 470 5% 1/10W
R996 1-216-809-11 METAL CHIP 100 5% 1/10W
R997 1-216-809-11 METAL CHIP 100 5% 1/10W
R999 1-216-809-11 METAL CHIP 100 5% 1/10W
< VIBRATOR >
X901 1-579-463-11 VIBRATOR, CRYSTAL (32.768kHz)
X902 1-795-482-11 VIBRATOR, CERAMIC (16MHz)
************************************************************
A-1159-739-A MIC. AUX. HP BOARD, COMPLETE
***************************
< CAPACITOR >
C781 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C782 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C783 1-165-621-11 CERAMIC CHIP 0.1uF 50V
C784 1-165-621-11 CERAMIC CHIP 0.1uF 50V
C820 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C821 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
< EARTH TERMINAL >
* EP701 1-537-738-21 TERMINAL, EARTH
< JACK >
J701 1-794-702-11 JACK, HEADPHONE (PHONES)
J702 1-794-702-11 JACK, HEADPHONE (AUDIO IN)
< RESISTOR >
R823 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R824 1-216-837-11 METAL CHIP 22K 5% 1/10W
R825 1-216-821-11 METAL CHIP 1K 5% 1/10W
R826 1-216-821-11 METAL CHIP 1K 5% 1/10W
R827 1-216-833-11 METAL CHIP 10K 5% 1/10W
R831 1-216-853-11 METAL CHIP 470K 5% 1/10W
R832 1-216-853-11 METAL CHIP 470K 5% 1/10W
************************************************************
1-687-133-12 MOTOR (LD) BOARD
*****************
************************************************************
1-687-134-12 MOTOR (TB) BOARD
****************
< CONNECTOR >
CN742 1-784-727-11 CONNECTOR, FFC 5P
************************************************************
A-1163-173-A PANEL BOARD, COMPLETE
**********************
2-658-282-01 GUIDE, FL
< CAPACITOR >
C621 1-126-961-11 ELECT 2.2uF 20% 50V
C622 1-126-961-11 ELECT 2.2uF 20% 50V
C625 1-128-131-11 ELECT 22uF 20% 50V
C631 1-126-947-11 ELECT 47uF 20% 35V
C641 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C642 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C701 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C702 1-126-947-11 ELECT 47uF 20% 35V
C703 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C704 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C705 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C707 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C708 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C709 1-126-947-11 ELECT 47uF 20% 35V
C710 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C711 1-165-621-11 CERAMIC CHIP 0.1uF 50V
C712 1-126-965-11 ELECT 22uF 20% 50V
< CONNECTOR >
CN601 1-784-780-11 CONNECTOR, FFC 19P
< DIODE >
D711 8-719-000-07 DIODE MC2836
< FLUORESCENT INDICATOR >
FL701 1-519-871-11 INDICATOR TUBE, FLUORESCENT
< IC >
IC610 6-600-446-01 IC RPM7240-H18
IC701 6-806-287-01 IC uPD780232GC-509-8BT-A
< JUMPER RESISTOR >
JR602 1-216-864-11 SHORT CHIP 0
JR603 1-216-864-11 SHORT CHIP 0
JR604 1-216-864-11 SHORT CHIP 0
JR605 1-216-864-11 SHORT CHIP 0
JR606 1-216-864-11 SHORT CHIP 0
JR607 1-216-864-11 SHORT CHIP 0
JR608 1-216-864-11 SHORT CHIP 0
JR609 1-216-864-11 SHORT CHIP 0
JR610 1-216-864-11 SHORT CHIP 0
JR611 1-216-864-11 SHORT CHIP 0
JR612 1-216-864-11 SHORT CHIP 0
JR613 1-216-864-11 SHORT CHIP 0
JR614 1-216-864-11 SHORT CHIP 0
< TRANSISTOR >
Q621 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q701 6-551-276-01 TRANSISTOR RT1N431C-TP-1
Q702 6-551-276-01 TRANSISTOR RT1N431C-TP-1
Q703 6-551-276-01 TRANSISTOR RT1N431C-TP-1
Q704 8-729-040-76 TRANSISTOR KTA1273-Y-AT
Q705 8-729-037-13 TRANSISTOR KTA1271Y
Q706 8-729-037-13 TRANSISTOR KTA1271Y
MAIN MIC. AUX. HP MOTOR (LD) MOTOR (TB) PANEL
