– 143 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
< TERMINAL >
TM401 1-537-240-31 TERMINAL BOARD (CHECKER PIN)(SPEAKER)
< VIBRATOR >
X551 1-567-098-41 VIBRATOR, CRYSTAL (32.768MHz)
X613 1-579-930-12 VIBRATOR, CERAMIC (16MHz)
**************************************************************
A-4419-305-A MD DIGITAL BOARD, COMPLETE
**************************
< CAPACITOR >
C171 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C201 1-163-227-11 CERAMIC CHIP 10PF 0.5PF 50V
C202 1-163-227-11 CERAMIC CHIP 10PF 0.5PF 50V
C203 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C204 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C216 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C341 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C342 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C343 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C350 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C351 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C352 1-126-204-11 ELECT CHIP 47uF 20% 16V
C353 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C355 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C357 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C358 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C359 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C360 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C362 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C363 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C503 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C509 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C510 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C522 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C527 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C528 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C529 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C2001 1-163-038-91 CERAMIC CHIP 0.1uF 25V
< CONNECTOR >
CN101 1-770-072-11 CONNECTOR,(LIF(NON-ZIF))FFC23P
CN102 1-784-687-41 PIN, CONNECTOR (PC BOARD) 7P
CN103 1-784-834-21 CONNECTOR,FFC(LIF(NON-ZIF))23P
CN104 1-784-833-21 CONNECTOR,FFC(LIF(NON-ZIF))21P
CN105 1-784-863-21 CONNECTOR,FFC(LIF(NON-ZIF))11P
< IC >
IC153 8-759-481-19 IC LB1830M-S-TE-L
IC201 8-759-553-65 IC UDA1341TS
IC202 8-759-564-53 IC MC74HCU04ADTR2
IC316 8-759-585-60 IC M30624MG-A01FP
IC2000 8-759-195-81 IC TC7S86FU
< COIL >
L181 1-424-675-11 INDUCTOR 33uH
L201 1-500-445-21 FERRITE 0uH
L202 1-500-445-21 FERRITE 0uH
< TRANSISTOR >
Q350 8-729-028-99 TRANSISTOR RT1N144M-TP-1
< RESISTOR >
R201 1-216-121-91 RES,CHIP 1M 5% 1/10W
R202 1-216-041-00 METAL CHIP 470 5% 1/10W
R203 1-216-049-91 RES,CHIP 1K 5% 1/10W
R204 1-216-089-91 RES,CHIP 47K 5% 1/10W
R205 1-216-113-00 METAL CHIP 470K 5% 1/10W
R206 1-216-073-00 METAL CHIP 10K 5% 1/10W
R207 1-216-025-91 RES,CHIP 100 5% 1/10W
R330 1-216-073-00 METAL CHIP 10K 5% 1/10W
R331 1-216-097-91 RES,CHIP 100K 5% 1/10W
R333 1-216-073-00 METAL CHIP 10K 5% 1/10W
R349 1-216-073-00 METAL CHIP 10K 5% 1/10W
R351 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R352 1-216-053-00 METAL CHIP 1.5K 5% 1/10W
R353 1-216-053-00 METAL CHIP 1.5K 5% 1/10W
R358 1-216-073-00 METAL CHIP 10K 5% 1/10W
R361 1-216-073-00 METAL CHIP 10K 5% 1/10W
R363 1-216-073-00 METAL CHIP 10K 5% 1/10W
R366 1-216-097-91 RES,CHIP 100K 5% 1/10W
R367 1-216-097-91 RES,CHIP 100K 5% 1/10W
R383 1-216-073-00 METAL CHIP 10K 5% 1/10W
R384 1-216-073-00 METAL CHIP 10K 5% 1/10W
R385 1-216-073-00 METAL CHIP 10K 5% 1/10W
R386 1-216-073-00 METAL CHIP 10K 5% 1/10W
R391 1-216-073-00 METAL CHIP 10K 5% 1/10W
R395 1-216-073-00 METAL CHIP 10K 5% 1/10W
R400 1-216-073-00 METAL CHIP 10K 5% 1/10W
R816 1-216-216-00 RES,CHIP 5.6K 5% 1/8W
R817 1-216-216-00 RES,CHIP 5.6K 5% 1/8W
R818 1-216-174-00 RES,CHIP 100 5% 1/8W
R819 1-216-174-00 RES,CHIP 100 5% 1/8W
R2002 1-216-073-00 METAL CHIP 10K 5% 1/10W
R2004 1-216-025-91 RES,CHIP 100 5% 1/10W
R2005 1-216-025-91 RES,CHIP 100 5% 1/10W
R2006 1-216-025-91 RES,CHIP 100 5% 1/10W
R2007 1-216-025-91 RES,CHIP 100 5% 1/10W
< VIBRATOR >
X201 1-767-286-11 VIBRATOR, CRYSTAL (22MHz)
X302 1-781-155-21 VIBRATOR, CERAMIC (10MHz)
**************************************************************
MD DIGITAL
MAIN
