5
HCD-GX470/GX570
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
A-1171-482-A DECK BOARD, COMPLETE
*********************
< CAPACITOR/RESISTOR >
C301 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C302 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C303 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C304 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C305 1-216-849-11 METAL CHIP 220K 5% 1/10W
C306 1-216-849-11 METAL CHIP 220K 5% 1/10W
C307 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C315 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C316 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C317 1-126-964-11 ELECT 10uF 20% 50V
C318 1-126-964-11 ELECT 10uF 20% 50V
C323 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C324 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C325 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C326 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C327 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C328 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C329 1-136-161-00 MYLAR 0.047uF 5% 50V
C330 1-136-161-00 MYLAR 0.047uF 5% 50V
C350 1-126-934-11 ELECT 220uF 20% 16V
C351 1-126-934-11 ELECT 220uF 20% 16V
C352 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C353 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C354 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C355 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C356 1-126-964-11 ELECT 10uF 20% 50V
C401 1-126-956-11 ELECT 0.1uF 20% 50V
C402 1-126-956-11 ELECT 0.1uF 20% 50V
C403 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C404 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C405 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C406 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C409 1-126-964-11 ELECT 10uF 20% 50V
C410 1-126-964-11 ELECT 10uF 20% 50V
C411 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V
C412 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V
C413 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C414 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C415 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C416 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
3. ELECTRICAL PARTS LIST
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX and -X mean standardized parts, so they
may have some difference from the original
one.
• RESISTORS
All resistors are in ohms.
METAL: Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F: nonflammable
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when
ordering these items.
• SEMICONDUCTORS
In each case, u: µ, for example:
uA... : µA... uPA... : µPA...
uPB... : µPB... uPC... : µPC...
uPD... : µPD...
• CAPACITORS
uF: µF
• COILS
uH: µH
DECK
C417 1-107-726-91 CERAMIC CHIP 0.01uF 10% 16V
C418 1-107-726-91 CERAMIC CHIP 0.01uF 10% 16V
C430 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C431 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C433 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C452 1-126-947-11 ELECT 47uF 20% 35V
C453 1-130-471-00 MYLAR 0.001uF 5% 50V
C454 1-130-479-00 MYLAR 0.0047uF 5% 50V
C456 1-130-483-00 MYLAR 0.01uF 5% 50V
C458 1-130-475-00 MYLAR 0.0022uF 5% 50V
C460 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C461 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C462 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
< CONNECTOR >
CN008 1-568-830-11 CONNECTOR, FFC 11P
CN301 1-815-444-11 PIN, CONNECTOR (PWB) 3P
CN302 1-815-449-11 PIN, CONNECTOR (PWB) 8P
< DIODE >
D301 6-501-165-01 DIODE UDZW-TE17-4.3B
D401 6-500-335-01 DIODE MC2838-T112-1
< JUMPER RESISTOR >
FB301 1-216-864-11 SHORT CHIP 0
< IC >
IC301 6-702-457-01 IC NJM14558M-TE2
IC401 8-759-909-71 IC BA4558F
< JUMPER RESISTOR >
JR301 1-216-864-11 SHORT CHIP 0
JR302 1-216-864-11 SHORT CHIP 0
JR306 1-216-864-11 SHORT CHIP 0
JR307 1-216-864-11 SHORT CHIP 0
JR310 1-216-864-11 SHORT CHIP 0
JR311 1-216-864-11 SHORT CHIP 0
JR402 1-216-864-11 SHORT CHIP 0
JR404 1-216-864-11 SHORT CHIP 0
< TRANSFORMER >
L451 1-443-760-11 TRANSFORMER, BIAS OSCILLATION
When indicating parts by reference
number, please include the board.
