5
HCD-L1
SECTION 2
GENERAL
This section is extracted
from instruction manual.
List of Button Locations and Reference Pages
How to use this page
Use this page to find the location of buttons and other
parts of the system that are mentioned in the text.
Main unit
ALPHABETICAL ORDER
A – F
CD cover 2 (11)
CD u 7 (11 - 13)
CD x 8 (11, 12)
DISPLAY 6 (17, 20, 21)
Display 1 (20, 21)
FUNCTION qa (11 - 14, 16, 23,
25)
P – Z
PHONES jack qf
PLAY MODE/TUNING MODE
qd (11 - 16, 25)
Remote sensor qg
TUNER/BAND 9 (15, 16, 25)
TUNING +/– qs (15, 16)
VOL +/– (19)
Illustration number
PLAY MODE qg (9, 13, 14)
RR
Name of button/part Reference page
12 3
6789
q;qaqd
qg
qf
5
BUTTON DESCRIPTIONS
/1? (power) 4 (8, 19)
./> qs (11 - 13)
m/M qs (11)
Z 3 (11)
V OPEN 5
To open the front cover, push
down on V OPEN.
q;
4
qs
