– 145 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
< IC >
IC701 8-759-633-65 IC M54641L
< RESISTOR >
R706 1-249-411-11 CARBON 330 5% 1/4W
R707 1-249-401-11 CARBON 47 5% 1/4W F
**************************************************************
1-673-381-11 POWER SW BOARD
****************
< DIODE >
D751 8-719-063-93 DIODE SLR325VC-N-T32 (1/u)
< RESISTOR >
R763 1-249-414-11 CARBON 560 5% 1/4W F
**************************************************************
1-673-377-11 SECONDARY BOARD
*****************
< CONNECTOR >
CN881 1-564-525-11 PLUG (MICRO CONNECTOR) 10P
(US,CND,AEP,UK,G,CIS)
* CN881 1-564-527-11 PLUG (MICRO CONNECTOR) 12P
(E,SP,MY,HK,AR,KR,AUS)
< FUSE >
! F881 1-532-506-31 FUSE (T6.3AL/250V)(EXCEPT US,CND)
! F881 1-576-109-21 FUSE (T6.3AL/250V)(US,CND,E,HK,AR)
! F882 1-532-504-31 FUSE (T4AL/250V)(E,SP,MY,HK,AR,KR,AUS)
! F883 1-532-504-31 FUSE (T4AL/250V)(E,SP,MY,HK,AR,KR,AUS)
! F884 1-532-506-31 FUSE (T6.3AL/250V)(EXCEPT US,CND)
! F884 1-576-109-21 FUSE (T6.3AL/250V)(US,CND,E,HK,AR)
< FUSE HOLDER >
FH8810 1-533-293-11 FUSE HOLDER
FH8811 1-533-293-11 FUSE HOLDER
FH8820 1-533-293-11 FUSE HOLDER (E,SP,MY,HK,AR,KR,AUS)
FH8821 1-533-293-11 FUSE HOLDER (E,SP,MY,HK,AR,KR,AUS)
FH8830 1-533-293-11 FUSE HOLDER (E,SP,MY,HK,AR,KR,AUS)
FH8831 1-533-293-11 FUSE HOLDER (E,SP,MY,HK,AR,KR,AUS)
FH8840 1-533-293-11 FUSE HOLDER
FH8841 1-533-293-11 FUSE HOLDER
< RESISTOR >
! R881 1-240-877-91 FUSIBLE 0.15 5% 1/2W F
! R882 1-240-877-91 FUSIBLE 0.15 5% 1/2W F
! R883 1-240-877-91 FUSIBLE 0.15 5% 1/2W F
**************************************************************
* 1-658-576-11 SENSOR BOARD
************
< IC >
IC702 8-749-924-18 IC PHOTO INTERRUPTER RPI-1391
IC703 8-749-924-30 IC PHOTO REFLECTOR GP2S28
**************************************************************
A-4419-327-A STANDBY BOARD, COMPLETE (AEP,UK,G,CIS)
***********************
A-4419-328-A STANDBY BOARD, COMPLETE (E,SP,MY,HK,AR)
***********************
A-4419-329-A STANDBY BOARD, COMPLETE (US,CND)
***********************
A-4419-330-A STANDBY BOARD, COMPLETE (AUS)
***********************
A-4419-651-A STANDBY BOARD, COMPLETE (KR)
***********************
< CAPACITOR >
C11 1-126-937-11 ELECT 4700uF 20% 16V
C12 1-164-159-11 CERAMIC 0.1uF 50V
C13 1-126-933-11 ELECT 100uF 20% 16V
C14 1-126-968-11 ELECT 100uF 20% 50V
C15 1-164-159-11 CERAMIC 0.1uF 50V
C16 1-126-948-11 ELECT 100uF 20% 35V
C17 1-104-664-11 ELECT 47uF 20% 16V
C21 1-113-925-11 CERAMIC 0.01uF 20% 250V
(US,CND)
C22 1-164-159-11 CERAMIC 0.1uF 50V
(EXCEPT US,CND)
< CONNECTOR >
CN11 1-564-321-00 PIN, CONNECTOR 2P (KR)
* CN11 1-580-230-11 PIN, CONNECTOR (PC BOARD) 2P (EXCEPT KR)
CN12 1-564-321-00 PIN, CONNECTOR 2P
(US,CND,AEP,UK,G,CIS,KR,AUS)
* CN12 1-564-687-11 PIN, CONNECTOR 3P (E,SP,MY,HK,AR)
* CN13 1-568-935-11 PIN, CONNECTOR 8P
< DIODE >
D11 8-719-911-19 DIODE 1SS119-25
D12 8-719-024-99 DIODE 11ES2-NTA2B
D13 8-719-024-99 DIODE 11ES2-NTA2B
D14 8-719-024-99 DIODE 11ES2-NTA2B
D15 8-719-024-99 DIODE 11ES2-NTA2B
D16 8-719-911-19 DIODE 1SS119-25
D17 8-719-024-99 DIODE 11ES2-NTA2B
D18 8-719-024-99 DIODE 11ES2-NTA2B
D19 8-719-024-99 DIODE 11ES2-NTA2B
D20 8-719-024-99 DIODE 11ES2-NTA2B
D21 8-719-986-67 DIODE HZS33-2LTA
D22 8-719-921-48 DIODE MTZJ-T-72-5.6C
D23 8-719-911-19 DIODE 1SS119-25
D24 8-719-911-19 DIODE 1SS119-25
D25 8-719-911-19 DIODE 1SS119-25
STANDBY
SECONDARY
Les composants identifiés par une
marque ! sont critiques pour la
sécurité.
Ne les remplacer que par une
piéce portant le numéro spécifié.
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
SENSORMOTOR (TURN) POWER SW
