– 144 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
A-4419-326-A MD LINK BOARD, COMPLETE (AEP,UK,G,CIS)
***********************
A-4419-499-A MD LINK BOARD, COMPLETE
***********************
(EXCEPT AEP,UK,G,CIS)
< CAPACITOR >
C201 1-164-159-11 CERAMIC 0.1uF 50V
C202 1-124-635-00 ELECT 220uF 20% 6.3V
C204 1-162-600-11 CERAMIC 0.0047uF 30% 16V
C205 1-162-282-31 CERAMIC 100PF 5% 50V
C206 1-162-283-31 CERAMIC 150PF 10% 50V
C251 1-164-159-11 CERAMIC 0.1uF 50V
C420 1-162-294-31 CERAMIC 0.001uF 10% 50V
C421 1-126-157-11 ELECT 10uF 20% 16V
C470 1-162-294-31 CERAMIC 0.001uF 10% 50V
C471 1-126-157-11 ELECT 10uF 20% 16V
< CONNECTOR >
CN201 1-793-097-11 SOCKET, CONNECTOR 11P
CN202 1-506-483-21 PIN, CONNECTOR 4P
CN401 1-790-428-11 JACK
< EARTH TERMINAL >
* E201 1-537-738-21 TERMINAL, EARTH
< IC >
IC403 8-749-015-19 IC PHOTO COUPLER ON3131-SA.S0
IC405 8-719-802-25 IC PHOTO TRANSISTOR TLP550-O
< TRANSISTOR >
Q201 8-729-900-80 TRANSISTOR DTC114ES
Q202 8-729-141-30 TRANSISTOR 2SC3623A-LK
Q204 8-729-119-78 TRANSISTOR 2SC403SP-51
Q205 8-729-900-80 TRANSISTOR DTC114ES
< RESISTOR >
R201 1-249-395-11 CARBON 15 5% 1/4W F
R202 1-247-807-31 CARBON 100 5% 1/4W
R203 1-247-807-31 CARBON 100 5% 1/4W
R204 1-249-411-11 CARBON 330 5% 1/4W
R205 1-249-431-11 CARBON 15K 5% 1/4W
R206 1-249-431-11 CARBON 15K 5% 1/4W
R207 1-249-417-11 CARBON 1K 5% 1/4W F
R208 1-249-426-11 CARBON 5.6K 5% 1/4W
R209 1-249-408-11 CARBON 180 5% 1/4W F
R230 1-249-429-11 CARBON 10K 5% 1/4W
R231 1-249-429-11 CARBON 10K 5% 1/4W
R232 1-249-441-11 CARBON 100K 5% 1/4W
R234 1-249-417-11 CARBON 1K 5% 1/4W F
R251 1-249-395-11 CARBON 15 5% 1/4W F
R252 1-247-807-31 CARBON 100 5% 1/4W
**************************************************************
1-673-382-11 MD LINK SW BOARD
*****************
< DIODE >
D753 8-719-063-93 DIODE SLR325VC-N-T32 (MD WALKMAN SYNC)
< RESISTOR >
R750 1-249-407-11 CARBON 150 5% 1/4W F
R762 1-249-427-11 CARBON 6.8K 5% 1/4W F
< SWITCH >
S762 1-762-875-21 SWITCH, KEYBOARD (MD WALKMAN SYNC)
**************************************************************
* 1-658-578-11 MOTOR (SLIDE) BOARD
*******************
< CAPACITOR >
C801 1-162-306-11 CERAMIC 0.01uF 20% 16V
C804 1-162-306-11 CERAMIC 0.01uF 20% 16V
C805 1-126-964-11 ELECT 10uF 20% 50V
< CONNECTOR >
* CN801 1-568-947-11 PIN, CONNECTOR 9P
< DIODE >
D801 8-719-921-48 DIODE MTZJ-T-72-5.6C
D804 8-719-911-19 DIODE 1SS119
D805 8-719-911-19 DIODE 1SS119
< IC >
IC801 8-759-274-09 IC BA6286N
< RESISTOR >
R801 1-249-401-11 CARBON 47 5% 1/4W F
< SWITCH >
S801 1-762-527-11 SWITCH, ROTARY (OPEN/CLOSE)
**************************************************************
* 1-658-577-11 MOTOR (TURN) BOARD
******************
< CAPACITOR >
C701 1-162-306-11 CERAMIC 0.01uF 20% 16V
C702 1-126-964-11 ELECT 10uF 20% 50V
C705 1-162-306-11 CERAMIC 0.01uF 20% 16V
< CONNECTOR >
CN703 1-750-413-11 CONNECTOR, FFC/FPC 8P
CN704 1-506-469-11 PIN, CONNECTOR 4P
< DIODE >
D701 8-719-983-66 DIODE MTZJ-T-72-3.6B
MOTOR (SLIDE)
MOTOR (TURN)
MD LINK
MD LINK SW
