Sony HCD-L1 - Page 63

Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
63
HCD-L1
L. MOTOR
1-683-915-12 L.MOTOR BOARD
***************
< CAPACITOR >
C711 1-126-791-11 ELECT 10uF 20.00% 16V
C715 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
< CONNECTOR >
CN711 1-785-330-11 PIN, CONNECTOR (LIGHT ANGLE)4P
< DIODE >
D711 8-719-083-57 DIODE UDZSTE-173.6B
< IC >
IC711 8-759-598-69 IC BA6956AN
< RESISTOR >
R711 1-216-815-11 METAL CHIP 330 5% 1/16W
R712 1-216-805-11 METAL CHIP 47 5% 1/16W
************************************************************
1-683-913-12 L.SENSOR BOARD
***************
< IC >
IC721 8-749-017-45 SENSOR, PHONT RPR-220C1N
< RESISTOR >
R721 1-216-815-11 METAL CHIP 330 5% 1/16W
R722 1-216-815-11 METAL CHIP 330 5% 1/16W
************************************************************
A-4728-124-A MAIN BOARD, COMPLETE (SP)
**************************
A-4728-100-A MAIN BOARD, COMPLETE (AEP,UK)
*****************************
A-4728-120-A MAIN BOARD, COMPLETE (US,CND)
*****************************
< CAPACITOR >
C500 1-126-916-11 ELECT 1000uF 20.00% 6.3V
C501 1-125-623-11 DOUBLE LAYER 0.22F 5.5V
C503 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C504 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C506 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C507 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C508 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C509 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C510 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C523 1-162-971-11 CERAMIC CHIP 0.001uF 10.00% 50V
C524 1-162-971-11 CERAMIC CHIP 0.001uF 10.00% 50V
C525 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C534 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C535 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C536 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C537 1-126-960-11 ELECT 1uF 20.00% 50V
C538 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C539 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C540 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C558 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C574 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C576 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C577 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C578 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C579 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C582 1-126-960-11 ELECT 1uF 20.00% 50V
C583 1-107-726-11 CERAMIC CHIP 0.01uF 10% 16V
C591 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C593 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C700 1-162-971-11 CERAMIC CHIP 0.001uF 10.00% 50V
C701 1-162-953-11 CERAMIC CHIP 100PF 5% 50V
C702 1-126-964-11 ELECT 10uF 20.00% 50V
C703 1-162-953-11 CERAMIC CHIP 100PF 5% 50V
C704 1-126-964-11 ELECT 10uF 20.00% 50V
C705 1-126-964-11 ELECT 10uF 20.00% 50V
C706 1-126-933-11 ELECT 100uF 20.00% 16V
C707 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C709 1-126-048-81 ELECT 10uF 20.00% 50V
C711 1-126-052-11 ELECT 100uF 20.00% 50V
C712 1-136-489-00 FILM 0.022uF 5.00% 50V
C713 1-136-489-00 FILM 0.022uF 5.00% 50V
C714 1-126-048-81 ELECT 10uF 20.00% 50V
C715 1-136-493-00 FILM 0.047uF 5.00% 50V
C716 1-130-479-00 MYLAR 0.0047uF 5% 50V
C717 1-126-048-81 ELECT 10uF 20.00% 50V
C718 1-136-494-00 FILM 0uF 5% 1/16W
C719 1-136-494-00 FILM 0.056uF 5.00% 50V
C720 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C721 1-126-048-81 ELECT 10uF 20.00% 50V
C722 1-216-864-11 METAL CHIP 0 5% 1/16W
C726 1-126-048-81 ELECT 10uF 20.00% 50V
C727 1-126-048-81 ELECT 10uF 20.00% 50V
C731 1-126-044-11 ELECT 1uF 20.00% 50V
C732 1-126-044-11 ELECT 1uF 20.00% 50V
C733 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C734 1-126-048-81 ELECT 10uF 20.00% 50V
C735 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C736 1-126-048-81 ELECT 10uF 20.00% 50V
C737 1-162-971-11 CERAMIC CHIP 0.001uF 10.00% 50V
C739 1-126-048-81 ELECT 10uF 20.00% 50V
C740 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C745 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C746 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C747 1-162-920-11 CERAMIC CHIP 27PF 5% 50V
C749 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C750 1-104-664-11 ELECT 47uF 25V
C751 1-162-953-11 CERAMIC CHIP 100PF 5% 50V
C752 1-126-964-11 ELECT 10uF 20.00% 50V
C753 1-162-953-11 CERAMIC CHIP 100PF 5% 50V
C754 1-126-964-11 ELECT 10uF 20.00% 50V
L.SENSOR MAIN
