Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
86
HCD-GX470/GX570
R002 1-216-845-11 METAL CHIP 100K 5% 1/10W
R003 1-216-845-11 METAL CHIP 100K 5% 1/10W
R004 1-216-845-11 METAL CHIP 100K 5% 1/10W
R005 1-216-845-11 METAL CHIP 100K 5% 1/10W
R006 1-216-845-11 METAL CHIP 100K 5% 1/10W
R007 1-216-833-11 METAL CHIP 10K 5% 1/10W
R008 1-216-821-11 METAL CHIP 1K 5% 1/10W
R009 1-216-821-11 METAL CHIP 1K 5% 1/10W
R010 1-216-809-11 METAL CHIP 100 5% 1/10W
R011 1-216-809-11 METAL CHIP 100 5% 1/10W
R012 1-216-845-11 METAL CHIP 100K 5% 1/10W
R014 1-216-809-11 METAL CHIP 100 5% 1/10W
R015 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R016 1-216-817-11 METAL CHIP 470 5% 1/10W
R017 1-216-809-11 METAL CHIP 100 5% 1/10W
R018 1-216-809-11 METAL CHIP 100 5% 1/10W
R019 1-216-809-11 METAL CHIP 100 5% 1/10W
R020 1-216-837-11 METAL CHIP 22K 5% 1/10W
R021 1-216-809-11 METAL CHIP 100 5% 1/10W
R022 1-216-809-11 METAL CHIP 100 5% 1/10W
R023 1-216-809-11 METAL CHIP 100 5% 1/10W
R024 1-216-809-11 METAL CHIP 100 5% 1/10W
R025 1-216-809-11 METAL CHIP 100 5% 1/10W
R026 1-216-809-11 METAL CHIP 100 5% 1/10W
R031 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R032 1-216-841-11 METAL CHIP 47K 5% 1/10W
R033 1-216-841-11 METAL CHIP 47K 5% 1/10W
R034 1-216-841-11 METAL CHIP 47K 5% 1/10W
R035 1-216-841-11 METAL CHIP 47K 5% 1/10W
R036 1-216-833-11 METAL CHIP 10K 5% 1/10W
R037 1-216-833-11 METAL CHIP 10K 5% 1/10W
R051 1-216-841-11 METAL CHIP 47K 5% 1/10W
R052 1-216-841-11 METAL CHIP 47K 5% 1/10W
R055 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R056 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R057 1-216-828-11 METAL CHIP 3.9K 5% 1/10W
R065 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R066 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R067 1-216-828-11 METAL CHIP 3.9K 5% 1/10W
< VIBRATOR >
X001 1-760-841-11 VIBRATOR, CRYSTAL (45.158MHz)
************************************************************
MISCELLANEOUS
**************
61 1-831-952-21 CABLE, FLEXIBLE FLAT (19 CORE)
62 1-831-779-21 CABLE, FLEXIBLE FLAT (11 CORE)
158 1-417-656-21 MECHA DECK (CWN42FF609)
168 1-831-772-21 CABLE, FLEXIBLE FLAT (9 CORE)
204 1-693-713-11 TUNER (FM/AM)
205 1-831-769-21 CABLE, FLEXIBLE FLAT (9 CORE)
206 1-831-786-21 CABLE, FLEXIBLE FLAT (13 CORE)
208 1-831-771-21 CABLE, FLEXIBLE FLAT (23 CORE)
212 1-832-848-21 WIRE (FLAT TYPE) (15 CORE) (GX570)
303 1-831-928-21 CABLE, FLEXIBLE FLAT (11 CORE)
0 306 1-830-190-11 CORD, POWER
502 1-828-938-51 WIRE (FLAT TYPE) (5 CORE)
XM
576 1-832-404-21 CABLE, FLEXIBLE FLAT (16 CORE)
0 579 A-4735-357-A OPTICAL PICK-UP BLOCK (KSM-213DHAP)
(including spindle motor (M401),
sled motor (M402))
580 1-471-035-21 MAGNET ASSY
0 F904 1-533-949-33 FUSE, CYLINDRICAL (TIME LUG) (T8AL/250V)
0 F905 1-533-949-33 FUSE, CYLINDRICAL (TIME LUG) (T8AL/250V)
0 F906 1-532-465-33 FUSE (T3.15AL/250V)
0 F907 1-532-465-33 FUSE (T3.15AL/250V)
M001 1-787-344-11 FAN, DC
M741 A-1108-965-A MOTOR ASSY, TABLE
M751 A-1108-966-A MOTOR ASSY, LOADING
0 PT901 1-443-924-11 TRANSFORMER, POWER (GX470)
0 PT901 1-443-925-11 TRANSFORMER, POWER (GX570)
S101 1-771-853-11 SWITCH, DETECTION (LIMIT)
S711 1-477-680-12 ENCODER, ROTARY
(DISC TABLE ADDRESS DETECT)
