7
HCD-GX470/GX570
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
A-1159-681-A KEY RIGHT BOARD, COMPLETE
**************************
< CAPACITOR >
C643 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C644 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
< RESISTOR >
R682 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R683 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R684 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R685 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R686 1-216-833-11 METAL CHIP 10K 5% 1/10W
R687 1-216-837-11 METAL CHIP 22K 5% 1/10W
R688 1-216-841-11 METAL CHIP 47K 5% 1/10W
< SWITCH >
S624 1-762-875-21 SWITCH, KEYBOARD (ENTER)
S631 1-762-875-21 SWITCH, KEYBOARD (EQ BAND)
S632 1-762-875-21 SWITCH, KEYBOARD (SURRROUND)
S633 1-762-875-21 SWITCH, KEYBOARD (GROOVE)
S634 1-762-875-21 SWITCH, KEYBOARD (DISC A)
S635 1-762-875-21 SWITCH, KEYBOARD (DISC SKIP/EX-CHANGE)
S636 1-762-875-21 SWITCH, KEYBOARD (DISC 3)
S637 1-762-875-21 SWITCH, KEYBOARD (DISC 2)
S638 1-762-875-21 SWITCH, KEYBOARD (DISC 1)
S672 1-786-418-11 SWITCH, ROTARY (ENCODER) (MULTI JOG)
************************************************************
A-1163-189-A MAIN BOARD, COMPLETE (GX570)
A-1163-190-A MAIN BOARD, COMPLETE (GX470)
*********************
7-685-872-01 SCREW +BVTT 3X8 (S)
< CAPACITOR >
C001 1-136-497-81 FILM 0.1uF 5% 50V
C002 1-136-497-81 FILM 0.1uF 5% 50V
C006 1-126-964-11 ELECT 10uF 20% 50V
C007 1-126-965-11 ELECT 22uF 20% 50V
C008 1-126-943-11 ELECT 2200uF 20% 25V
C010 1-165-621-11 CERAMIC CHIP 0.1uF 50V
C011 1-136-497-81 FILM 0.1uF 5% 50V
C012 1-136-497-81 FILM 0.1uF 5% 50V
C013 1-126-943-11 ELECT 2200uF 20% 25V
3. ELECTRICAL PARTS LIST
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX and -X mean standardized parts, so they
may have some difference from the original
one.
• RESISTORS
All resistors are in ohms.
METAL: Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F: nonflammable
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when
ordering these items.
• SEMICONDUCTORS
In each case, u: µ, for example:
uA... : µA... uPA... : µPA...
uPB... : µPB... uPC... : µPC...
uPD... : µPD...
• CAPACITORS
uF: µF
• COILS
uH: µH
KEY RIGHT MAIN
C015 1-126-933-11 ELECT 100uF 20% 16V
C023 1-126-943-11 ELECT 2200uF 20% 25V
C025 1-126-933-11 ELECT 100uF 20% 16V
C026 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C027 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C029 1-126-964-11 ELECT 10uF 20% 50V
(GX570)
C030 1-126-933-11 ELECT 100uF 20% 16V
(GX570)
C031 1-216-864-11 SHORT CHIP 0
C032 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C033 1-126-933-11 ELECT 100uF 20% 16V
C034 1-126-963-11 ELECT 4.7uF 20% 50V
C035 1-126-947-11 ELECT 47uF 20% 35V
C063 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C064 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C065 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C066 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C068 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C069 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C109 1-126-964-11 ELECT 10uF 20% 50V
C110 1-126-964-11 ELECT 10uF 20% 50V
C111 1-126-965-11 ELECT 22uF 20% 50V
C112 1-126-947-11 ELECT 47uF 20% 35V
C114 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C115 1-126-933-11 ELECT 100uF 20% 16V
C116 1-126-960-11 ELECT 1uF 20% 50V
C117 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C118 1-126-961-11 ELECT 2.2uF 20% 50V
C119 1-126-961-11 ELECT 2.2uF 20% 50V
C120 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C121 1-126-933-11 ELECT 100uF 20% 16V
C122 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C123 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C124 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C125 1-126-960-11 ELECT 1uF 20% 50V
C126 1-126-960-11 ELECT 1uF 20% 50V
C129 1-126-960-11 ELECT 1uF 20% 50V
C130 1-126-960-11 ELECT 1uF 20% 50V
C137 1-126-960-11 ELECT 1uF 20% 50V
C138 1-126-960-11 ELECT 1uF 20% 50V
C139 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C140 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
Les composants identifiés par une
marque 0 sont critiquens pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
The components identified by mark
0 or dotted line with mark 0 are
critical for safety.
Replace only with part number
specified.
When indicating parts by reference
number, please include the board.
To Next Page
