Sony HCD-L1 - Disassembly Procedures; Exterior Component Disassembly

9
HCD-L1
Note : Follow the disassembly procedure in the numerical order given.
3-1. Bottom Plate,Case
3-2. Front Panel Section
1 five screws (+BVTP 3 × 8 )
2 three screws (+BVTP 2.6 × 8)
7 s crew (+PTT 3 × 6 )
9 s crew (+PTT 3 × 6 )
5 f our screws (SS)
6 t wo screws (SS)
q; t wo screws (+PTT 3 × 6 )
qa t wo screws
(+PTT 3
× 6 )
8 t wo screws (SS)
4 b ottom plate
3 earth plate
qd three claws
qg case
qs
qf
c onnector
(CN801)
4 two screws (+BVTP 2.6 × 8)
8 c onnector (CN401)
1 earth plate
9 c onnector (CN1201)
q; c onnector
(CN1321)
6 flat type wire (13 core)
7 f lat type wire (11 core)
5 c hassis section
qa Front panel section
3 t wo screws (+BVTP 2.6 × 8)
2 screw (+BVTP 3 × 8
)
